Summary of Contents for Subject Link RPT-2010G-2F-X4 Series
- Page 1 RPT-2010G-2F-X4 Series Hardware User Manual www.sbjlink.com sales@sbjlink.com...
- Page 2 Subject Link Inc. may make improvements and/or changes to the product and/or specifications of the product described in this manual, without prior notice. Subject Link Inc. will not be liable for any technical inaccuracies or typographical errors found in this guide. Changes are periodically made to the information contained herein and will be incorporated into later versions of the manual.
- Page 3 FCC Notice This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy.
-
Page 4: Table Of Contents
Contents Overview ......................... 1 Software Features ....................1 Hardware Features ....................1 Package Contents ..................... 2 Safety Precaution ..................... 2 Hardware Description ..................... 4 Physical Dimensions ....................4 Front Panel ....................... 5 Top View........................5 LED Indicators ......................6 Ethernet Ports ......................7 Cabling ........................ -
Page 5: Overview
Overview This series is rated IP30 and installation by DIN Rail. Each unit of this industrial gigabit managed Ethernet switch series has 8* 10/100/1000TX Gigabit Ethernet ports and 2 dual-rate (100/1000) SFP slots, suitable for applications that require high bandwidth and long distance communication. In order to prevent unregulated voltage, this series provides high EFT and ESD protection. -
Page 6: Package Contents
• 8K MAC Address Table • Supports 12.2Kbytes Jumbo Frame • 4Mbits memory buffer Power Input ● Redundant power DC 12~48V with connective 1*6-pin removable terminal block ● Max. current 3.5A ● Relay Contact: 24 VDC, 1A resistive ● The power input specification is complied with the requirements of SELV (Safety Extra Low Voltage), and the power supply should be complied with UL 61010-1 &... - Page 7 Figure 1.1: Caution Label This warning label is on the device, and means that the surface of the device is hot. (Shown in Figure 1.2) Figure 1.2: Hot Surface Warning Label...
-
Page 8: Hardware Description
Hardware Description Physical Dimensions Figure 2.1, below, shows the physical dimensions of RPT-2010G-2F-X4 series: 10-port industrial gigabit managed Ethernet switch with 8*10/100/1000Tx Gigabit Ethernet, and 2*100/1000 SFP slots. (W x D x H) is 54mm x 99mm x 142mm Figure 2.1: RPT-2010G-2F-X4 Series Physical Dimensions... -
Page 9: Front Panel
Figure 2.2: The Front Panel of RPT-2010G-2F-X4 Series Top View Figure 2.3, below, shows the top panel of the RPT-2010G-2F-X4 series switch that is equipped with one 6-pin removal terminal block connector for dual DC power inputs (12~48VDC). Figure 2.3: Top Panel View of RPT-2010G-2F-X4 Series... -
Page 10: Led Indicators
Green Connected to network, 1000Mbps Flashing Networking is active (LAN Port 1-8) Not connected to network Green Connected to network, 10/100Mbps 10/100 Flashing Networking is active (LAN Port 1-8) Not connected to network Table 2.4: LED Indictors for RPT-2010G-2F-X4 Series... -
Page 11: Ethernet Ports
Ethernet Ports RJ-45 Ports (Auto MDI/MDIX) The RJ-45 ports are auto-sensing for 10Base-T, 100Base-TX or 1000Base-T devices connections. Auto MDI/MDIX means that the switch can connect to another switch or workstation without changing the straight-through or crossover cabling. See the figures as below for straight-through and crossover cabling schematics. -
Page 12: Cabling
Cabling Use the four twisted-pair, category 5e, or the above cabling for RJ-45 port connections. The cable between the switch and the link partner (switch, hub, workstation, etc.) must be less than 100 meters (328 ft.) long. The small form-factor pluggable (SFP) is a compact optical transceiver used in optical communications for both telecommunication and data communication applications. - Page 13 Step 2 Insert the fiber cable of the LC connector into the transceiver as shown below in Figure 2.9. Figure 2.9: LC Connector to the Transceiver To remove the LC connector from the transceiver, please follow the steps shown below: Step 1 Press the upper side of the LC connector from the transceiver and pull it out to release as shown below in Figure 2.4 Figure 2.4: Remove LC Connector...
-
Page 14: Wiring The Power Inputs
Wiring the Power Inputs Caution: Please follow the below steps to insert the power wire. Step 1 Insert the positive and negative wires into the PWR1 (V1+, V1-) and PWR2 (V2+, V2-) contacts on the terminal block connector as shown below in Figure 2.6. Figure 2.6: Power Terminal Block Step 2 Tighten the wire-clamp screws to prevent the wires from loosening, as shown below in Figure 2.7. -
Page 15: Wiring The Fault Alarm Contact
Wiring the Fault Alarm Contact The fault alarm contact is in the middle of the terminal block connector as the picture shows below in Figure 2.8. By inserting the wires, it will detect the fault status including power failure or port link failure (managed industrial switch only) and form a normally open circuit. An application example for the fault alarm contact is shown below in Figure 2.8. -
Page 16: Mounting Installation
Mounting Installation DIN-Rail Mounting The DIN-Rail is pre-installed on the industrial Ethernet switch from the factory. If the DIN-Rail is not on the industrial Ethernet switch, please see Figure 3.1 to learn how to install the DIN-Rail on the switch. Figure 3.1: The Rear Side of the Switch and DIN-Rail Bracket Follow the steps below to learn how to hang the industrial Ethernet switch. - Page 17 Figure 3.2: Insert the Switch on the DIN-Rail Step 4 Lightly pull down the bracket on to the rail as shown below in Figure 3.3. Figure 3.3: Stable the Switch on DIN-Rail Step 5 Check if the bracket is mounted tightly on the rail. Step 6 To remove the industrial Ethernet switch from the rail, do the opposite from the above steps.
-
Page 18: Wall Mounting
Wall Mounting Follow the steps below to mount the industrial Ethernet switch using the wall mounting bracket as shown below in Figure 3.4. Caution: “Wall” means industrial control panel wall. Step 1 Remove the DIN-Rail bracket from the industrial Ethernet switch by loosening the screws. -
Page 19: Hardware Installation
Hardware Installation Installation Steps This section will explain how to install RPT-2010G-2F-X4 series: 10-port industrial gigabit managed Ethernet switch with 8*10/100/1000Tx Gigabit Ethernet, and 2*100/1000 SFP slots. Caution: This device is intended for use indoor and at altitudes up to 2000 meters. -
Page 20: Maintenance And Service
Maintenance and Service • If the device requires servicing of any kind, the user is required to disconnect and remove it from its mounting. The initial installation should be done in a way that makes this as convenient as possible. •... -
Page 21: Trouble Shooting
Trouble Shooting • Verify you have the right power cord or adapter. Never use a power supply or adapter with a non-compliant DC output voltage or it will burn the equipment. • Select the proper UTP or STP cable in order to construct the network. Use an unshielded twisted-pair (UTP) or shield twisted-pair (STP) cable for RJ-45 connections: 100Ω...
