- Page 1 POWER SUPPLY USER MANUAL www.panther.tv...
- Page 2 Your new Panther Product is designed to power the equipment that you love working with. To ensure that you will love working with your Panther Product and that all requirements during shooting can be fulfilled considering utmost safety and reliability, please carefully read this user manual.
-
Page 3: General Information
AGM Battery: 24V - Charging time: approx. 5-7 hours 80-90% = full 27-28,5V = full - Charge only with suitable 24V charger. We recommend the Panther Charging Station (313165). Important: 24V = empty 50% = empty Recharge after use! Do not short Circuit! -
Page 4: Connecting Cables
CAPACITY TESTER OVERVIEW This battery capacity tester can test the voltage and capacity of battery, and display them with intuitive battery symbol and percentage. Users can know the state of battery in time. Remove / Install The Tester is fixed by buckles, so it is easy to remove / install. Use a flat screw driver to do so. Connecting Cables This is how you have to connect the cables:... -
Page 5: Display Mode
CAPACITY TESTER USAGE Functions The Tester has two functions : F0 and F2. Use the“K+” key on the back to select F0 and F2. Then press the“OK”key on the front, the selected function will run. The default function is F2. F0: Backlight on Tester run all the time, LCD and backlight always on. -
Page 6: Charging Station
CHARGING CHARGING STATION Charge smart: with the Charging Station (313165) you can charge up to 2 „Slide-In“ Batteries or 2 „Snap-On“ Batteries simultaneously. Slide-In Battery Charging Station Snap-On Battery Charging: Snap-On Battery Plug in the 1-Way Charge Cable (134643) into the Snap-On battery and into the Charging Station. Charging: Slide-In Battery Slide in the Slide-In Battery on the top side of the Charging Station. -
Page 7: Front Panel Led Indicators
Charger for AGM batteries Built-in 3 stage programmable charging curve Fanless design, cooling by free air convection Protection: Short circuit / Over voltage / Over temperature / Battery under voltage / Battery over voltage / Battery reverse polarity protection Boost Charge Voltage (Vboost) (default) 28.8V Float Charge Voltage (Vfloat) (default) 27.6V Output... -
Page 8: Safety Guidelines
SAFETY Safety Guidelines • Do not use in wet or humid conditions • The cables between charger and battery should be kept as short as possible to prevent excessive voltage drop (suggested cable length: 50cm - 100cm). Too much voltage drop will lead to longer charging period. - Page 9 NOTES...
-
Page 10: Further Assistance
FURTHER ASSISTANCE If you need any further assistance with this instructions (or also other questions) please contact our service department. SERVICE PHONE: SERVICE MAIL: (+49) 8095 71230 - 05 eric.suchetet@panther.tv ADDRESS PHONE / FAX ONLINE Phone: Am Bahnhof 19 (+49) 8095 71230 - 00 contact@panther.tv...
