LIGMAN EU-20256 Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
For Installation of Eurasia post top luminaire.
Model. EU-20256,20286 and EU-20406
Product drawing (dimensions)
EU-20256
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-1 standard.
Technical amendments and modifications techniques reserved.
L i g m a n L i g h t i n g
Europe Headquarters
Ligman Europe s.r.o.
VGP Park Usti nad Labem, P 2
Prestanov 113
403 17 Prestanov
Czech Republic
Tel. +420 608 740 504 sales.cz@ligman.com
|
www.ligman.com
IP55 IK08 CLASS I
EU-20286 EU-20406
(1) DOME TOP
(2) FLAT TOP
(3) POINTED TOP
Thailand Headquarters
Ligman Lighting Co., Ltd.
17/2 Moo 4, Monthong, Bangnampreaw
Chachoengsao 24150 Thailand
Tel : +66 (2) 7339140
info@ligman.com
4,5
TOOL
M EU-20256/21/04/17/REV.3
1/2
20 30
6
EU-30216
CABLE SIZE : 3x1.0mm
L
N
Push
Torque:10.6Nm.
