Summary of Contents for Alstom DS Agile C26 Series
- Page 1 DS Agile C26x Addendum to Technical Manual System version: from 5.1.0 to 5.1.7 C26x/EN M/C67...
- Page 2 DS Agile C26x. However, the guide cannot cover all conceivable circumstances or include detailed information on all topics. In the event of questions or specific problems, do not take any action without proper authorization. Please, contact the appropriate Alstom technical sales office and request the necessary information.
-
Page 3: Table Of Contents
DS Agile C26x Addendum to Technical Manual Contents INTRODUCTION FIREWALL USAGE REQUIREMENTS Firewall Usage SCE Configuration 2.1.1 SCS level 2.1.2 Computer level Network Separation SBUS and Maintenance Access Point 2.2.1 Firewall usage set to YES (Enabled) 2.2.2 Firewall usage set to NO (Disabled) LIMITS C26x/EN AD/C67 AD-1... - Page 4 Addendum to Technical Manual DS Agile C26x AD-2 C26x/EN AD/C67...
-
Page 5: Introduction
DS Agile C26x Addendum to Technical Manual INTRODUCTION The Firewall usage function allows network separation which enforces the security and reduces the intrusions. The C26x uses the configuration settings in the SCE for the Firewall usage function. Use the SCE for configuring the network separation between: ... -
Page 6: Firewall Usage Requirements
Addendum to Technical Manual DS Agile C26x FIREWALL USAGE REQUIREMENTS Firewall usage requirements for network separation on the C26x BCU are: Different subnet IP addresses on Eth1 and Eth2. (Default subnet mask is 255.255.255.0). Operational database. Note: Firewall usage is configured only in Off-line mode through the SCE. FIREWALL USAGE SCE CONFIGURATION Configure the Firewall usage in SCE. -
Page 7: Computer Level
DS Agile C26x Addendum to Technical Manual 2.1.2 COMPUTER LEVEL Computer level defines the IP-Address for Sbus port ( ETH1) and Maintenance port (ETH2): W0411ENa Note: Eth1 and Eth2 IP addresses are set in different subnets via CMT. The configured IP addresses must be the same as the IP addresses of the C26x BCU. Use the CMT tool: ... -
Page 8: Network Separation Sbus And Maintenance Access Point
Addendum to Technical Manual DS Agile C26x NETWORK SEPARATION SBUS AND MAINTENANCE ACCESS POINT Firewall function is activated only when: The Firewall function is enabled in the configured Database. The configured Database with the Firewall function enabled is set as the current Database. Firewall function is disabled if there is no operational Database on the C26x BCU. -
Page 9: Limits
DS Agile C26x Addendum to Technical Manual LIMITS The Firewall usage is forbidden when the C26x BCU is used in one of these architectures: Mulitrack mode RTU mode PBus mode Firewall is only configurable in Off-line mode trough the SCE. The SCE applies the Firewall Usage on all the C26x BCUs configured in the Database. - Page 10 Addendum to Technical Manual DS Agile C26x AD-8 C26x/EN AD/C67...
- Page 12 Alstom Grid © - ALSTOM 2015. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances.
