- Page 1 AFRICAN CLEAN ENERGY ACE One User Manual...
-
Page 3: What's Included
About your ACE One x2 Handles USB ports x2 Fan control knob DC charging port Smart battery indicator What’s included? Solar 1-year panel lamp warranty... -
Page 4: How It Works
How it works Burning chamber (fuel goes in here) The air blows in the fuel chamber and stimulates the fire Battery-powered fan creates airflow The battery can be charged with the solar panel placed in the sun, or with the electricity grid using the wall charger*. - Page 5 OUTPUT HEAT BURNING OF HOT GAS GASIFICATION BURNING OF BIOMASS AIR FLOWS IN AIR FLOWS IN...
-
Page 6: Charging The Battery
Charging the battery Ensure the stove shows the fully- charged green light Connect the solar panel and leave the panel facing the sun for the best charging performance Or plug in the wall charger* *wall charger is not included... - Page 7 Orange light: Red light: Fully charged Low battery Charge now While charging your ACE One, the LED will also indicate the speed of the charge. Slow flashing? It’s charging slowly. Flashing quickly? Your ACE One is charging fast! Battery Indicator...
- Page 8 ACE Connect App If you are an ACE Connect customer, the LED light will give indications about your credits (days remaining) and data transfers. Pink light: There is a payment issue. You may need to make a payment or sync with your ACE Connect app...
-
Page 9: Fuel Types
Fuel types Types of ignition fuel Use only natural and dry fuel No plastic Leaves Paper Palm oil nuts bags Types of cooking fuel Wood Biomass fuel Sticks pellets Corn cobs Coconut shells Dried cow No liquid dung fuel... - Page 10 Fuel preparation Cut thin pieces of wood Upper airholes Place the fuel in the stove below the upper airholes...
- Page 11 Using wood pellets Begin by filling a jar with pellets and soaking them in parrafin You can also use: Corn Coconut cobs shells Add dry pellets into the stove (maximum level is just below the top air holes)
- Page 12 Add a thin layer of paraffin soaked pellets on top of the dry pellets Light the pellets then begin cooking...
- Page 13 Setting up your ACE One Make sure the battery is fully charged by using the solar panel or wall charger* Place the stove on something stable and on a clean surface...
- Page 14 Check whether the solar panel is facing the sun...
- Page 15 Cooking steps Collect enough fuel Chop the fuel into the right size...
- Page 16 Prepare the food before lighting the fire Upper airholes Place the kindling below the upper airholes...
- Page 17 Light the kindling in a well-ventilated space Turn the knob clockwise Wait for the fire to begin spreading, then gently turn the fan on low...
- Page 18 Begin adding the small pieces of wood, wait for them to catch light, then increase the fan speed Once the fire is strong, start cooking and use a lid if possible...
- Page 19 Caution hot surface! When refilling the ACE 1 with fuel, be careful of hot surfaces Turn the knob anti-clockwise Turn the fan off after cooking...
- Page 20 minutes Wait until the ashes have fully cooled down Empty the stove. You can save the ash and spread it around your garden...
- Page 21 Don’t do this Do not place fuel Do not spill food above the airholes into the stove Do not cook on the ACE One Do not carry the without using the stove top stove whilst lit...
- Page 22 Do not pour flammable liquid Do not use the ACE or water into your ACE One One in a closed room Do not leave your ACE Do not put heavy weight One in rain or water on your ACE One...
- Page 23 Do this Ideally, install your solar Regularly clean the panel on the roof solar panel Regularly clean your Place your ACE One ACE One indoors when it is raining...
-
Page 24: Optional Accessories
Disclaimers Caution, open fire, hot surfaces, risk of severe burns Only use in well ventilated space Do not use in a closed environment Risk of smoke inhalation Optional accessories Wall Wood Tripod charger charging cable pellets... - Page 25 ACE One Energy System AFRICAN CLEAN ENERGY Manufactured by African Clean Energy www.africancleanenergy.com African Clean Energy...
