Operating Manual
SHOCK DISCHARGE GENERATOR
SWG 505
Produktbild wie in den Prospekten ohne Rahmen
Ansprechpartner Frau Badziura
Mess- und Ortungstechnik
Measuring and Locating Technologies
Elektrizitätsnetze
Power Networks
Kommunikationsnetze
Communication Networks
Rohrleitungsnetze
Water Networks
Leitungsortung
Line Locating
Date of release: September 1999 – EN
128312846

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWG 505 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for sebaKMT SWG 505

  • Page 1 Operating Manual SHOCK DISCHARGE GENERATOR Produktbild wie in den Prospekten ohne Rahmen SWG 505 Ansprechpartner Frau Badziura Mess- und Ortungstechnik Measuring and Locating Technologies Elektrizitätsnetze Power Networks Kommunikationsnetze Communication Networks Rohrleitungsnetze Water Networks Leitungsortung Line Locating Date of release: September 1999 – EN...
  • Page 2 SWG 505 man_swg505_en_01-4.doc...
  • Page 3 SWG 505 Quality System Certificate   The quality management system of Seba Dynatronic and sebatel fulfils the stringent requirements of the international quality standard DIN ISO 9001 and of the European standard EN 29001. The German Association for the Certification of Quality Systems has awarded us the Quality System Certificates EN 19677 and DQS 19677-01.
  • Page 4 SWG 505 man_swg505_en_01-4.doc...
  • Page 5: Table Of Contents

    SWG 505 Contents Description General Technical data Design Current supply Putting into operation Safety Earthing of the instrument Connection to the faulty cable Isolation of open cable ends Selection of the surge voltage Safety terms as per VDE 0104 2.6.1 Ready for mains connection 2.6.2...
  • Page 6 SWG 505 man_swg505_en_01-4.doc...
  • Page 7: Description

    FLE 66 or FLE 90 Q and then indicated acoustically and/or optically. IMPORTANT: The SWG 505 is a high voltage instrument. Hence, the safety precautions have imperatively to be observed. These can be found under paragraph 3.1. on page 5.
  • Page 8: Design

    Current supply The SWG 505 is operated from a 220 V AC mains with a frequency of 45 to 60 Hz. For 240 V operation, an internal voltage matching for the mains supply of the control unit has been provided.
  • Page 9: Putting Into Operation

    SWG 505 Putting into operation Safety The shock discharge generator SWG 505 releases dangerous contact voltages. Hence the instrument must be operated by specialists or personnel who have been trained or instructed in the use of the instrument. The following safety precautions should be adhered to Para.
  • Page 10: Connection To The Faulty Cable

    SWG 505 Connection to the faulty cable The plug of the high voltage lead is connected to the high voltage socket (13) and is secured by means of the fixing screw. Now a micro contact inside the instrument closes and renders the Instrument ready for connection of a mains supply.
  • Page 11: Selection Of The Surge Voltage

    SWG 505 Selection of the surge voltage The selection of the surge voltage mainly depends an the test voltage of the faulty cable and the installations. A reduction in surge voltage also reduces the output which is due to the fact that the output is governed by the square of the voltage.
  • Page 12: Mains Connection

    SWG 505 Mains connection The earthed power supply lead is connected to socket (12). The mains voltage should be 220 - 240 V. A mains frequency of 45 - 60 Hz is permissible. Setting the surge voltage and output The desired surge voltage is selected by means of rotary...
  • Page 13: Setting The Impulse Sequence

    SWG 505 2.10 Setting the impulse sequence Rotary control (9) is combined with a rotary switch. When the rotary control is turned fully to the left, the automatic impulse sequence is switched off (single-shot pulse). If the rotary control is turned to the right (clockwise), then the Impulse sequence can be continuously selected after the switching threshold has been passed.
  • Page 15: Switching Off

    SWG 505 Switching Off After completion of the test, the instrument is switched off by operating the luminous pushbutton (5), whereby both the control unit and the high voltage generation are switched off. Simultaneously, the instrument and the connected cable are automatically discharged.
  • Page 16 SWG 505 man_swg505_en_01-4.doc...
  • Page 17: Description Of The Operating And Connecting Panel

    SWG 505 Description of the operating and connecting panel Figure 1 : Operating and connecting panel man_swg505_en_01-4.doc...
  • Page 18 SWG 505 1 kV-meter : 0 - 6 kV 2 Microfuse/Mains circuit : F3 (T 2 / 250 D) 3 Microfuse/Mains circuit : F1 (T 2 / 250 D) 4 Microfuse/Control circuit : F2 (M 0.5 / 250 D) 5 Luminous pushbutton : when operated: "OFF"...
  • Page 19 SWG 505 man_swg505_en_01-4.doc...
  • Page 21 SWG 505 COPYRIGHT NOTICE The information contained in this document is for informational purposes only  and is subject to change without notice. Seba Dynatronic makes no warranty of any kind with regard to the information contained in this manual, including but not limited to the implied warranties of merchantability and fitness for a particular ...
