Installation Manual for PV Modules MPS---N-R
1. Introduction to user manual
This manual contains information about the installation and safe operation of the OZ
POWER PRODUCTS PTY LTD Modules (here in after referred to as modules). It contains
standard modules MPSxxxN-R, if new standard modules are added, they will be updated. OZ
POWER PRODUCTS PTY LTD is called " MaxPower Solar " for short. Failure to comply with
these safety guidelines may result in loss of life or damage to property.
Name of solar cell
166 solar cell
182 solar cell
Installers must read and understand this guide before installing. If you have any
questions, please contact our customer service department or our local representative for
more detailed information. The installer must comply with all safety precautions, local
requirements and requirements of the law or authorized agency as described in this guide.
Before installing the PV module, the installer shall be familiar with its mechanical and
electrical requirements. The operation of PV modules requires relevant professional
knowledge, and system installation and maintenance must be carried out by qualified
personnel with professional knowledge.
Please store this guide in a safe place for future reference (maintenance and upkeep)
and use when selling or handling modules. MAXPOWER SOLAR has passed the test of
global testing and certification authority. Please use it at ease, under the premise of following
the requirements of this manual.
The module installer must inform the end customer (or consumer) accordingly of the
above.
1.1
Disclaimer
MAXPOWER SOLAR reserves the right to change this installation manual without prior
notice. MAXPOWER SOLAR makes no warranties of any kind with respect to any express or
V1Mar 2023
Name of solar cell module
(xxx=350-390, in steps of 5)
MPSxxxN-R
Single glass full frame module
(xxx=440-470, in steps of 5)
MPSxxxN-R
glass full frame module
(xxx=395-435, in steps of 5)
MPSxxxN-R
Single glass full frame module
(xxx=525-580, in steps of 5)
MPSxxxN-R
Single glass full frame module
Single
www.maxpowersolar.com.au
1
Dimensions of module
(mm)
1756*1039*30/35/40
2095*1039*30/35/40
1722*1134*30/35/40
2278*1134*30/35/40
