- Page 1 A8 Electric Scooter USER MANUAL...
-
Page 2: Table Of Contents
Product Features..............2 Accessories ................. 2 Specifications..............3 Assembly................3 Charger Your Scooter............4 How To Ride..............5 Folding.................. 6 Unfolding................6 Phantomgogo APP ............. 7 Safety Precautions.............. 8 Cleaning And Storage........... 12 ..........12 Battery Maintenance............12 Environmental Protection..........13 After-sales Service............. 14 Non-warranty Rule.............. -
Page 3: Product Features
Product Features Accelerator Handlebar Folding hook Brake lever Front tube Motor unit Folding handle Atmosphere light Charging port Function mode: Cruise mode, Pedestrian mode, Error prompt, Light, Bluetooth, Lock. Gear mode: The maximum speed limit is 3.8 mph for Gear L, 5.8 mph for Gear M and 15.5 mph for Gear H. -
Page 4: Specifications
Specifications Model Net weight 33 lbs Unfolded size 45.5× 7.5×19 inch Recommended age Recommended height 51~78 inch Maximum load 220 lbs Maximum speed 15.5 mph Mileage 28 miles Gradeability About 15% Waterproof certification IPX5 Charging time About 5.5 hours Over-charge, Over-temperature, Over-discharge, BMS management Over-current, Short circuit, Over-voltage Brake system... -
Page 5: Charger Your Scooter
Charge Your Scooter 1. The indicator light of the charger turns green when the scooter is connected to the power supply. 2. When actively charging, the light should switch to red from green. 3. After charging, the indicator light should switch back to green. Plug the power adapter Fasten the rubber into the charging port... -
Page 6: How To Ride
How To Ride 1. Press the Switch button to turn the scooter on and check the battery level. If the battery level is too low, please charge it before riding. 2. Stand with one foot on the baseboard and kick off against the ground with your other foot. -
Page 7: Folding
Folding folding handle; fold the front tube clamp, align the folding hook and put it into the hook fixing buckle; lift the front tube and Unfolding Press the red button on the folding hook to remove the hook from the folding retaining buckle, straighten the front tube, close... -
Page 8: Phantomgogo App
Press the button to turn on the scooter and then turn on the Bluetooth function of your mobile phone. STEP 2 Open the Phantomgogo APP. Please register/log in to your account according to the app instructions. STEP 3 On the APP homepage, select “Search the binding”. The according to the prompt in the APP interface. -
Page 9: Safety Precautions
Safety Precautions 1. Please carefully read the User Manual, which will assist in explaining the basic working principles and provide tips on how to best enjoy your scooter experience. 2. Please wear all appropriate safety and protective gear as previously mentioned in the User Manual before operating the scooter. - Page 10 17. Do not attempt to ride over bumps or objects greater than 0.6 inch even when prepared and bending your knees. 18. PAY ATTENTION - look to where you are riding and be attentive of the road conditions, people, places, property and objects around you.
- Page 11 36. Do not ride the scooter near or over potholes, cracks or uneven pavement. 38. Do not exceed the maximum weight limit of 220 lbs. 39. Avoid driving the scooter in unsafe places, including near 40. Scooter users are recommended to be 12+ years and 55 to 78 inch tall.
- Page 12 53. Do not place the scooter in a high temperature higher than 122F or a low temperature lower than -4F. Do not put the scooter into a fire, otherwise it may lead to battery failure, overheating, and even fire risk. 54.
-
Page 13: Cleaning And Storage
Tips: Do not use alcohol, gasoline, kerosene or other corrosive and volatile chemical solvents to clean, otherwise it will seriously damage the appearance and internal structure of the body. Do not use pressurized water to spray and wash. is tightly fastened during cleaning, otherwise electric shock or serious failure may occur due to internal water flow. -
Page 14: Environmental Protection
personal injury or death. 5. Avoid recharging after the battery is completely depleted, and try to charge as soon as possible to prolong the service life of the battery. 6. Only use the original power adapter when charging, or else 7. -
Page 15: After-Sales Service
After-sales Service This product strictly implements the relevant laws and regulations from the date of purchase: ● For problems within 1 month of ownership, users can opt for a replacement scooter. For problems within 12 months of ownership, users can abide ●... -
Page 16: User Stub
User Stub User information (Please fill in the real information. User information will only be used for after-sales warranty services). User name： Phone number： E-mail： Postal code： Address： Product information Product name： Model： SN code： Color： Date of manufacture ： Service：... -
Page 17: Manufacturer Stub
Manufacturer Stub User information (Please fill in the real information. User information will only be used for after-sales warranty services). User name： Phone number： E-mail： Postal code： Address： Product information Product name： Model： SN code： Color： Date of manufacture ： Service：... -
Page 18: Fault Code
Fault Code Description of Corresponding Solution Code Fault Content Parts Undervoltage, Please charge in time. Battery low battery Overvoltage, Needs to unplug the Battery too high battery charger. Controller Fault Controller needs to be Controller replaced. After 15 minutes of shutdown, restart to confirm MOS Tube Fault Controller... - Page 19 Description of Corresponding Solution Code Fault Content Parts Check the brake lever connection line, if the connection is normal, Brake Lever Fault Brake Lever whether the fault is resolved; if not, the brake lever needs to be replaced. Shut down for 5 minutes, then restart to confirm OCP Protection Controller...
- Page 20 Contact us via email info@phantomgogo . com or call us at (888)-780-1685 if you need replacement parts, or have any questions. We will reply within 24 hours.
Need help?
Do you have a question about the A8 and is the answer not in the manual?
Questions and answers
How do you fold the other model R1 scooter
To fold the Phantomgogo A8 scooter:
1. Push the designated latch or locking mechanism.
2. Press the black part near the latch.
3. Pull the front tube while pressing the latch.
4. Align the "P"-shaped hook into the locking slot.
5. Once aligned, it will lock in place.
6. The scooter is now folded and can be lifted and carried.
This answer is automatically generated
How do I unlock my phantom go to e scooter?
To unlock the speed limit on the Phantomgogo A8 e-scooter, follow this method:
1. Turn off the scooter.
2. Push the scooter to gain speed—either down a hill or on flat ground.
3. While the scooter is rolling at higher speed, turn it on.
This may bypass the 15 mph speed limit temporarily. No disassembly is required.
This answer is automatically generated
How do I get the wiring diagram for a phantom go go
The context does not provide a wiring diagram, but it mentions that you can contact Phantomgogo for replacement parts or questions. To obtain the wiring diagram, contact them via email at info@phantomgogo.com or call (888)-780-1685.
This answer is automatically generated
What does the wrench symbol mean
@Joann hi tht symbol means something on your scooter needs to be fixed things is could be 1. The back of brakes the red slot thing might be pushed forward so check that 2. You might need air in one of both of your tires just go to any gas station and they will help with air 3. Check your brake switch on handle bars see if it has any damage like from falling on the ground you can unscrew that yourself and re hook it back up but be very wise while doing so.
How do you change the rear tire & Tube on the Phantom GoGo scooter
Tire pressure?
Looking foR new headset bearings for the A8
It's on L how to change it faster
To change the speed setting on the Phantomgogo A8, press the switch button twice while the scooter is powered on.
This answer is automatically generated
