Boean B10 - TWS Earbuds Manual

Product Overview

Manual thoroughly before operating your device. In order to avoid unnecessary in juries, please do not disassemble this product by yourself. Please use a standard charger.

1. Choose the ear cap that suits you.


2. Make sure that the ear caps face down and put the earbuds into the ear in the angle shown as the picture on the right.

3. Wearing earbuds and adjust the right angle as the picture shows. It's OK when we feel comfortable and stable.

4. Wrong Demonstration
   Do not wear the earbudslike the way shown as the picture on the right


First time using

1. Tear off the insulating film.

2. Put the two earphones back into the charging compartment to charge (the white light is on After activating the headset).

3. Take both earbuds out from the charging case, they will power on and pair to each other automatically. Waiting for pairing(blue/white light flashes alternately).

Tips:
If the earphone is not turned on or there is no sound, please put it back in the charging box again to make sure it is in the charging state before taking it out for use (white/blue light flashes alternately)

4. Turn on the Bluetooth function on your phone and search fo【r B10】and connect it.


Tips:
when the two earbuds can't pair under the first time use, or there is no sound in one of the earbud, please proceed as follows:

• Left/right Earbud Connection & Pairing
  Turn off the phone' s Bluetooth and the earbuds, and then hold the earbuds, power buttons for 9 seconds to turn on the earbuds, the earbuds will enter paring mode (indicators flash blue fast) and about 5 seconds the two earbuds will enter pair to the phone mode(the indicator will turn to blue and white alternately)

Button control

Take earbuds out of the charging case or Long press for 5 seconds.

Put it back in the charging case or No connection for 5 minutes.

Voice Assistant / Siri

Press either earbud MFB for three times will activate Siri function and exit with same operation. (this function is only available to IOS system. In playing music, it can be activate while pause state).

The voice assistant will be based on different operating systems in the mobile systemAutomatically activate.

Restore factory setting

If the earbuds can't work properly by misoperation, please repair them as follows:

1. Clear the record: first turn off the Bluetooth function of the mobile phone and turn offthe earbuds, then press and hold the power button for 5 seconds, then let go, and then quickly press the power button four times. After the white light of the earbuds is on for 1 second, the record will be cleared and the earbuds will automatically shut down.

2. Reset: Put the left and right earphones back into the charging case at the same time and reactivate them.
3. Automatic pairing: Take out the left and right earbuds at the same time to automatically complete the pairing.
4. After restoring the headset settings, delete the [B10] historical pairing records on the mobile phone and then search for the [B10] headset again.

Earbuds indicator

Charging case indicator

Charging case
Please use a charger with an output voltage of DC5V/1A to charge the charging case. You can also use a computer USB or other USB interface charger to charge (Must choose a charger certified by a regular manufacturer).

Parameter specification

Notice:

• If the charging case is out of power, it may cause the earbuds to fail to shut down and remain connected to the phone even when they are placed in the charging case. So please remerber to charge the charging case in time.
• If you want to switch the Bluetooth connection to another device, please disable the Bluetooth function in the previosly connected device OR delete the pairing name of "B10" from the original device. Then the pairing name of "B10" can be searched in new device and connected successfully.
• If moisture remains at the audio output hole, the sound may become fuzzy or completely inaudible. This is completely normal. In this case, please remove the earplugs and shake the audio output hole down several times to allow water to flow out or let it air dry for 1-2 hours, then the sound quality will become normal.


Attentions

The Charging cable is not waterproof

The Charging case is not waterproof

Do not use hot water to disinfect the product

When the earbuds has water, please wipe it dry and put it back into the charging box to avoid damaging the device.

Tips:

1. If the product is dirty, ple or soak it in boiling water for disinfection. It is recommended to wipe the earplugs with an alcohol-containing or wet paper towel.
2. If you accidentally fall into the water, please pick it up in time, dry it with natural wind or dry it in the sun for 2 hours before using it.
   (Otherwise it will affect the sound quality and make you not get a better experience)

1. Do not use corrosive liquid to clean this product.
2. If it comes into contact with chemicals, please rub it with a damp cloth wet with clean water.
3. Do not put the equipment under too high or too low temperature ( Below -10 ℃ or above 60℃)
4. To avoid explosion, please do not throw this product into fire.
5. To avoid scratches, please do not touch the earbuds with sharp objects..
6. Do not insert objects into the earbuds, otherwise it would cause damage to the internal components.
7. Do not disassemble the earbud.
8. Please keep regular charge to earbuds, don' t leave them become empty battery status to keep their lifetime.
9. Please do not charge products with power adapter over 2A current. Excessive current may cause the damage to battery.

Battery
There is a built-in lithium battery in this product.
To avoid explosion, do NOT expose the product to strong sunlight, fire or throw it into fire.
