KoamTac KBD401 User Manual

Usb bluetooth dongle
Hide thumbs Also See for KBD401:
Table of Contents

Advertisement

Quick Links

Download this manual
KBD401 USB
®
Bluetooth
Dongle
User Manual
Rev 1.0
December 2013
for Windows 7/8 OS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KBD401 and is the answer not in the manual?

Questions and answers

Related Manuals for KoamTac KBD401

Summary of Contents for KoamTac KBD401

  • Page 1 KBD401 USB ® Bluetooth Dongle User Manual Rev 1.0 December 2013 for Windows 7/8 OS...

  • Page 2: Table Of Contents

    KBD401 USB Bluetooth Dongle User Manual Table of Contents Knowing your USB Bluetooth dongle ........... 5 Package contents ........................5 System requirements ....................... 5 KBD401 Specifications Summary ..................... 6 Driver Installation ................. 7 Pairing with KDC as a Bluetooth device ........9 Find Bluetooth Serial Comport # ..........
  • Page 3 KBD401 USB Bluetooth Dongle User Manual Regulatory Compliance FCC ID : VH9KBD401 This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum 20cm between the radiator and your body. This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the FCC.
  • Page 4 KBD401 USB Bluetooth Dongle User Manual Warnings and Notes General warnings: If the equipment is used in a manner not specified in the equipment’s manual, the protection provided by the equipment could be impaired! Do not use the Bluetooth Dongle if any damage is present!

  • Page 5: Knowing Your Usb Bluetooth Dongle

     Installation CD (G version only) KBD401 USB Bluetooth Dongle 1.2 System requirements Before using your KBD401 USB Bluetooth dongle, ensure that your system meets the following requirements: Operating system: Microsoft Windows 7 / 8 System memory: 512MB or larger Hard drive free space: 10MB for device driver, 500MB for Bluesoleil Bluetooth software (G version only).

  • Page 6: Kbd401 Specifications Summary

    KBD401 USB Bluetooth Dongle User Manual 1.3 KBD401 Specifications Summary Chipset CSR8510 Bluetooth Standards Bluetooth 4.0 Class I Interface USB 2.0/1.1 Antenna Internal Chip Antenna Range 30 meters SPP, HID, (Optional PAN, FTP, SYNCH, OPP, BPP, Bluetooth Profile FAX, BIP, A2DP, HSP, PBA and MAP Via Bluesoleil) Radio Frequency 2.4 GHz - 2.4835 GHz...

  • Page 7: Driver Installation

    KBD401 USB Bluetooth Dongle User Manual 2. Driver Installation To install the Bluetooth driver to your computer. 1. Insert USB BT Dongle into your computer’s USB port. 2. Windows will install “Generic Bluetooth Radio” driver automatically. 3. Computer will display below message.
  • Page 8 KBD401 USB Bluetooth Dongle User Manual Copyright ® 2013, KoamTac, Inc.

  • Page 9: Pairing With Kdc As A Bluetooth Device

    KBD401 USB Bluetooth Dongle User Manual 3. Pairing with KDC as a Bluetooth device 1. Click Bluetooth icon on tray. 2. Click “Add a Device”. Copyright ® 2013, KoamTac, Inc.
  • Page 10 KBD401 USB Bluetooth Dongle User Manual 3. Select the Bluetooth device that you want to connect on the list. 4. Select “Next”. 5. Finish Add a Device. Copyright ® 2013, KoamTac, Inc.

  • Page 11: Find Bluetooth Serial Comport

    KBD401 USB Bluetooth Dongle User Manual 4. Find Bluetooth Serial Comport # 1. Go to Bluetooth device list via “Show Bluetooth Devices”. 2. Select Bluetooth device that is paired to find serial comport #. Copyright ® 2013, KoamTac, Inc.
  • Page 12 KBD401 USB Bluetooth Dongle User Manual 3. Right-click and select “Properties”. 4. Select Hardware tab. You can find Bluetooth device serial comport #. Copyright ® 2013, KoamTac, Inc.

  • Page 13: Using Kdc With Bluesoleil Through Kbd401G

    KBD401 USB Bluetooth Dongle User Manual 5. Using KDC with Bluesoleil through KBD401G KBD401G version supports various functions through Bluesoleil software such as transferring file to and from your mobile phone, printing a file using a Bluetooth printer (within range) without any cable connection, and using a Bluetooth wireless keyboard and mouse device with your computer and so on.
  • Page 14 KBD401 USB Bluetooth Dongle User Manual 3. Choose the setup language. 4. Follow the instructions on the screen. 5. Restart your computer. Note: If you do not restart, some operations may be abnormal. Copyright ® 2013, KoamTac, Inc.

  • Page 15: Uninstalling Bluesoleil

    KBD401 USB Bluetooth Dongle User Manual 5.2 Uninstalling BlueSoleil BlueSoleil can only be removed from Control Panel. For detailed instructions, please refer to "step 2.1 Before installing" in this guide. 5.3 Getting Started 1. Starting BlueSoleil Double click "Bluetooth Places" icon on the desktop or right-click the Bluetooth icon in the system tray and select "Explore Bluetooth Places".
  • Page 16 KBD401 USB Bluetooth Dongle User Manual 3. Search Services Double-click the device icon to enter the device's subfolder. Services supported by the device will appear in the window automatically. If not, double-click Search Services icon to refresh. 4. Establish a connection Double-click a service icon to initiate a connection.
  • Page 17 KBD401 USB Bluetooth Dongle User Manual You might be prompted to enter a passkey to authenticate. Enter the same passkey on both sides, or enter the specific one provided by the device manufacture on your computer side only. On BlueSoleil side, the dialog box as shown in the following picture will pop up for you to enter a passkey.
  • Page 18 KBD401 USB Bluetooth Dongle User Manual 6. When you use SPP, pair the KDC by selecting When you select and right-click on the available KDC, you can check Serial Port Number. Copyright ® 2013, KoamTac, Inc.
  • Page 19 KBD401 USB Bluetooth Dongle User Manual 7. Run KTSync by double-clicking icon in your computer desktop. When KTSync runs, the KDC communicates with KTSync though the serial port. 8. When you use HID, pair the KDC by selecting Copyright ® 2013, KoamTac, Inc.
  • Page 20 KBD401 USB Bluetooth Dongle User Manual 9. Terminate a connection Right-click the connecting remote service icon, and select Disconnect. 10. Both KDB401 and Bluesoleil 9.x support BLE (Bluetooth Low Energy). You can use BLE supporting devices by following the processes as below.
  • Page 21 KBD401 USB Bluetooth Dongle User Manual 11. Click , and you will find other settings and information. Copyright ® 2013, KoamTac, Inc.

  • Page 22: Warranty

    KoamTac will not be liable in cases (i) in which the unit has been repaired or altered unless done or approved by KoamTac, (ii) in which the unit has not been...

  • Page 23: Contact Information

    KBD401 USB Bluetooth Dongle User Manual 7. Contact Information CORPORATE HEADQUARTERS 116 Village Blvd., Suite 305 Princeton, NJ 08540, USA Phone: 609-256-4700, FAX: 609-228-4373 Email: support@koamtac.com For more information, visit our website - www.koamtac.com Copyright ® 2013, KoamTac, Inc.
