Samuel Heath V740-A Product Data Sheet

Exposed 1/2" thermostatic shower valve
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product Data Sheet
V740-A Exposed 1/2" Thermostatic Shower Valve
V721-XK
V721-LK

- Available Handle Options -

V721-XF
V721-LF
*Levers/Cross Tops sold separately

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V740-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samuel Heath V740-A

Summary of Contents for Samuel Heath V740-A

  • Page 1 Product Data Sheet V740-A Exposed 1/2" Thermostatic Shower Valve *Levers/Cross Tops sold separately - Available Handle Options - V721-XK V721-XF V721-LK V721-LF...
  • Page 2 Dimension Key V740K-A V740F-A...
  • Page 3 Flow Rates The flow rate data provided in this document is indicative of each product and is given in an open outlet condition. Installation design, external connections and fittings not supplied may affect the data provided.
  • Page 4 Spares Information V740-A Item Part No. Description Item Part No. Description Screw Wall Plug Washer Set Screw Valve Stem Check Valve Valve Cap Circlip Cartridge (VS56064) Elbow Escutcheon Shower Body Elbow O-ring Rubber Washer Direct Coupler Filter O-ring Screw O-ring...
  • Page 5 Installation 1. Install the pipe work (X) to suit the dimensional drawings in the front of this booklet. 2. Secure escutcheon (A) to the wall using screws (B), ensuring it is central to the pipe work (X). 3. Screw elbows (C) onto the pipe work (X), captivating escutcheons (D).
  • Page 6 Installation 4. Position the elbows (C) so that they are in line as shown. 5. Push the dual control valve (E) over the chassis (A) and secure with set screws (F). 6. Screw the captive nuts (G) onto elbows (C) ensuring the rubber washer (H) is captivated.
  • Page 7 Control Assembly Instructions 1. Screw handle (A) onto spindle (B) using screw (C) and washer (D). 2. Push indice (E) into the handle option (A) to conceal the fixing. 3. The octagonal nut (F) can be rotated to the desired angle. Note: The taper on the spindle (B) will lock in to the female taper in the handle option (A).
  • Page 8 5. Ceramic cartridges in hard water areas. To prolong the lifespan and reduce servicing periods of your Samuel Heath tap we recom- mend that a suitable water softener be fitted. Consult your installer/designer for details.

This manual is also suitable for:

V721-xkV721-lkV721-xfV721-lfV740k-aV740f-a
