INSTRUCTION MANUAL
MONTAGUE
Heavy Duty Underfired
Gas Broilers
RADIANT MODELS:
Range Match: UF (24R, 30R, 36R, 48R, 60R, 72R)
Freestanding: UFS (24R, 30R, 36R, 48R, 60R, 72R)
Low-Profile Counter: UFLC (18R, 24R, 30R, 36R, 48R, 60R, 72R)
Modular: UFSM (24R, 30R, 36R, 48R, 60R, 72R)
Counter: UFSC (24R, 30R, 36R, 48R, 60R, 72R)
Shallow Counter: UFLCS (18R, 24R, 30R, 36R, 48R, 60R, 72R)
These instructions should be read thoroughly before attempting installation.
Set up and installation should be performed by qualified installation personnel.
Keep area around appliances free and clear from combustibles.
PLEASE RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
THE MONTAGUE COMPANY
1830 Stearman Avenue
P.O. BOX 4954
Hayward, CA 94540-4954
TEL: (510) 785-8822 FAX: (510) 785-3342
Advertisement
Table of Contents
Summary of Contents for MONTAGUE LEGEND UF24R
- Page 1 INSTRUCTION MANUAL MONTAGUE Heavy Duty Underfired Gas Broilers RADIANT MODELS: Range Match: UF (24R, 30R, 36R, 48R, 60R, 72R) Freestanding: UFS (24R, 30R, 36R, 48R, 60R, 72R) Low-Profile Counter: UFLC (18R, 24R, 30R, 36R, 48R, 60R, 72R) Modular: UFSM (24R, 30R, 36R, 48R, 60R, 72R) Counter: UFSC (24R, 30R, 36R, 48R, 60R, 72R) Shallow Counter: UFLCS (18R, 24R, 30R, 36R, 48R, 60R, 72R) These instructions should be read thoroughly before attempting installation.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important (Cautions and Warnings) ............Page 1 Installation ....................Page 2 - 5 Operation ...................... Page 6 Maintenance ....................Page 7 - 9 Maintenance Schedule ................Page 10 Service ......................Page 11 Orifice Size Chart - Drill Size ............... Page 12 UF Exploded View .................. -
Page 3: Important (Cautions And Warnings)
IMPORTANT FOR YOUR SAFETY WARNING IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ THE OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. WARNING DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS AND LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. -
Page 4: Installation
INSTALLATION The Montague gas broilers are produced with Provisions must be made for adequate air the best possible materials and workmanship. supply to the unit. Proper installation is essential for safe and VENTILATING HOOD efficient trouble-free operation. The broiler must be installed under a properly NOTE: installation instructions... - Page 5 INSTALLATION CLEARANCES Models Noncombustible Construction UF, UFS, UFSC & UFSM Back 0” Left & Right Side 0” UFLC Back 0” Left & Right Side 0“ WARNING: FOR USE IN NON-COMBUSTIBLE LOCATIONS ONLY. CAUTION threaded receptacle is located on each corner (and in the middle of units larger DO NOT OBSTRUCT THE FLOW OF than 36”) of the base of the unit.
- Page 6 INSTALLATION gas on rating plate. CURB INSTALLATION Place shim under the low side. This operation 1. 1-1/4” Front Manifold is important since variations in floors and The gas manifold of this appliance or of the curbs are common. Unless units are level, battery which it is a part must be connected to difficulty will be encountered in aligning the a gas appliance pressure regulator adjusted...
- Page 7 INSTALLATION the pressure marked on the rating plate — 4. To shutdown, turn pilot valve clockwise 6.0” WC for natural and 10.0” WC for until tight. propane gas. 5. Do not attempt to relight for 5 minutes after 4. Turn off all burner valves. shutdown.
-
Page 8: Operation
OPERATION HEATING exhibit characteristics that chefs require to Be sure all standing pilots are lit. Turn on the achieve high production broiling perfection. number of burners desired, to the full “ON” High Heat Capacity position. After 20 minutes, the flame can be turned back if less heat is desired. -
Page 9: Maintenance
MAINTENANCE water. Dry thoroughly with a clean lint-free GENERAL CLEANING cloth. Drying thoroughly will prevent water The complete broiler should be given a spots which are harmful to the finish. periodic cleaning. Lint and grease suspended in the air tend to collect in air passages. CAUTION Exterior NEVER... - Page 10 MAINTENANCE Sharp knives or choppers usually have Radiants hard carbon steel edges and will leave Stainless steel radiants require only their mark on stainless surfaces. occasional cleaning since most food particles With only a little care, your stainless steel don’t stick to their surface.
- Page 11 MAINTENANCE Radiant Reflectors The radiant reflectors located beneath the burners in UFLC models should be removed weekly and scrubbed to remove grease and debris. Dry thoroughly before reinstalling. WARNING COVERING THE GRATES AND BURNER BOX FOR “BURN OFF” CLEANING WILL CAUSE PREMATURE COMPONENT...
-
Page 12: Maintenance Schedule
MAINTENANCE SCHEDULE Product Maintenance Schedule Components May June July Aug Sept Pilots Burner Burner Valve Regulator Top Grids* Grid Frame Radiant Reflector Radiant Grease Container* Debris Screen* (1) Inspect (2) Clean (3) Adjust (4) Replace (As Needed) (5) Lubricate NOTE: Lack of maintenance may result in pre-mature failure of components. NOTE: Parts marked with * should be cleaned daily. -
Page 13: Service
SERVICE When service is needed, contact a local leaks. The valve should be turned on and off service company, dealer, or the factory to several times to seat correctly. perform mechanical maintenance and repairs. BURNER BOX These instructions are intended for use by competent service personnel. -
Page 14: Orifice Size Chart - Drill Size
ORIFICE SIZE CHART - DRILL SIZE NOTE: Orifice size may vary depending on country of destination and/or elevation. UF & UFS Nat. 6.0 W.C. (14.94 mbar) Orifice #48 Part Number 6381-9 LP 10.0 W.C. (24.90 mbar) Orifice #55 Part Number 2138-5 UFLC Nat. -
Page 15: Uf Exploded View
EXPLODED VIEW... -
Page 16: Exploded View Parts List
UF & UFS (RADIANT) EXPLODED VIEW PARTS LIST ITEM # DESCRIPTION 24” UNIT 30” UNIT 36” UNIT CABINET BASE 6137-9 6137-9 6137-9 BRKT, VALVE LEG W/ FOOT 28441-6 28441-6 28441-6 19413-1 19413-1 19413-1 TRIM ASSY, TOP LT (SS) 19412-3 19412-3 19412-3 TRIM ASSY, TOP RT (SS) TRIM REAR, TOP (SS) - Page 17 UF & UFS (RADIANT) EXPLODED VIEW PARTS LIST ITEM # DESCRIPTION 24” UNIT 30” UNIT 36” UNIT KNOB, BLACK OVAL 22269-0 22269-0 22269-0 1279-3 1279-3 1279-3 PLUG, PIPE (BR) 20535-4 20535-4 20535-4 LIGHTER, PILOT VALVE, PILOT 1055-3 1055-3 1055-3 25549-1 25549-1 25549-1 VALVE ASSY, BURNER (NAT)
-
Page 19: Uflc Exploded View Parts List
UFLC EXPLODED VIEW PARTS LIST 18” 24” 30” 36” ITEM # DESCRIPTION UNIT UNIT UNIT UNIT 44364-6 21756-5 21753-0 21507-4 TRIM, TOP-REAR (SS) 21085-4 21085-4 21085-4 21085-4 TRIM, TOP-LEFT (SS) 21086-2 21086-2 21086-2 21086-2 TRIM, TOP-RIGHT (SS) 44352-2 20248-7 20363-7 20010-7 RAIL, GUARD ASSY. - Page 20 UFLC EXPLODED VIEW PARTS LIST 18” 24” 30” 36” ITEM # DESCRIPTION UNIT UNIT UNIT UNIT GRID FRAME ASSY. 44341-7 21993-2 21992-4 21408-6 19692-4 19692-4 19692-4 19692-4 GRID, TOP GRID, TOP (NARROW) 9347-5 9347-5 9347-5 9347-5 24579-8 21710-7 21711-5 21502-3 OUTER PANEL, BACK NOTE: Part numbers provided are for 18”...
- Page 21 WARNING If not installed, operated and maintained in accordance with the manufacturer's instructions, this product could expose you to substances in fuel or in fuel combustion which can cause death or serious illness and which are known to the State of California to cause cancer, birth defects or other reproductive harm.
- Page 22 When ordering parts, to eliminate mistakes and facilitate deliver, always give the following information: Serial No. ___________________________________________ Model No. ___________________________________________ Change No. _________________________________________ Name and Number of Part Model No. Change No. Serial No. The Montague Company 1830 Stearman Avenue P.O.
