- Page 1 Cardinal Health Brand Refrigerators and Freezers Installation and Operation Manual Explosion-Proof Flammable Material Storage General Purpose 20EFEECAA 20LREECAA 20FFEECAA 20EREECAA 20LFEECAA 20FREECAA 17LREECAA 18LCEECAA 326702H01 Rev C...
-
Page 2: Table Of Contents
Intended Use Statement .............................. 4 Explosion-Proof Refrigerators and Freezers........................ 5 Overview ..................................5 MODEL 20EREECAA ..............................6 MODEL 20EFEECAA ..............................6 Flammable Materials Storage Refrigerators and Freezers ..................7 Overview ..................................7 MODEL 20FREECAA ..............................8 MODEL 20FFEECAA ..............................8 General-Purpose Laboratory Refrigerators/Freezers .................... -
Page 3: Safety Information
Safety Information Thank you for selecting Cardinal Health products for your equipment needs. These instructions contain important operating and safety information. The user must carefully read and understand these instructions before using the unit. Your unit has been designed to optimize function, reliability, safety and ease of use. It is the user’s responsibility to install the unit in conformance with local electrical codes. -
Page 4: Intended Use Statement
Intended Use Statement The Refrigerators/Freezers described in this manual are for professional use only. These products are intended for use in research for the storage of samples or inventory in the following temperature ranges : Refrigerators +1°C to +12°C Freezers -12°C to -20°C Only Explosion Proof Units or Flammable Material Storage Units are to be used for the storage of flammable inventory/samples. -
Page 5: Explosion-Proof Refrigerators And Freezers
Explosion-Proof Refrigerators and Freezers Overview Conventional refrigerators and freezers are not suitable for storing flammable materials. Such units have components in their electrical and refrigeration systems that can trigger explosions of flammable air- vapor mixtures inside the unit and/or in the immediate surrounding area. -
Page 6: Model 20Ereecaa
XPLOSION ROOF NITS MODEL 20EREECAA MODEL 20EFEECAA 33" Wide, 33" Wide, Refrigerator Freezer Features: Features: • Overall 21 Cu. ft. • Overall 21 Cu. ft. • Four shelves (non-adjustable) • Four shelves (non-adjustable) • Manual defrost • Manual defrost •... -
Page 7: Flammable Materials Storage Refrigerators And Freezers
Flammable Materials Storage Refrigerators and Freezers Overview Conventional refrigerators and freezers are not suitable for storing flammable materials. Such units have components in their electrical and refrigeration systems that can trigger explosions of flammable air-vapor mixtures inside the unit. Flammable Materials Storage (FMS) refrigerators/freezers are designed for use in locations, which are not classified by the Authority Having Jurisdiction (AHJ) as hazardous. -
Page 8: Model 20Freecaa
LAMMABLE ATERIALS TORAGE NITS MODEL 20FFEECAA MODEL 20FREECAA 33" Wide, 33" Wide, Freezer Refrigerator Features: Features: • Overall 21 cu. ft. • Overall 21 cu. ft. • Four shelves (non-adjustable) • Four shelves (non-adjustable) • Manual defrost • Manual defrost •... -
Page 9: General-Purpose Laboratory Refrigerators/Freezers
General-Purpose Laboratory Refrigerators/Freezers Overview These are general-purpose units available in all refrigerator, freezer combination refrigerator/freezer models. These units intended for basic laboratory use only. Storage of high-value, life science materials or clinical biological materials may require alarm, monitoring, back-up and temperature performance features. -
Page 10: Model 20Lreecaa
ENERAL URPOSE ABORATORY EFRIGERATORS REEZERS MODEL 20LFEECAA MODEL 20LREECAA 32" Wide, 33" Wide, Freezer Refrigerator Features: Features: • • Overall 21 cu. ft. Overall 21 cu. ft. • Four shelves (non-adjustable) • Four shelves • Manual defrost (adjustable) • • HIPS Plastic interior HIPS Plastic interior •... -
Page 11: Model 17Lreecaa
ENERAL URPOSE ABORATORY EFRIGERATORS REEZERS MODEL 17LREECAA MODEL 18LCEECAA 28" Wide, 34" Wide, Refrigerator Refrigerator/Freezer Features: Overall 16.6 cu. ft. • Features: Overall 17.6 cu. ft. • • Plastic interior HIPS Plastic interior • • White color. • White color. 3 adjustable wire shelves. -
Page 12: Unpacking And Installation
Unpacking and Installation Shipping Carton This should be inspected upon delivery. When received, carefully examine for any shipping damage before unpacking. If damage is discovered, the delivering carrier should both specify and sign for the damage on your copy of the delivery receipt. Open the carton carefully making certain that all parts are accounted for before packaging materials are discarded. -
Page 13: Clearance
Clearance Position the unit so that there is at least 12” clearance on the top, 3” at the back, and 2” on each side. It is recommended that even more space be left at the back of the unit in case maintenance is required. -
Page 14: Installation
INSTALLATION Electrical Caution DO NOT REMOVE, under Flammable Material Storage and General Purpose units must circumstance, be connected to a grounded outlet matching the nameplate and/or the information furnished in this manual. If you are not grounding prongs from the 3- sure about the outlet, you should contact a qualified prong power cord supplied electrician for assistance. -
Page 15: How To Seal Killark® Box Conduit With Fiber And Sealing Compound To Help Protect Against Explosions (Explosion-Proof Units Only)
NSTALLATION How to Seal Killark® Box Conduit with Fiber and Sealing Compound to Help Protect Against Explosions (Explosion-Proof Units Only): The purpose of the procedure that follows is to build fiber rope dams on the left and right hubs of the horizontal conduit. The fiber rope dams will surround conduit wiring that is housed inside the horizontal conduit. - Page 16 NSTALLATION Note: wires must be kept separated as shown in the diagrams Figure 2: Horizontal Conduit, Cutaway • Insert fiber rope material down into horizontal conduit opening. Pressing down firmly, work the material into the left hub and—most importantly—being sure the material COMPLETELY SURROUNDS THE WIRING, from the top to the bottom, completely blocking this end of the horizontal conduit.
- Page 17 NSTALLATION • Pour sealing compound down in between the two fiber rope dams filling the remaining space. Pour slowly, being careful not to trap air bubbles. Immediately wipe off any spilled sealing compound. • Screw, conduit domed-cover back onto conduit opening. NOTE: INITIAL SETUP OF SEALING COMPOUND WILL OCCUR IN APPROXIMATELY 30 MINUTES HOWEVER, THE SEALING COMPOUND REQUIRES A MINIMUM OF 8 HOURS ABOVE 32ºF TO DEVELOP SUFFICIENT STRENGTH TO WITHSTAND EXPLOSIONS.
-
Page 18: Operation
Operation Environmental Operating Conditions POLLUTION DEGREE*: INSTALLATION CATEGORY*: 2000 Meters MSL (Mean Sea Level) ALTITUDE: 80% maximum, non-condensing HUMIDITY: 115V/60Hz ELECTRICAL SUPPLY: ±10% of normal rated line VOLTAGE TOLERANCE: TEMPERATURE: 15ºC to 32ºC PRODUCT USAGE: This product is intended for use indoors only *Refer to IEC 664-1 Start-Up Procedure Rotate the control knob clockwise to lower the temperature... - Page 19 - SHy Differential for auxiliary relay - ArP Probe for auxiliary relay Digital controller for medium temperature - Sdd Auxiliary output off during defrost refrigeration applications By means of these 5 parameters the functioning of the auxiliary relay can be set.. The differential is given by the SHy parameter.
- Page 20 6. MAIN FUNCTIONS REGULATION Hy Differential: (0,1 ÷ 25,5°C / 1÷255 °F) Intervention differential for set point. Compressor Cut IN is 6.1 TO SET THE CURRENT TIME AND DAY (ONLY FOR INSTRUMENTS Set Point + differential (Hy). Compressor Cut OUT is when the temperature reaches the set WITH RTC) point.
- Page 21 N.B. :To disable a defrost cycle set it to “nu”(not used). Ex. If Ld6=nu ; the sixth defrost cycle is disabled ALARMS OTHER ALP Probe selection for alarm: nP = no probe, the temperature alarms are disabled; P1 = Probe 1 (Thermostat probe);...
- Page 22 11. INSTALLATION AND MOUNTING Instrument XR35CX shall be mounted on vertical panel, in a 29x71 15. TECHNICAL DATA mm hole, and fixed using the special bracket supplied. Housing: self extinguishing ABS. The temperature range allowed for correct operation is 060 °C. Case: frontal 32x74 mm;...
- Page 23 Label Name Range Value Level ILE* Energy Saving cycle start during 0 ÷ 23h 50 min. 17. DEFAULT SETTING VALUES workdays dLE* Energy Saving cycle length during 0 ÷ 24h 00 min. Label Name Range Value Level workdays Set Set point LS÷US - - - ISE* Energy Saving cycle start on holidays...
-
Page 24: How To Save Energy
PERATION How to Save Energy • Be sure to follow location suggestions as mentioned in the previous INSTALLATION section. • Wipe moisture from glassware or other materials before placing them in a unit. • Don't overcrowd the unit. Too many items can increase electrical energy demand in order to keep everything cool. -
Page 25: Material Compatibility
PERATION Material Compatibility The interior cabinet of this unit is constructed of High impact polystyrene. Care must be exercised when determining which chemicals may be stored in the refrigerator and freezer sections and which type of storage materials should be employed. HIPS(High Impact Poly styrene) Plastic deteriorates when exposed to, but not limited to the following: Amines( Aromatic), Aldehydes ( Aromatic , Aliphatic),... -
Page 26: Troubleshooting
Troubleshooting In the event that your unit is not operating properly, check the following before calling for service assistance— this may save you the cost of unnecessary service calls. Symptom Possible Cause of Problem Make certain that the unit is connected to a grounded outlet. Unit not operating. -
Page 27: Maintenance
Maintenance Cleaning of Units • Disconnect power cord from its outlet. Note Make no attempt to service or repair • Set the temperature control to the OFF position. without consulting your dealer. After warranty period, such • The unit designs permit easy and rapid cleaning and consultation still advised,... -
Page 28: Manual Defrost Procedure
AINTENANCE Manual Defrost Procedure Caution Do not use any sharp instrument, blade or scraper to remove ice and frost refrigerator surfaces Use the following procedure to defrost manually: because of the very real danger of • Change the temperature control to the OFF puncturing the cooling coil. -
Page 29: Replacement Parts
Replacement Parts To obtain replacement parts information and pricing, please call Customer Service Department at 800-438-4851 and have the unit’s model, serial and code numbers available. This information is located on data plates on the rear of the unit or on the upper left side of the interiors. -
Page 30: Ordering Procedures
Ordering Procedures Please refer to the Specification Plate for the complete model number, serial number, and series number when requesting service, replacement parts or in any correspondence concerning this unit. All parts may be ordered from the dealer from whom you purchased this unit or can be obtained promptly from the factory. -
Page 31: 13 Month Limited Warranty
13 Month Limited Warranty This product is warranted to be free of defects in materials and workmanship for one (13) months from the first to occur of (i) the date the product is sold by the manufacturer or (ii) the date the product is purchased by the original retail customer (the “Commencement Date”). -
Page 32: Weee Compliance
WEEE Compliance Great Britain WEEE Compliance. This product is required to comply with the European Union’s Waste Electrical & Electronic Equipment (WEEE) Directive 2002/96EC. It is marked with the following symbol. Thermo Fisher Scientific has contracted with one or more recycling/disposal companies in each EU Member State, and this product should be disposed of or recycled through them.
