Elecder D18 - Wireless Earbuds Manual

Introduction

Thank you for purchasing your new Elecder D18 true wireless earbuds.

We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers.

Read all the safety instructions carefully before use and keep this instruction manual for future reference.

Safety Rules

1. Charge the earbuds and the charging case at least once every 6 months.
2. Do not store the product in extreme temperature (below 0℃ or above 45℃).
3. Do not use chemicals or detergents to clean the product.
4. Do not drop or knock the product on hard surfaces.
5. Do not scrape the surface of product with sharp objects.
6. Do not try to take the product apart.

Specifications

Product Overview

How to Wear?

The correct way of wearing
Put earbuds in the ear and gently rotate until 45° above (as shown below).

Power ON/OFF

Power ON:
When you open the charging case(with battery power inside), it will be power ON automatically and blue LED will blink.

When the earbuds L & R is power OFF after taking out of the charging case, long touch the L & R earbuds button to turn it on and blue LED will blink.

Power OFF:
When you put the L & R earbuds into the charging case(with battery power inside), close the charging case, it will be power OFF automatically.

When the earbuds L & R is power ON after taking out of the charging case, long touch the L or R earbuds button to turn it off under BT disconnection status.

Note: Under BT disconnection status more than 5 mins, the L & R earbuds will be power OFF automatically.

Pairing

Stereo Mode

1. Take out both earbuds from the charging case, the L&R earbuds will be automatically connected.
   Blue LED will blink.

2. Activate Bluetooth on the phone and search for "Elecder D18" to connect. Blue LED will blink slowly after connected.


Mono Mode

1. Take out L or R earbuds from the charging case.
   Blue LED will blink.

2. Activate Bluetooth on the phone and search for
   "Elecder D18" for L earbuds Or
   "Elecder D18 R" for R earbuds.
   Blue LED will blink slowly after connected.


Multi Functions

Note: In Mono mode, double tap L or R can only move to next song.

Charging Mode

1. Charging the earbuds
   Take earbuds into charge case

   * Charging: Red LED is on
   * Full charged: Blue LED is on & turned off after about 30s

2. Charging the case by Type-C cable

   * Charging: < 30% battery, Red LED is on
   30%-80% battery, Orange LED is on
   80%-100% battery, Green LED is on
   * Full charged: Green LED is off

Note: 5V/1A or 5V/1.5A is the best choice for the charger.

3. Charge the case by wireless charger


Factory reset

In case there is no auto pairing after taking out the earbuds from the charging case, please follow the below steps to restore the default setting:

1. Ensure L&R disconnect to any device(trun off the bluetooth device connected before).
2. Trun off both L&R earpbuds.
3. Long touch MFB button of L&R earbuds around 8s till both red light flash 3 times. The factory reset is now finished.
4. The L&R earbuds will be automatically connected and blue LED will blink. The earbuds is ready to pair with your device now.

EARBUDS MANTENANCE:

1. Keep the earbuds away from high temperature and humidity
2. Do not put the earbuds directly in the sun to burst, or put it in a high temperature environment, which will shorten the life of the earbuds (internal department of electronic components and batteries).
3. Do not try to disassemble the earbuds body.
4. Do not drop the earbuds on a hard surface.
5. Do not use sharp objects to scratch the surface of the product.
6. Do not use chemicals or detergents to clean the earbuds.

WARRANTY REGULATIONS

The following conditions are not covered by the warrenty:

1. Because of buying second-hand or used products.
2. Damage caused by irregular operation.
3. Damage caused by natural disasters.
4. Damage caused by chemical substances, open flames, radioactive substances, toxic substances, liquids.
5. Damage caused by third parties / people / things or others.

WARRANTY AND AFTER SALES

If you need after-sales or any help, please contact us by the email "support@elecder.net", our customer service will reply you within 24 hours, we will do our best to solve your problem.

For more information please visit http://www.elecder.net
