ADVENTURE STARTS HERE
Roof Tent User Guide
YOU MUST READ THIS GUIDE BEFORE ATTEMPTING
TO INSTALL OR USE YOUR ROOF TENT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pioneer and is the answer not in the manual?

Questions and answers

Summary of Contents for Latitude Pioneer

  • Page 1 ADVENTURE STARTS HERE Roof Tent User Guide YOU MUST READ THIS GUIDE BEFORE ATTEMPTING TO INSTALL OR USE YOUR ROOF TENT...
  • Page 3 Latitude Roof Tent onto your roof rack or roof bars. All of the tools and hardware required for installation are included.

  • Page 4: Table Of Contents

    Contents Getting Started Hardware Identification Chart Tent Orientation On Your Vehicle Tent Assembly Attaching Mounting Channels Installing the Ladder Installing Travel Cover Vehicle Installation Attaching to the roof rack Tent Set Up 10 -11 Setting Up the Tent Setting Up the Annex Installing the Boot Bags Storage and Handling Warranty...

  • Page 5: Getting Started

    Getting Started 1. Start by opening one end of the box. BE CAREFUL NOT TO CUT THE TENT FABRIC! Fold back the box flaps and flip the box so the open side is pointing down. You should be able to slide the box straight up and off the tent.

  • Page 6: Hardware Identification Chart

    What’s in the Hardware Bag? All of the tools you need to install your tent are included. Clear a space to empty the hardware bag. Please check that all these items are inside: Item. Quantity/No. Ladder Mounting Bracket 60 mm Stainless Steel Bolt 35 mm Stainless Steel Bolt 30mm Stainless Steel Bolt 20 mm Stainless Steel Bolt...

  • Page 7: Tent Orientation On Your Vehicle

    Tent Orientation On Your Vehicle There are two mounting options for the orientation of your new Latitude Roof Top Tent. Either the tent will open so that the ladder extends off the back of the vehicle, “Rear Mounted,” or the ladder extends off the side of your vehicle, “Side Mounted.”...
  • Page 8 Tent Assembly Attaching Mounting Rails 1. After removing the contents, close the tent so the channel mounting surface is facing upwards (the side with 8 holes in the centre area). 2. Take the mounting rails and align them with the pre drilled holes to coinside with the desired orientation.
  • Page 9 Tent Assembly Installing the Ladder 1. Flip the tent over so the side with mounting channels is facing down. 2. Align the ladder brackets over the pre drilled holes at the edge of the bed/tent base. 3. Feed the 35mm bolts with washers from the inside of the tent and screw on the nylock nuts by reaching inside the tent.

  • Page 10: Tent Assembly - Attaching Mounting Channels 6 - Installing The Ladder 7 - Installing Travel Cover

    Tent Assembly Installing Travel Cover 1. To attach the travel cover, first fasten the buckles on either side of the tent to compress and hold the canopy in place. 2. Slide the rounded fabric end of the cover into the rounded C-channel at the hinge side of the tent base.

  • Page 11: Attaching To The Roof Rack

    Vehicle Installing Attachment to the Roof Rack 1. Place the tent on top of your vehicle rack system, ensuring the mounting tracks are perpendicular to the bars they will mount to, and the tent is centered on the roof rack. Position the hinge so that the tent will open to the desired side.

  • Page 12: Tent Set Up - Setting Up The Tent

    Tent Set Up Setting Up the Tent 1. Release the straps over the travel cover. Unzip the cover and fold it back. You can remove it, roll it up, or let it hang off the side of your vehicle. 2. Undo the buckle straps keeping the tent closed. 3.
  • Page 13 5. To adjust the height, start with the top section, pressing the two buttons on the ladder rung to release the locking levers. Slide the ladder up so that it recedes into the top rung. Repeat for each section until the ladder is the desired height. Be sure that the remaining sections of the ladder are fully locked.
  • Page 14 Tent Set Up Setting Up the Ground Floor Extension (if included) 1. To start, you’ll need to remove the travel cover if you have not already. Do so by sliding it to one side and out of the channel in the frame. 2.

  • Page 15: Installing The Boot Bags

    Tent Set Up Installing the Boot Bags Install the boot bags by sliding the fabric edge into the frame on the side where the ladder is mounted.

  • Page 16: Storage And Handling

    Storage and Handling Clean and dry your tent after each camping trip: Every time that you return from camping you should clean and dry your tent. Also, wash the mattress and cover once in a while (only hang dry). 1. Open the tent fully and brush / vacuum inside. 2.

  • Page 17: Warranty

    HOW TO OBTAIN WARRANTY SERVICE Return the product, freight prepaid, to the Latitude Tents Dealer from whom it was purchased; or, contact Latitude Tents Limited via email: info@latitudetents.com. Collect shipments or shipments without return authorization cannot be accepted.

  • Page 18: Hints And Tips

    4. Run chargers through the velcro strap. The little velcro flaps around the hinge area allow you to run power cables from inside your car to inside your tent! Late-night movies in the comfort of your Latitude roof tent, check.

  • Page 19: Notes

    Notes contact details: www.latitudetents.com Tel: 07377 456 037...
