- Page 1 · 自 律 · 自 由 · FRAMESET USER MANUAL www.yoeleobike.com @yoeleo Yoeleo...
- Page 2 Frameset Diagrams Saddle clamp Top cap The R11's component parts are listed from . You will receive all the parts Stem bolts nut inside your package. Stem bolt Spacers Handlebar Rear brake hose Bearing cover Front derailleur cable Compression plug Split ring Rear derailleur cable Seatpost...
- Page 3 Brake & Gear Housing Routing Route the housing into the down tube of the frame from the hole where each house comes out. Please measure the correct length of the brake and shifter housing before cutting. Rear brake hose Front derailleur cable Rear derailleur cable Front brake hose Sponge tube...
- Page 4 Headset Bearing Installation Please route the cable housing FIRST before install the bearings. Lightly grease the contact point between metal and carbon surface. Top cap Compression plug Handlebar Spacer (10mm) Stem bolts nut Spacer (10mm) Stem bolt Spacer (5mm) Bearing cover Split ring (10mm) Headset bearings...
- Page 5 Spacers Installation Pick the right spacer height to adjust your riding position. Remember to route the housing inside bearing cover ring before routing inside the handlebar. Handlebar Internal Routing Spacer (10mm) Route housing to the Lever from this hole. Spacer (10mm) Compression plug Spacer (5mm) Compression Plug...
- Page 6 Seatpost Installation If needed, change the height of the seats and cut off any extra length. Remember that the minimum insertion is 10 CM. Saddle Clamp Assembly Saddle Angle Adjuster Saddle Wedge Slider Change the saddle's position forward and backward. Seatpost Tightening Seatpost clamp To tighten the seatpost wedge, turn the bolt...
- Page 7 Mount Fixing Points Carefully observe the bolt's length before attempting to tighten. Bottle cage Bottle cage bolt*4 Frameset User Manual...
- Page 8 Safety Legend WARNING Properly tighten hardware Apply appropriate grease always tighten hardware to the specified torque. Over-tightening hardware could deform or break the hardware or components. Under-tightening hardware could cause hardware or components to become loose. Either situation could damage Apply threadlocker the bicycle and result in injury to the rider.
-
Page 9: Installation
A Quick guide for installation Shifting cable and brake house routing Rear brake hose Rear derailleur cable Di2 wire Front derailleur cable Front brake hose Internal Routing Frameset Traditional Frameset In order to use the complete internal cables routing, In case of assembling on traditional frameset, cables the frame and the fork have to be compatible. - Page 10 Shifter/Brake lever Installation Carefully observe the bolt's length before attempting to tighten. Use torque wrench to tighten the bolt around 6-8Nm Di2 11-Speed cable routing diagram Route the cable in to Shifter Angle Adjustment the Junction Box. Follow line marks on both side of the bar to level left and right shifter.
- Page 11 GoPro style accessory mount Rubber Strap for Lights Computer heads Light Mount Computer Holder Main Arm Installation Guide Fixing Bolts group Main Arm Fixing Bolt Spacers Integrated Handlebar Computer Holder GIANT GARMIN BRYTON Fixing bolt 0.8Nm WAHOO Main Arm Fixing Bolt Spacers Computer Holder Main Arm GoPro style accessory mount Fixing Bolt...
- Page 12 Installation Guide Integrated Handlebar Computer Holder Fixing Bolt Light Mount Rubber Strap for Lights Integrated Handlebar Computer Holder Installation Guide...
- Page 13 FRAMESET USER MANUAL...
