OPERATING AND INSTALLATION INSTRUCTIONS
Remote control
Topper Mertik AB
Topper Dungs AB
ten behoeve van Topper Gasblokkenvuren
Applicable to the following Topper models:
2413, 2424, 3613, 4525, 4813 , 6013, 9013, 9513, 12013
Topper Steel:
5015 (1060)
8015 (1061)
10015 (1062)
12015 (1063)
14015 (1064)
Advertisement
Summary of Contents for Thermocell Topper 2413
- Page 1 Pag.1 OPERATING AND INSTALLATION INSTRUCTIONS Remote control Topper Mertik AB Topper Dungs AB ten behoeve van Topper Gasblokkenvuren Applicable to the following Topper models: 2413, 2424, 3613, 4525, 4813 , 6013, 9013, 9513, 12013 Topper Steel: 5015 (1060) 8015 (1061) 10015 (1062) 12015 (1063) 14015 (1064)
- Page 2 General page 3 Pag.2 Contents of the packaging Safety of the unit page 4 Safety Remote control (Mertik GV60) page 5 General Manual transmitter Screen setup Setting the time Operation (Remote Control) Possible error messages Setting the flame size / Extinguishing the fire Switching the unit off Inserting and replacing the batteries Manual operation...
-
Page 3: Package Contents
Pag.3 We hope that you enjoy the warmth of your new Topper Burner. Read these instructions carefully before installing and using the Topper Burner. Keep these instructions in a safe place. Always provide the follow- ing information if the burner breaks down: model and serial number, which can be found on the unit. Your receipt of purchase is your proof of warranty. -
Page 4: Safety Device
Pag.4 2. SAFETY DEVICE The unit is fully safeguarded by means of thermo-electric pilot light protection to prevent unforeseen discharge of gas from the main burner. 2.1 Safety Do not place ceramic burner decoration material or logs against the pilot burner. Ensure the pilot light is able to burn freely over the main burner. -
Page 5: Remote Control
Pag.5 REMOTE CONTROL Please note: Before the device is switched on, the air supply flue gas discharge valve must be opened. The control knob is located front-right in the unit. If this valve is not open, the unit will not function General The unit is operated using a radio-controlled remote control. - Page 6 Pag.6 Operation (Remote Control) Igniting the flame Open the gas shut-off cock that has been installed in the gas pipe to the unit. Press the “O I” switch on the gas control block to the “I” position. Turn the operating button on the gas control block into the ON position. Press the OFF (large) switches on the remote control at the same time.
- Page 7 Pag.7 Setting the flame height / extinguishing the flame After the burner is ignited, the flame size will adjust to its maximum height automatically. Press the button (small) on the image of the flame to reduce the height and to switch the burner off. (Extinguishing the flame: “STAND BY”).
- Page 8 Pag.8 MANUAL OPERATION (in case of emergency, only if remote control is not working) The unit may be operated by hand if there is a defect in the remote control. To do so, the ignite (piezo)cable of the receiver must first be removed and carefully slid into the piezo connector on the gas control block. Small metal circle for manual operation of the ignition...
- Page 9 Page.9 INSTRUCTIONS FOR THE MERTIK MAXITROL GV60 AND REMOTE CONTROL: Ensure that the fuel supplied to the unit is clean and free from particles and moisture. Before a gas supply pipe (new or existing) is connected to the main gas pipe at the gas meter and to the gas control block of the unit, clean and dry compressed air should been blown through it.
- Page 10 Page.10 Do not extend the thermocouple supplied to the pilot set Extending the thermocouple beyond its limit will lead to a reduction in voltage. This may, in turn, lead to the magnetic coil not being activated. Prevent leakage of the ignition spark to parts of the installation other than the ignition rod at the pilot. Ensure the ignition cable is not in contact with the shell or other metal parts.
- Page 11 6. TECHNICAL DETAILS GV60 Page.11 Gas block type : Mertik GV60 M1-C5D3KL-0001 Automat type : G6R-R4Ax Ignition : Distance operation and Piezo ignition : 3/8" (Internal) A=Gas intake B=Gas exhaust C=Thermocouple connection Gas connection D=Pilot burner connection Unit category : C11-C31-C91 Pilot flame : SIT 3 flames Combustion gas discharge...
- Page 12 Page.12...
- Page 13 Page.13 Mertik GV60 Troubleshooting Flow Chart ACTION Possible problem/cause Solution Option: wall switch START: Bent pin on switch, or cable not Straighten pin, replace wall switch press ON button > wall switch operating properly. or cable. works. Manual transmitter START: press Manual transmitter battery low.
- Page 14 Page.14 ACTION Possible problem/cause Solution Ignition components not operating properly. Check connection between cable & IGN electrode. Check IGN electrode spark gap. Check IGN electrode for discharge to ground (break in ceramic). Check IGN cable for damage Increase distance between IGN cable and all metal parts.
- Page 15 Page.15 ACTION Possible problem/cause Solution Resistance in thermo Check cables and connections in current circuit too high. thermo current circuit. Magnet unit drops Not enough heat on Check position of pilot to (audible click) thermocouple. thermocouple and intensity of pilot flame.
- Page 16 Page.16 OPERATING INSTRUCTIONS DUNGS GAS REGULATOR COMBINATION AB This regulator is fitted with a complete infra-red control system. This means that you can ignite the unit, smoothly adjust the flame height and extinguish the unit using the remote control. Infra-red remote control and its operation The infra-red remote control allows you to comfortably control the AB system.
-
Page 17: Electrical Connection
Page.17 After completing any work: Test for leaks and check operation. Connecting to the mains supply The regulation equipment is fitted with an electronic control. Take into account the length of the cable when connecting to a power socket. Chimney If it is connected to a chimney that had previously been connected to a wood-fuelled fire, than the flue should be thoroughly and professionally cleaned as dirt can still become dislodged from the chimney when used with gas. -
Page 18: Basic Diagram
Page.18 BASIC DIAGRAM... - Page 19 Page.19 Optional protected air supply and combustion gas flue system for type II gas-fired block fires in natu rally and mechanically ventilated homes. You can additionally connect an air supply and combustion gas flue system. The protection system is used in existing or newly installed type II block fires in open hearths which are set up in mechanically ventilated homes.
- Page 20 Page.20 COMBINATION DIAGRAM Dungs / Exhausto EFC 21 Operation using control knobs. (See pages 16 and 21) Three buttons are required for operation: - “UP” button – “DOWN” button – “RESET” button To start the system, press the “UP” en “DOWN” buttons together for at least three seconds. The start-up process is indicated by a se- ries of three short tones.
- Page 21 Page.21 Dungs gas regulation combination components...
- Page 22 Page.22 GAS TECHNICAL SPECIFICATIONS FOR TOPPER BURNERS 3613 >12013 3613 4813 6013 9013 6013 3613 4525 4813 9013 2413 2424 GASTYPE G30/31 G30/31 G30/31 G30/31 G25/G20 G25/G20 G25/G20 G25/G20 G25/G20 G25/G20 G25/G20 COUNTRY NL/NO/DE/ NL/NO/DE/ NL/NO/DE/ NL/NO/DE/ES/PT/ NL/NO/ES/ NL/NO/ES/ NL/NO/ES/ NL/NO/ NL/NO/ES/ NL/NO/ES/...
- Page 23 Page.23 10.1 GAS TECHNICAL SPECIFICATIONS FOR TOPPER STEEL BURNERS 5015 to 14015 1060 1060 1061 1061 1062 GASTYPE G20/G25 G30/31 G20/G25 G30/31 G20/G25 NL/DE/BE/DK/GB/IE/ NL/DE/BE/DK/GB/IE/NO/ NL/DE/BE/DK/GB/IE/NO/ NL/DE/BE/DK/GB/IE/NO/ NL/DE/BE/DK/GB/IE/NO/ COUNTRY NO/ES/FR/ ES/FR/ ES/FR/ ES/FR/ ES/FR/ GR/AT/CH/IT/PT/PL/CY/ GR/AT/CH/IT/PT/PL/CY/ GR/AT/CH/IT/PT/PL/CY/ GR/AT/CH/IT/PT/PL/CY/ GR/AT/CH/IT/PT/PL/CY/ LU/MT/RO LU/MT/RO LU/MT/RO LU/MT/RO...
- Page 24 Page.24 11.0 MAINTENANCE CHECK-UP LIST. Fitter details: Name Address Unit serial number Date of purchase Installation date Comments Service and maintenance logbook: Service date Performed by Work activities performed...
-
Page 25: Maintenance Activities
Page.25 12. MAINTENANCE ACTIVITIES. Please note: whenever possible, turn off the gas supply and power supply during maintenance activities. Maintenance activities should be performed by a qualified fitter. Close the gas tap while maintenance activities are being performed Inspect Works 1 General inspec- The main burner should ignite smoothly (within several seconds) and not give a bang sound due tion... -
Page 26: Instalation Instructions
Page.26 INSTALATION INSTRUCTIONS Important: The installation may only be performed by an authorised person. 13.1 General instructions The gas block fire must be installed, connected and inspected as a closed unit by a qualified fitter, according to national, regional, and local standards and regulations. The flue tube system and the outlets in the outer wall or roof face must also meet the requirements outlined in the applicable standards and regulations. - Page 27 Page.27 14. Installing the ceramic wood blocks - Standaard Before positioning the blocks, the accompanying Vermiculite glowing embers should be evenly spread over the burner. Model 2413 (see page 29) Position the 6 blocks at an angle on the burner. Model 2424 (see page 29) Position the 2x oak logs on the burner.
- Page 28 17. Covering burner 9013 with Carrara stones Page.28 9013 (see page 32) Carefully fill the burner with the supplied Carrara stones. Ensure that the ornamental peb- • ble stones do not impede the functioning of the pilot flame burner (keep it clear from the stones) Any remain- ing stones can be evenly spread across the platform (providing there are enough of them) level with the burner to give the burner tray a pleasant level appearance.
- Page 29 Page.29 STANDARD DE LUXE Topper 2413 Topper 2413 Topper 2424 Topper 2424 Topper 3613 Topper 3613 Topper 4525 Topper 4813 / 6013 Topper 4813 en 6013...
- Page 30 Page.30 Blok A direct op brander Achterzijde Voorzijde Blokken C Topper 2413 B/P Blok B Blok A direct op brander ontsteking/ waakvlam Blok A Topper 2424 B/P ontsteking/ waakvlam Blok C direct op brander Blok C Blok A...
- Page 31 Page.31 Topper 9013 B/P Topper 9513 NG Topper 12013 NG Topper Steel 1060 NG-B/P Topper Steel 1061, 1062, 1063, 1064 NG-B/P...
- Page 32 Page.32 Topper 9013/9513/12013 Vermiculite and Carrara Topper 9513 Topper 12013...
- Page 33 1060 NG Page.33...
- Page 34 1060 B/P Page.34...
- Page 35 Page.35 1061 NG - B/P...
- Page 36 1062 NG - B/P Page.36...
- Page 37 Page.37 1063 - 1064 NG - B/P...
- Page 38 Page.38 Pebbles Carrara...
- Page 39 Page.39 Thermocet International B.V. Laagerfseweg 31 3931 PC Woudenberg www.thermocet.nl...
