Secure Home Heath Zenith DUALBRITE SH-4266-PB Installation And Operating Instructions Manual

D B ® Motion Sensing
UAL RITE
Coach Light with BulbSaver
Technology
Item Model
12043 SH-4266-PB
21746 SH-4266-SA
482286 SH-4266-BK
Motion Decorative Light
* BulbSaver - Light comes on dim and gradually increases to
full brightness. When the light turns off it will gradually dim to
half-bright, pause, and then will continue dimming until the
light turns off.
For a description of the DualBrite® technology, see page 6.
© 2013 HeathCo LLC
INSTALLATION AND OPERATING
*
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
HARDWARE CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
LIGHT FIXTURE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
WIRING THE LIGHT FIXTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
OPTIONAL WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
MOUNTING THE LIGHT FIXTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
TESTING AND ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
FINAL SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
MANUAL MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
CARE AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
TROUBLESHOOTING GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
TECHNICAL SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
THREE YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Please refer to the troubleshooting guide in this manual
or call our technical service department (English speak-
ing only) at 1-800-858-8501, 8:00 a.m. - 5:00 p.m., CST,
Monday - Friday before returning to your retailer.
Keep this manual for future reference.
ATTACH YOUR RECEIPT HERE
Receipt is required for all warranty requests.
Purchase Date
INSTRUCTIONS
Questions?
206476-01A
