OWNER MANUAL
BOTTLED
WATER
DISPENSER
MODEL 28
MODEL 28
COOLING
FLOOR
CABINET
STANDING
CAUTION:
Before using the water dispenser, read this manual and follow all safety rules and operating
instructions.
MODEL 30
MODEL 25
MODEL 28
MODEL 31
TABLETOP
TABLETOP
MODEL 31
MODEL 24
MODEL 24
TABLETOP
MODEL 26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 28 and is the answer not in the manual?

Questions and answers

Summary of Contents for TVC 28

  • Page 1 OWNER MANUAL BOTTLED WATER DISPENSER MODEL 30 MODEL 28 MODEL 28 COOLING FLOOR CABINET STANDING MODEL 31 MODEL 25 MODEL 26 MODEL 24 MODEL 28 MODEL 31 MODEL 24 TABLETOP TABLETOP TABLETOP CAUTION: Before using the water dispenser, read this manual and follow all safety rules and operating...
  • Page 2 Current publication in May 2022 First published in April 2017 Manufactured by: The Vending Company Disclaimers: Actual design, colour and specification may vary from the sketches shown. The picture is used for representation purpose only. Note: The Machine specifications are subject to change without notice.
  • Page 3 Adjusting The Temperature (Cold Water Only) Cleaning And Maintenance LED Function Indicators Technical Specification Exploded view & parts name of M 31 Exploded view & parts name of M 28 Troubleshooting Tips Troubleshooting Tips M 31 Disposal Of Machine Frequently Asked Questions...
  • Page 4 LETTER FROM THE COMPANY Congratulations on your purchase of the Bottled Water Dispenser. Please read the This product has been engineered for optimum User manual prior and convenient performance. to using the machine. We assure you years of satisfactory and trouble Ensure staff...

  • Page 5: Important Safeguards

    IMPORTANT SAFEGUARDS Never turn the dispenser upside down or tilt more than 45 degrees. If unit has been resting on its side for an extended period of time, place the water dispenser in the upright position for approximately 12 hours before turning it on. Do not switch on the hot water until water runs out from the red tap •...

  • Page 6: Installing The Water Bottle

    OPERATING INSTRUCTIONS Initial Product Cleaning Procedure. As with most new appliances, it is recommended to clean the reservoir prior to first time use. 1. Make sure the unit is unplugged and power switch is turned off. 2. Remove the bottle support funnel, saturate a clean cloth with water dispenser cleaner or vinegar and wipe the inside of the reservoir.

  • Page 7: Dispensing Water

    IMPORTANT NOTICE ABOUT LEAKING BOTTLES If you find that your dispenser is leaking, check the water bottle first ! Almost all 10-25 liter water bottles are recycled, and handled extensively during cleaning, filling, and shipping. As a result they are very prone to developing pin holes or small cracks that can cause an overflow (or leak) when placed on top of a water dispenser.
  • Page 8 ADJUSTING THE TEMPERATURE (COLD WATER ONLY) By turning the thermostat at the back of the unit, the temperature can be adjusted. If the water dispenser is not dispensing water, there could be TESTED a possible ice build up due to the thermostat being set too cold.
  • Page 9 CLEANING AND MAINTENANCE Like most appliances, your new water dispenser requires periodic maintenance to operate efficiently. Your water dispenser must be cleaned every 4 months. Please note that as per your warranty, routine maintenance of the dispenser is required. Failure to maintain the water dispenser will void your warranty.
  • Page 10 DRAINING THE RESERVOIRS Drain the reservoirs before and after cleaning, when going on long vacations or if not using the dispenser for long periods of time. Drain valve IMPORTANT! Turn power switch to the OFF position and unplug the dispenser before performing this procedure.

  • Page 11: Technical Specifications

    TECHNICAL SPECIFICATIONS MODEL 31 MODEL 28 MODELS MODEL 30 FLOOR FLOOR COOLING TABLE TABLE DESCRIPTION STANDING STANDING CABINET No. of Faucets Power Source 230V-1Ph-50/60 Hz Cold Storage Capacity (litres) Cooling Capacity (litres/hr) Refrigerent R-134A Power Cold (W) Static Static Static...

  • Page 12: Exploded View Of Machine

    EXPLODED VIEW OF MACHINE PARTS IDENTIFICATIONS - Model 31 S.NO. S.NO. PARTS NAME PARTS NAME Funnel Front Lower Front Upper Cold Switch LEDs Hot Switch Tap Cover Power Cord Hot Water Outlet Condenser Normal Water Outlet Earthing   Cold Water Outlet Drain Outlet Waste Water Tray...
  • Page 13 EXPLODED VIEW OF MACHINE PARTS IDENTIFICATIONS - Model 28 S.NO. PARTS NAME Funnel Front Upper Hot Water Outlet Normal Water Outlet Cold Water Outlet Waste Water Tray Refrigeration Middle Tray Cabinet Door...

  • Page 14: Troubleshooting Tips

    TROUBLESHOOTING TIPS PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTION Small pin hole or crack in the bottle, Conduct water bottle leak test (common with recycled water as outlined in manual. bottles). Water dispenser Ensure seal is secure in drain or dispensing tap Drain cap and silicone seal are not plug an d tighten drain cap.
  • Page 15 TROUBLESHOOTING TIPS Model 31 PROBLEM/FEATURE DESCRIPTION Atlantis Airpress come with ON/OFF mode (By Default) with blue LED continuously How much Mode Airpress glowing, where show finger to START and come with show finger to STOP. Second one is steady mode where show finger to START otherwise STOP.

  • Page 16: Frequently Asked Questions

    b. Through Sales Offices of The Vending Company and Channel Partners: Company can also collect defective Electrical & Electronic parts or defective Product after its life span, which are intended to be discarded from Channel partners/ Dealers / Distributors / customers. This e-waste is then recycled through authorised e-waste re-cycler c.

  • Page 17: Warranty Card

    Q: WHAT IS THE SPIKE THAT GOES INTO THE BOTTLE? A.: Water dispensers feature a “puncturing tube” as part of the bottle support funnel, providing added convenience for water bottle installation. Depending on the water bottle supplier, a small opening may or may not be present in the bottle cap for this specific purpose.

  • Page 18: Customer Details

    CUSTOMER DETAILS Model No. : Serial No. Date of Purchase : Customer Name & Address Customer Name & Address Tel : Tel : Customer’s Signature Dealer’s Signature & Stamp...
  • Page 19 Name and Address of the Seller : Seller’s Stamp & Signature : Manufactured by: THE VENDING COMPANY PLOT NO - 28, SECTOR- 4, IIE, SIDCUL, PANTNAGAR, RUDRAPUR, UTTARAKHAND - 263153, INDIA Model : Name of Customer : Date of Purchase : Serial No.
