Summary of Contents for Illustra Pro PTZ
- Page 1 Quick Reference Guide Illustra Pro PTZ Breakout Box 8200-1199-06 A0...
- Page 2 Notice The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without notice. Copyright Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form, in whole or in part, without prior written consent of Tyco Security Products.
- Page 3 Table of Contents Illustra Pro PTZ Breakout Box To the Installer ............1 What’s in the box .
- Page 4 Table of Contents i-ii Quick Reference Guide...
- Page 5 Illustra Pro PTZ Breakout Box To the Installer This guide assumes that the Illustra Pro PTZ Outdoor Housing has been installed and that the required cables have been pulled to the site. What’s in the box Standard Items • Illustra Pro PTZ Breakout Box Assembly •...
- Page 6 Illustra Pro PTZ Breakout Box Mounting the Breakout Box The breakout box can be mounted either indoors or outdoors to any suitable vertical flat surface. Step Action Remove the cover from the box. Using the breakout box as a template, mark locations for the four mounting screws. As seen in the Figure 1.
- Page 7 Illustra Pro PTZ Breakout Box Wiring the Breakout Box This guide assumes that cables have been pulled to the site. Step Action For outdoor installations, remove the four watertight cord grip fittings and replace with appropriately rated 20mm conduit needed for outdoor use. Fit seals/glands in accordance with conduit manufacturer’s instructions.
- Page 8 Illustra Pro PTZ Breakout Box Specifications Mechanical Environment ...... Indoor / Outdoor Wall mounting options ..Concrete, wood, sheet rock Dimensions (H x W x D) ..175 x 125 x75mm (6.9 x 4.9 x 3 inches) Mounting area (H x W) ..281 x 200mm (11.1 x 7.9 inches) Weight .......
