Summary of Contents for Classen HTS-20HE
- Page 1 HYDRO OVERSEEDER MODELS: HTS-20HE Hydro Overseeder Honda GX270 PARTS MANUAL 4173364...
- Page 2 CALIFORNIA WARNING Proposition 65 Warning Diesel engine exhaust and some The engine exhaust from this product of its constituents are known to the contains chemicals known to the State State of California to cause cancer, of California to cause cancer, birth birth defects and other reproductive defects or other reproductive harm.
-
Page 3: Table Of Contents
Your safe use of this Classen product is one of our prime design objectives. Many safety features are built in, but we also rely on your good sense and care to achieve accident-free operation. -
Page 4: Safety
SAFETY HTS-20 This symbol means: NOTICE !!! ATTENTION! Unauthorized modifications may present extreme BECOME ALERT! safety hazards to operators and bystanders and could also result in product damage. Your safety and the safety of others is involved. Schiller Grounds Care, Inc. strongly warns against, Signal word definitions rejects and disclaims any modifications, add-on accessories or product alterations that are not... - Page 5 HTS-20 SAFETY OPERATOR PREPARATION & TRAINING SITE PREPARATION & CIRCUMSTANCES • Evaluate the terrain to determine how to safely READ THE OPERATION & SAFETY MANUAL perform the job. Only use accessories and attachments approved by the manufacturer. • If an operator or mechanic •...
- Page 6 HTS-20 SAFETY OPERATING SAFELY repairs made as needed before restarting; IN GENERAL - except for repairs or adjustments as specifically • Use extra care when loading or unloading the noted, such as for carburetor adjustment, where machine into a trailer or truck. the engine must be running.
- Page 7 SAFETY HTS-20 MAINTENANCE SAFETY FUEL SAFETY WARNING • Gasoline is flammable; gasoline IN GENERAL vapors are explosive. Use extra care • Maintain machine according to manufacturer's when handling. schedule and instructions for maximum safety and • Store only in containers specifically best results.
-
Page 8: Specifications
HTS-20 SPECIFICATIONS HTS-20 Dimensions: Width................31" (787 mm) Length................57" (1448 mm) Length (handle folded)...........46" (1168 mm) Height (transport)............45" (1143 mm) Height (handle folded).............33" (838 mm) Maximum gate Width............32" (813 mm) Net Weight: Weight...............300 lbs. (136 Kg) Removable weights................N/A Speed: Seed............Forward...3 mph (4.8 kph) ..............Reverse..1.5 mph(2.4 kph) Engine: Model HTS-20H... -
Page 9: Labels
LABELS HTS-20 WARNING LABELS Warning labels are an important part of the safety system incorporated in this machine. Replace labels if damaged or illegible 4173241 4168759... -
Page 10: Controls
CONTROLS HTS-20 CONTROLS THROTTLE (A) Controls engine speed and vacuum suction level. CHOKE (B) Move to the “CHOKE” position to apply the choke. Move to the “RUN” position to remove the choke. FUEL SHUT OFF (C) Move to the “OFF” position to shut off the fuel whenever transporting the machine by trailer or truck or during storage. -
Page 11: Operation
OPERATION HTS-20 BEFORE STARTING THE ENGINE OPERATING THE SEEDER 1. Read the Operator Manual and Engine Manual. Be- 1. Release both right and left engagement arms to come familiar with the controls, how each functions, neutral position. and what it operates. 2. - Page 12 OPERATION HTS-20 SEEDING AND SLICING OPERATION 1. The seeding blades are used for cutting grooves for over-seeding and can also be used for verticutting grasses. To set the height properly, place unit on the lawn surface and adjust the wheel height up. Adjusting the wheel height up lowers the blades.
-
Page 13: Maintenance/ Storage
(for When replacement parts are required, use genuine example, a furnace or water heater pilot). Classen parts or parts with equivalent characteristics, including type, strength and material. Failure to do so Before the equipment is put into storage for any... -
Page 14: Troubleshooting
TROUBLESHOOTING HTS-20 TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Engine will not start. Out of gasoline. Fill gasoline tank. Spark plug lead wire loose or Reconnect spark plug lead wire. disconnected. Defective spark plug. Replace spark plug. Throttle control lever not in proper Move throttle control lever to start position. -
Page 15: Blade Assembly
BLADE ASSEMBLY HTS-20 SHAFT ASSEMBLY REPLACEMENT To replace the shaft assembly: 1. On right side of unit (from operator position) first remove the 2 bolts holding on the right shaft cover (C400455) and then remove cover. 2. Next remove bolts from both sides of bearing collar and loosen set screw. -
Page 16: Declaration Of Conformity
Station Road Industrial Estate Jim White Wombwell, Barnsley, South Yorkshire, S73 OBS UK Managing Director Date: 14th December, 2015 Declare that the machine described below: Make & Type………………………………………….Classen Seeder Category…………………………………………Turf Seeder Series…………………………………………….HTS-20HE Engine……………………………………………Honda GX270 Speed…………………………………………….3600 rpm Net installed power…………………………….. 8.5 HP (6.3 kW) Complies with the provisions of the following European directives and Amendments and the Regulations transposing it into national law. -
Page 18: Warranty
Effective April 1, 2007 For the period of two years from the date of purchase, CLASSEN will repair or replace for the original purchaser free of charge, any part or parts found upon the examination of our factory authorized service station, or by the factory in Southampton, PA to be defective in material or workmanship.
