CMT-BX1/BX3/BX5BT
SERVICE MANUAL
Ver. 1.2 2007.08
• CMT-BX1/BX3/BX5BT are composed of following models.
As service manuals are issued for each component model,
please refer to them.
COMPONENT MODEL NAME
CMT-BX1
Compact Disc Receiver
HCD-CBX1
Speaker System
SS-CBX1
SPECIFICATIONS
Power requirements
120 V AC, 60 Hz (BX1/BX3: Canadian model/BX5BT)
230 V AC, 50/60 Hz (BX3: European model)
230 − 240 V AC, 50/60 Hz (BX3: Australian model)
220 V AC, 60 Hz (BX3: Korean model)
120 V AC, 50/60 Hz (BX3: Taiwan model)
120 V 220 V 230 − 240 V AC, 50/60 Hz adjustable with
voltage selector (BX3: Other models)
Power consumption:
40 watts (BX5BT/BX1)
65 watts (BX3)
Dimensions (w/h/d) (excl. speakers):
Approx. 200 × 132 × 298 mm
Mass (excl. speakers):
CMT-BX1: 3.4 kg
CMT-BX3: 3.7 kg
CMT-BX5BT: 3.5 kg
Supplied accessories: Remote Commander
(1), R6 (Size AA) batteries (2), AM loop
antenna (1), FM lead antenna (1)
Design and specifications are subject to
change without notice.
Sony Corporation
9-887-615-03
Personal Audio Division
2007H05-1
Published by Sony Techno Create Corporation
© 2007.08
CMT-BX3
CMT-BX5BT
HCD-CBX3
HCD-BX5BT
SS-CBX3
SS-CBX5
ACCESSORIES
Part No.
1-754-102-31 ANTENNA, LOOP (LW.MW) (AM loop antenna)
1-754-243-11 ANTENNA (FM lead antenna)
2-055-382-01 LID, BATTERY CASE (for RM-SC31/SCU37)
3-095-504-12 MANUAL, INSTRUCTION (ENGLISH) (BX1)
3-095-504-21 MANUAL, INSTRUCTION (ENGLISH)
3-095-504-31 MANUAL, INSTRUCTION (FRENCH) (BX3: CND, AEP, SP)
3-095-504-41 MANUAL, INSTRUCTION (SPANISH) (BX3: AEP, SP)
3-095-504-51 MANUAL, INSTRUCTION (GERMAN, DUTCH, ITALIAN)
3-095-504-61 MANUAL, INSTRUCTION (SWEDISH, POLISH) (BX3: AEP)
3-095-504-72 MANUAL, INSTRUCTION (TRADITIONAL CHINESE)
3-095-504-81 MANUAL, INSTRUCTION (KOREAN) (BX3: KR)
3-095-507-12 MANUAL, INSTRUCTION (ENGLISH) (BX5BT)
3-095-507-21 MANUAL, INSTRUCTION (FRENCH) (BX5BT: CND)
A-1237-274-A RM-SC31 (Remote Commander)
A-1237-275-A RM-SCU37 (Remote Commander)
• Abbreviation
MICRO HI-FI COMPONENT SYSTEM
Canadian Model
Australian model
Description
(including battery case lid) (BX1/BX5BT)
AUS : Australian model
CND : Canadian model
KR : Korean model
SP
: Singapore model
TW : Taiwan model
US Model
CMT-BX1/BX5BT
CMT-BX3/BX5BT
AEP Model
UK Model
E Model
CMT-BX3
Remark
(BX3: CND, AEP, UK, SP, TW, AUS)
(BX3: AEP)
(BX3: SP, TW)
(including battery case lid) (BX3)
