Contents: Main Box
(Box Dims DX4800: 32.5"x32.5"x12")
(Box Dims DX6800: 37"x35.5"x13")
Components Main Box Qty Components Main Box Qty
Hardware Packets
Assembly Manual
Owners Manual
Top Cover Lid
Motor
Motor Bracket Arms
Pump
Propeller
Propeller Ring
Junction Box
Panel Cover
Diagonal Braces DX4800
Diagonal Braces DX6800
DAX Assembly Sheet 031023
A s s e m b l y I n s t r u c t i o n s
D X 4 8 0 0 , D X 6 8 0 0
Box 1 of 2
6
Top Cover Diag. Braces
1
Side Discharge Venturi
1
Float Valve Assembly
1
Pump Hose
1
Corner Columns
4
Water Tank
1
Top Cover
1
Overflow Tube & Nut
1
Drain Plug
1
Water Diverter (attached)
1
Water Distributor
2
Water Distribution Tubes
4
H e s s a i r e R o o f t o p
E v a p o r a t i v e C o o l e r s
(Box Dims DX4800: 26.5"x20.5"x11")
Components Media Box
2
1
1
1
2
1
1
1
1
3
1
3
Box 2 of 2
Contents: Media Panel Box
(Box Dims DX6800: 30.5"x26"x12")
Media Side Panels
Qty
3
