Goalzero ROCKOUT 2 Manual

INSIDE
ROCKOUT
PORTABLE SPEAKER
®
Get to Know Your Gear
Getting Started
1. Be sure to ACTIVATE YOUR WARRANTY at www.GOALZERO.com/warranty
2. Connect the ROCKOUT 2 to your audio player with the audio input cord.
3. Turn it on to start playing.
4. Control your device with external audio controls.*
5. Charge through any USB power source with attached cords.
*External audio controls optimized to work with Apple(R) and Windows (R) products and works on most Android(R) devices.
Die Cut Line:
Mountain Fold:
Valley Fold:
How to Use
Audio Input Cord
Plug your audio device into the built-in 3.5mm audio input.
Audio Controls and Power Button
Press the
HANG IT
indicates charging.
Use the bungee harness to attach
the speaker to your pack or ride.
USB Charging Cord
PROTECT IT
Charge directly from any USB source with attached cord.
Audio device fits neatly inside the
internal pocket.
Chaining Port
ROCK IT
Chain together additional ROCKOUT speakers through this port.
Advanced DarkBass™ Technology delivers
precise, high-quality sound every time.
CONNECT IT
Input cord works with any
standard headphone jack.
CHAIN IT
Chain multiple speakers together
for even more boom.
CHARGE IT
Juice up directly from any USB source
with the attached power cord.
* Battery Saving Auto-Off Feature
ROCKOUT 2 will shut off after 20 minutes of inactivity to save
battery.
Technical Specs
Usage
Run time
Charge time
to turn on. Blue light indicates power on. Red light
Outputs
Audio output port
Audio
Speakers
Driver
Power
Battery
General
Weight
Dimensions
Warranty
Certifications
Optimal operating temp. 32-104ºF (0-40ºC)
Other
Input
Charging
Attached Cords
Attached USB Charging Cable
Attached Audio Input Cord
20+ hours
2 hours
3.5mm female audio jack, line-level (chaining)
2x 3W Stereo
100Hz-20kHz
Lithium-ion, 3.7V, 800 mAh, 3Wh
12.2 oz (346 g)
7 x 3.75 x 2.5 in (17.9 x 9.5 x 6.4 cm)
12 months
CE and FCC
3.5mm audio jack, line-level
USB Cord, 5V
