WASHING MACHINE EVOGT 1206E2D
A
PROGRAMME SELECTOR
Use this control to select the desired wash programme. Turn the selector (it
can be turned in both directions) so that the programme is opposite the
reference indicator (p). The temperature selected will depend on the
programme. (See the Programme Table).
B
SPIN SPEED SELECTOR
1
B
DELAY START
2
C
COLD WASH
1
C
AQUAPLUS (SENSITIVE KEY)
2
G
DOOR LIGHT
H
START/PAUSE KEY
V
"DIGITAL" Display
The display's indicator system allows you to be constantly informed about the status of
p
CONTROL POSITION INDICATOR
"Gentle Touch Opening" is an innovative braking system enabling the washing machine to be loaded
safely and easily. Thanks to the two buffers at each end, the drum can be opened in 2 seconds by
lightly pressing the central key
H
B2
the machine
G
B1
V
C2
A
C1
p
Advertisement
Related Manuals for Candy EVOGT 1206E2D
Summary of Contents for Candy EVOGT 1206E2D
- Page 1 WASHING MACHINE EVOGT 1206E2D PROGRAMME SELECTOR Use this control to select the desired wash programme. Turn the selector (it can be turned in both directions) so that the programme is opposite the reference indicator (p). The temperature selected will depend on the programme.
- Page 2 Programme table mod EVOGT 1206E2D washing powder option keys max. load aprox. temp. spin max. time setting speed load programme programme for min. ºC rpm/min Fast coloureds with prewash display 90º 1200 ...
- Page 3 PREPARING THE WASH CYCLE 1.- Once the washing is loaded, ensure that the drum doors are properly closed.. 2.- Add detergent and additives, not exceeding the maximum level indicator. detergent for pre-wash I detergent for wash programme II ...
- Page 4 cycle duration (V) When a programme is selected the display automatically shows the cycle duration, which can vary, depending on the options selected. Once the programme has started you will be kept informed constantly of the time remaining to the end of the wash.
