Robotic Pool Cleaner
ITEM: 75067
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: 909.628.0880 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Related Manuals for XtremepowerUS 75067
Summary of Contents for XtremepowerUS 75067
- Page 1 Robotic Pool Cleaner ITEM: 75067 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER) FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: 909.628.0880 MON-FRI 9AM TO 3PM PST...
- Page 2 Index 1. Product Introduction 2. Warning and Cautions 3.Features and Operation Instructions 4.Routine Maintenance 5.Trouble Shooting 6.Specifications 7.Parts Breakdown and Replaceable Parts List...
-
Page 3: Product Introduction
Product Introduction Swimming is good to you health.The cleaning robot is a kind of the underwater cleaner , it is fully automatically. It is mainly used to clean the dirt and debris such as hair, leaves and sand from the pool floor; pool wall and waterline. As long as you put it into the pool after initial program setting, the cleaning robot can automatically measure the size of the pool, automatically design the working route, and clean the pool by itself. -
Page 4: Brief Introduction
Brief Introduction start/stop button, error alarm 2.Floor clean only To clean the pool floor only.It will increase the clean efficiency 3.All purpose clean All-around cleaning, including pool floor; pool wall and waterline. 4 Timed Stop!running time" Choose the preferred running hours(2/3/5 hours,press the button to choose the time you want,red light means the cleaner will work for 2 hours,green light for 3 hours,blue for 5 hours),before start the cleaner.The cleaner will stop automatically after working 5.Mobile phone Bluetooth APP Control (Not applicable in some models) - Page 5 3.Put the Pool Cleaner into the pool. Release the Pool Cleaner and let it sink to the floor of Put the Pool Cleaner into the pool. Release the Pool Cleaner and let it sink to the floor of Put the Pool Cleaner into the pool. Release the Pool Cleaner and let it sink to the floor of the pool.
- Page 6 6.Indicator lights# All Purpose Clean On Off Button Floor Clean Only Running Time Bluetooth Light Running Time Indication: Red light twinkling means the cleaner has been set for 2 hours Green light twinkling means the cleaner has been set for 3 hours Blue light twinkling means the cleaner has been set for 5 hours...
-
Page 7: Daily Maintenance
Daily Maintenance 1.Clean the Filter Basket Cut off the power supply ( light go out)Turn off the Pool cleaner. Open the filter cover. Clean the filter basket with a hose. Insert the clean filter basket and close the filter cover. Make sure the power supply is switched off and unplugged.It is highly recommended to clean the filter basket after each cleaning cycle... -
Page 8: Troubleshooting
2.Floating cable daily maintenance The floating cable may get intertwined after 6 hours of working which need to be sorted out manually.It highly recommend to sort the cable out after each cleaning. Trouble Shooting Symptom Possible Reason Corrective Action The pool cleaner moves but does not clean the Clogged filter basket Clean the filter basket... - Page 9 Specification Specifications 18.5x 16 x1 0 i n ch Product dimension Package dimension 21 x 18.5x1 5.4 i n ch Product weight Around 23 Ibs Package weight Around 40 Ibs Cleaning area All-around Filtration accuracy Length of floating cable 55 feet Filter speed 60-80 GPM Warranty...
- Page 10 Parts Breakdown and Replaceable Parts List Parts Name Cover and wiring assembly Parts Name Filter Basket Cover Motor box Main Frame Wheel Brush Side Panel Buoyancy block Motor Box Driven wheel Controller Box Bearing Floating Cable Drive Belt Side panel Wheel Brush Controller Box Handle...
-
Page 11: Please Read The Following Carefully
DISCLAIMER PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
