ISTRUZIONI DI UTILIZZO WB-44
* Verificare la disponibilità di nuovi prodotti compatibili con WB-44 sul sito www.dbtechnologies.com
* Please check the availability of new products compatible with WB-44 on www.dbtechnologies.com
WB-44-> Staffa per l'installazione a muro dei top ES1203TOP (sistema ES1203).
WB-44--> Wall bracket suitable for ES1203TOPs speakers (ES1203 system).
A
- n°1 STAFFA DI SOSTEGNO A MURO CON FORI DI MONTAGGIO x E y
no. 1 WALL BRACKET WITH x AND y MOUNTING HOLES
B
- n°1 PERNO FILETTATO A TESTA CAVA ESAGONALE E DADO FLANGIATO
no. 1 THREADED PIN WITH HEXAGONAL SOCKET HEAD AND FLANGE NUT
C
- n°1 STAFFA PER ES1203TOP CON ASOLA DI REGOLAZIONE z
no.1 ES1203TOP BRACKET WITH z ADJUSTING SLOT
D
- n°2 VITI A TESTA BOMBATA CAVA ESAGONALE
no.2 ROUND HEXAGONAL SOCKET HEAD SCREWS
ATTENZIONE: WB-44 deve essere utilizzato solo da personale qualificato! Assicurarsi che l'installazione sia
posizionata in modo stabile e sicuro per scongiurare ogni condizione di pericolo per persone, animali e/o
cose. L'utilizzatore è tenuto a verificare le regolamentazioni e le leggi cogenti in materia di sicurezza nel
Paese in cui si utilizza il prodotto. Installare il prodotto attenendosi a quanto illustrato in queste istruzioni.
WARNING: For installation of WB-44 use only specialist personnel! Make sure that the installation is
positioned in a stable and secure way in order to avoid any dangerous conditions for people, animals and/
or objects. It is mandatory to follow the safety law and regulations of the Country in which the equipment
is installed. Install the product as described in these instructions.
WB-44 INSTRUCTIONS
Accessorio
Accessory
WB-44
ES1203TOP
Prodotto*
Sistema
Product*
System
ES1203
WB-44
1
FOT000087 REV.1.0
