19" RACK MOUNT INDUSTRIAL MONITOR
USER MANUAL
Model: HRM819TR
i-Tech Company LLC
TOLL FREE: (888) 483-2418
email:
info@itechlcd.com
web:
www.iTechLCD.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HRM819TR and is the answer not in the manual?

Questions and answers

Summary of Contents for I-Tech HRM819TR

  • Page 1 19” RACK MOUNT INDUSTRIAL MONITOR USER MANUAL Model: HRM819TR i-Tech Company LLC TOLL FREE: (888) 483-2418 email: info@itechlcd.com web: www.iTechLCD.com...
  • Page 2: Table Of Contents

    Table of Contents Safety and Regulatory Information ................... FCC Notice ............................Waste Electrical and Electronic Equipment Directive (WEEE) .............. Mechanical Drawings ....................... Front View ............................Bottom View ............................Side View .............................. Installation Instructions ....................Step 1: Prepare for Installation ......................Step 2: Bench-test Confguration ......................
  • Page 3: Safety And Regulatory Information

    Safety and Regulatory Information Safety and Regulatory Information WARNING! To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualifed personnel only.
  • Page 4: Waste Electrical And Electronic Equipment Directive (Weee)

    Safety and Regulatory Information Waste Electrical and Electronic Equipment Directive (WEEE) The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.
  • Page 5: Mechanical Drawings

    Mechanical Drawings Mechanical Drawings Front View Bottom View...
  • Page 6: Side View

    Mechanical Drawings Side View...
  • Page 7: Installation Instructions

    3. Ensure that the air temperature around the unit (top and bottom) will not exceed the rated specifcations of the unit. The maximum rated temperature for the HRM819TR is 50°C (122°F). ► Remember that heat rises - the temperature at the top of the...
  • Page 8: Step 2: Bench-Test Confguration

    (if applicable) to your monitor. Video Connection The HRM819TR supports analog and digital video. Analog Video Connection Connect one end of the VGA video cable to the HD-15 input port on the rear of the monitor.
  • Page 9: Install Touchscreen Driver

    Connect the other end to the digital video output port on the host computer. Power Connection The HRM819TR is powered by 120/240 VAC, 1.5/0.75 A, 60/50 Connect the AC power cable to the power input port on the rear of the monitor.
  • Page 10 Installation Instructions Select the appropriate driver for your operating system. If downloading from the web address listed above, select the appropriate driver for your operating system. If using the included CD, insert it into the host computer's CD-ROM drive. the CD does not automatically run, browse the contents of the CD and open the ReadMe.htm fle in a web browser.
  • Page 11: Step 3: Install Into Rack

    Our monitors will ft in type A, B, and C racks with a width of 482.6 mm (19") (preferred EIA rack width). WARNING! i-Tech will not assume liability for damage to internal electronics due to improper installation. Contact HIS if you need additional assistance.
  • Page 12: Video Settings

    Video Settings Video Settings Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (e.g.
  • Page 13: Control Panel Buttons

    Video Settings Control Panel Buttons Use the control panel buttons located on the back of the monitor to display and adjust various settings on the On-Screen Display (OSD) menu. 1. To display the Main Menu, press button [1]. NOTE: All OSD menus and adjustments screens disappear automatically after seconds.
  • Page 14: Osd And Power Lock Settings

    Video Settings OSD and Power Lock Settings ► OSD Lock: Press and hold [1] and the up [▲] button for 10 seconds. If any buttons are pressed the message OSD Locked will display for 3 seconds. ► OSD Unlock: Press and hold [1] and the up [▲] button again for 10 seconds.
  • Page 15: On-Screen Display (Osd) Menus

    Video Settings On-Screen Display (OSD) Menus To open the OSD menu, press button [1] once. The following screen will appear: Main Menu Description Auto Image Adjust Automatically sizes, centers, and fne tunes the video signal to eliminate waviness and distortion. Contrast / Brightness Includes the Contrast and Brightness functions.
  • Page 16: Contrast/ Brightness Menu

    Video Settings Contrast/ Brightness Menu The Contrast/Brightness menu includes the Contrast and Brightness functions. Description Contrast / Brightness Menu Contrast • Adjusts the difference between the image background (black level) and the foreground (white level). • This feature may also be accessed by pressing the up [▲] button outside of the OSD menu.
  • Page 17: Information Menu

    Video Settings Color Adjust Menu Description sRGB This is quickly becoming the industry standard for color management, with support being included in many of the latest applications. Enabling this setting allows the LCD to more accurately display colors the way they were originally intended.
  • Page 18: Manual Image Adjust Menu

    Video Settings Manual Image Adjust Menu The Manual Image Adjust menu includes the H./V. Position, Horizontal Size, Fine Tune, Sharpness, Dynamic Contrast, and ECO Mode functions. Description Manual Image Adjust Menu Moves the screen image left or right and up or down.
  • Page 19: Setup Menu

    Video Settings Setup Menu The Setup menu includes the Language Select, Resolution Notice, OSD Position, OSD Time Out, OSD Background, and Auto Power Off functions. Setup Menu Description Language Select Allows the user to choose the language used in the menus and control screens.
  • Page 20: Cleaning Instructions

    Cleaning Instructions Cleaning Instructions CAUTION! DO NOT USE ABRASIVE MATERIALS, SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS, ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. IMPORTANT! Always spray the cleaner on the cloth or towel frst and then clean the monitor screen.
  • Page 21: Troubleshooting

    If this fixes the problem and allows the monitor to work properly, then the KVM extender is the source of the problem. Please refer to the troubleshooting section of the KVM extender manual or contact i-Tech for additional assistance. Symptom Causes Solutions...
  • Page 22 Troubleshooting Symptom Causes Solutions "Out of Range" The source signal exceeds the Adjust the computer settings to the message box and maximum resolution and/or monitor's native resolution: 1280 x 1024 @ 60 Hz no image on the refresh rate that the monitor screen can handle ( >...
  • Page 23: Touchscreen Troubleshooting

    Solutions No response Touchscreen driver has not Download and install the latest driver from when touching been installed. the i-Tech website. the touchscreen Touchscreen cable is not Make sure either the USB or Serial cable is plugged in correctly. securely connected to the monitor and Do not connect both.
  • Page 24: Specifcations

    Specifcations Specifcations Display Type Thin-flm transistor (TFT) Active Matrix Liquid Crystal Size 19" diagonal Image Size (W x H) 376 mm x 301 mm (14.8" x 11.9") Native Resolution SXGA (1280 x 1024, 5:4 aspect ratio) Minimum Resolution VGA (640 x 480) Pixel Pitch 0.294 mm x 0.294 mm Number of Colors...
  • Page 25: Video

    Specifcations Video Input Connectors HD-15, DVI-D NOTE: Optional BNC input using HD-15 to 5-wire BNC adapter; see "Input Signal Formats" for a list of compatible video signals. Input Signal Formats • RGB Analog video, 0.7/1.0 Vp-p, 75 Ohms Compatible sync modes: Separate H/V sync •...
  • Page 26: Rack Compatibility

    Specifcations Rack Compatibility EIA Standard EIA-310-D EIA Type Rack A, B, and C Rack Width 482.6 mm (19.0") (preferred EIA width) Mounting 8 Slots, 7.1 mm (0.28") wide 8U, 354.3 mm (13.95") Panel Height Physical Enclosure Type Rack mount Panel Rating Built to IP20 standards;...
