Table of content Product overview ............................................3 1.1. Appearance............................................3 1.2. Product specification ..........................................3 1.3. Content of the package..........................................4 1.4. Storage and transportation ........................................4 Installation instruction ............................................ 4 2.1. Safety tips .............................................. 4 2.2. Installation guide ............................................ 4 Charging instructions ............................................ - Page 3 Application SAFETY INSTRUCTIONS The Smart Mini Charging Station is a device that connects to an AC • The person installing and using the charger must follow the (alternating current) network to charge the battery of an electric vehicle with sufficient power. instructions for safety.
-
Page 4: Product Overview
1. Product overview 1.2. Product specification Model: TS-EVC07-003 TS-EVC11-003 TS-EVC22-003 1.1. Appearance 230V AC 380V AC 380V AC Rated voltage ±10% ±10% ±10% Max output current Frequency 50/60Hz 50/60Hz 50/60Hz Max output power 7 kW 11 kW 22 kW Charging socket Type1 or Type2 + 4M charging cable Housing material PCV0 for outdoor usage... -
Page 5: Content Of The Package
2. Installation instruction 1.3. Content of the package Safety tips 2.1. Smart Mini charger Wall-mount bracket The charger does not contain any user-repairable parts. Do not attempt to repair or service the charger yourself. If your device needs repair, contact us. Mounting materials Protect the charger from external impact. - Page 6 Pedestal installation dimension Wall-mounted dimension...
- Page 7 Wall installation Installation method 2: Installation method 1: 1. Remove the two fixing screws from the bottom of the cover plate, then push the front plate upwards to remove. 3. Use the drill to 4. Insert the fixing make mounting dowels into the holes suitable...
-
Page 8: Charging Instructions
3.2.2. After successful login, the app will list the available 3. Charging instructions available devices. 3.1. Charge preparation After turning on the charger, download the "TEISON ME" mobile app to your device. Download it from the App Store for iOS and from the Google Play store for Android. - Page 9 3.2.4. There are three function buttons in the lower menu bar: Start/Stop 3.2.5. Click on the function button in the top right corner to access (Charging start/stop), Reserve (Scheduled charging setting), and network settings. You can then choose to set up a Wi-Fi or 4G (LTE) Setting, where you can set the charging current and the Plug &...
-
Page 10: Help And Issue Feedback
3.3. Help and issue feedback 3.2.6. Enter the correct Wi-Fi settings (Wi-Fi name, password) for the charger, after successful connection the charger will configure the network settings. 3.3.1. The charger is on and connected correctly, but it is not Once the network settings are completed, the charger will be online. If the found in the app: Bluetooth connection remains active, the user can control the charger via Wi- Fi or Bluetooth connection. -
Page 11: Lcd Indicator Light
4. Maintenance instructions 3.4. LCD indicator light 4.1. Caution Check the incoming and outgoing wires on a monthly basis to make sure they are not damaged. 4.2. Error signals Red light flash times Condition LED status (N+ 5s stop) Electric leakage Over-voltage LED status Red/Green/Blue... -
Page 12: Warranty Card
5. Warranty card Product name: Model: Warranty date: Name of the user: Contact phone: Mail address: Name of distributor: Email of the distributor:...
