OPERATION MANUAL
for the
MODEL SRB-406 TYPE S ELT
PN P3-03-0041 Series
Where used: P3-03-0041 Series
Next assembly: P3-03-0041 Series
Y1-06-0130
6830 N.W. 16th Terrace, Fort Lauderdale, FL 33309
Document No. Y1-06-0130 Rev. B
Date:
September 12, 2002
Date:
September 12, 2002
Date:
September 12, 2002
Date:
September 12, 2002
Advertisement
Summary of Contents for DME SRB-406
- Page 1 NOTICE IS HEREBY GIVEN THAT ALL DATA CONTAINED IN, REVEALED BY, OR SHOWN IN THIS DOCUMENT ARE PROPRIETARY AND BELONGS TO DME CORP., FT. LAUDERDALE, FLORIDA. IT IS FURNISHED AND RECEIVED IN CONFIDENCE SOLELY FOR INFORMATIONAL PURPOSES OF THE RECIPIENT FOR THE PURPOSES HEREWITH TRANSMITTED. NONE OF THE INFORMATION CONTAINED HEREIN SHALL BE USED FOR ANY OTHER PURPOSES OR DUPLICATED IN WHOLE OR IN PART WITHOUT PRIOR AUTHORIZATION OF DME CORP.
- Page 2 Y1-06-0130 Rev. B REVISIONS Revision Date Change Description Approval 12/19/02 ECO #13565 T. Cohen 3/21/03 ECO #13724 T. Cohen Page 2 of 9...
-
Page 3: General Description
There are two models, the -001 and the -002. The -001 single antenna SRB-406 is configured for use on non-reversible, self-righting rafts and the -002 dual antenna SRB-406 is for rafts that are reversible. - Page 4 Y1-06-0130 Rev. B Bilingual -001 Single Antenna Model Bilingual -002 Double Antenna Model Figure 1. Model SRB-406 Page 4 of 9...
- Page 5 On the -002 model, the water activation sensors are on both antennas. Battery Power for the SRB-406 transmitter is provided by a single lithium battery pack that is located within the transmitter housing. The battery pack uses 4 each lithium/manganese dioxide, 1-1/4 “C” size cells. The cells are arranged in series. Each cell is protected from short circuit by a manufacturers installed safety device (PTC).
- Page 6 Slide the new battery connector into the corresponding connector half from the SRB-406 until it snaps into place. Place the new battery into the cavity in the unit, push battery cabling into cavity sufficiently to facilitate installation of the cover removed in step 1; ensure the battery does not pinch any of the wires.
- Page 7 Y1-06-0130 Rev. B Figure 2. Cover Removal Figure 3. Battery Removal/Installation Press to Test Switch A tactile-type switch, labeled PRESS TO TEST, is provided on the transmitter housing (see Figure 1 for location) for the purpose of testing the unit for proper operation. Momentarily depressing the PRESS TO TEST Switch will cause the LED to flash once immediately.
-
Page 8: Technical Data
TECHNICAL DATA Buoyancy The SRB-406 is used only as part of a TSO-C69 or TSO-C69A raft, or a TSO C12c life raft. The transmitter/battery assembly is secured in a pouch that is an integral part of the raft, therefore, buoyancy of the SRB-406 is not required. - Page 9 Y1-06-0130 Rev. B Operating Specifications Transmitter Duty Cycle: 5 watt digital signal every 50 seconds, for 440 millisecond duration Homing Signal Tone Frequency: 700 Hz Sweep between 1600 and 300 Hz Homing Signal Tone Sweeping Rate: 2 to 4 times per second Operating Temperature Range: -20`C to 55`C (-4°F to 131 °F) Homing Signal Operating Range:...
