- Page 1 Band saw BAS-650 Original Instructions Manual ______________ Serial number...
- Page 3 Instruction manual and servicing Band Saw BAS-650 INDEX: 1. Marking 2. Using 3. Working places 4. Safety instructions 5. Maintenance and setting 6. Forbidden handling 7. Drawings and schemes 8. ES certificate of conformity 1. Marking Producer: Dr. Schulze GmbH...
- Page 4 Main measurements of the machine...
- Page 5 This machine is intended for cutting with the help of endless saw band. High quality blade allows the top results and performance. Band saw BAS-650 is not intended for cutting of soft materials such as wood, and plastic. Construction of band saw has been designed such as robust and strong, but simultaneously lightweight so that it can be easily transported for the working places.
- Page 6 !!Attention!!Operate the machine with a loose blade is forbidden! Cutting Band saw BAS-650 allows only perpendicular cuts (angle of 90 °). Procedure for cutting: - Before starting the saw is necessary to check the network connection, the state of the power cord and connection cable covering (against damages), condition and attachment of the cutting blade and condition and tighten of the table and the fastening of the covers.
- Page 7 - After start of the machine by the main switch the motor starts and spin the cutting band. - Place the cut material on the cutting table, lean it on the cutting ruler and move gradually towards the cutting zone, first test the cutting on a sample - Cutted material must be moved fluently to get straight and fluent cut, otherwise the band saw can be damage (the band can be twisted, it can lead to its destruction).
- Page 8 Regular and careful maintenance ensures the correct operation of individual parts. Repairs Possible repairs of band saw BAS-650 are recommended to send directly to the producer or person/company who is recommended by producer. Repair is recommended if the machine works abnormally (irregular noise, uneven speed, vibration, etc.).
- Page 9 Problems and their solving Problem May cause Possible solutions check the wiring low voltage low engine power change the supply cable incorrect wiring check the connection cut material is incorrectly set up cut material set up on the cutting table cut is not straight reduce cutting speed high pressure on the...
- Page 10 Forbidden manipulations: Operator is not allowed: operate a device that its design does not correspond with the conditions mentioned in this manual interfere to the electrical or mechanical parts of the machine when the machine is in operation connect the machine to the electrical system, which does not have ground use the band saw for other than the manufacturer specified materials operate the machine in the rain in the open space operate the machine with a damaged electric cable...
- Page 11 checking, adjusting, maintaining and cleaning the moving parts as recommended by the manufacturer / supplier of device know about switches to stop the device, including emergency, switches must be easy available, all areas must allow access to them, must be kept clean and free of obstacles regularly check function switches make lubrication equipment in accordance with operating instructions / manual...
- Page 12 Drawings and schemes List with the spare parts for BAS-650 Qty of pcs List of spare parts Position Order no. used on 1 machine Frame 500-00-913 Holder of the upper wheel 500-00-914 Bounding ring 500-00-98 Bushings Eccentric 500-00-915 500-00-916 Lever...
- Page 13 Qty of pcs List of spare parts Position Order no. used on 1 machine 500-00-932 Ruler Locking plate 500-00-933 Screw 500-00-934 Upper cover 500-00-935 Bottom cover 500-00-936 Connecting profile Rivet 500-00-937 Rivet 500-00-264 Fork 500-00-938 Safety profile 500-00-34 Rubber stopper 500-00-87 Handles 500-00-33...
- Page 14 Qty of pcs Position List of spare parts Order no. used on 1 machine Limit switch 500-00-939 Table of the Band saw Screw Screw Screw 500-00-101 Bearings Screw square 500-00-88 Clique Screw 500-00-89 Screw adjusting the blade 500-00-113 Clamping clique 100.
- Page 17 Circuit diagrame for BAS-650...
- Page 18 Used pictograms on the machine Read the instruction manual Caution, risk of injury by cutting Command to wear hearing protection Command to wear eye protection Command to wear hand protection...
-
Page 19: Declaration Of Conformity
Internal production control according to article 14 § 2 according to annexe V. The declaration of conformity is no longer valid, as soon as the installation and the use of the Band saw BAS-650 does not correspond to the machine guidelines and specifications.
