Summary of Contents for Spendor THEATRE AC1
- Page 1 S P E N D O R T H E AT R E Advanced Set-up Guide...
- Page 2 A DVA N C E D S E T- U P G U I D E...
- Page 3 This guide is for the Spendor AC1, AC2, DC1 centre channel products and the AW1 & DS1 wall mount products. To get the most out of your new loudspeakers, please read this guide thoroughly before you begin installation.
- Page 4 LO U D S P E A K E R P L AC E M E N T F O R D S 1 I N S T E R E O ( 2 . 0 ) O R S T E R E O & S U BWO O F E R ( 2 . 1 ) LEFT AND RIGHT CHANNEL LOUDSPEAKERS Place the left &...
- Page 5 2m - 3m (6’6”- 9’10”) 0.8-1.2m (2’6”- 3’9”) From the ground IDEALLY, THE HF UNIT SHOULD BE LEVEL WITH YOUR EARS IN THE SEATED POSITION...
- Page 6 LO U D S P E A K E R P L AC E M E N T F O R 5 . 1 SY S T E M S LEFT AND RIGHT CHANNEL LOUDSPEAKERS CENTRE CHANNEL LOUDSPEAKER Place the left & right channel loudspeakers on either side If possible, locate the centre loudspeaker at the same height of the video screen, anywhere from 1.8m to 3m (5’10”- as the left &...
- Page 7 LEFT & RIGHT SURROUND CHANNEL LOUDSPEAKERS The left & right channel surround loudspeakers should If placing the loudspeakers on the walls directly to the sides be placed on the walls directly to the sides of the listening of the listening position isn’t possible, you can mount them position, between 1.5m (4’11”) and 2.1m (6’10”) off the on the rear wall.
- Page 8 LO U D S P E A K E R P L AC E M E N T F O R 6 . 1 & 7 . 1 SY S T E M The surround back loudspeakers in a 6.1 or 7.1 channel N.B. You can use any Spendor A-Line, D-Line and Classic system should be placed on the rear wall of the listening...
-
Page 9: Lo U D S P E A K E R C O N F I G U R At I O N
FREQUENCY N.B. For all other AV amplifier/receiver settings, please refer Sub bass 20-60 Hz to the owners manual for that product or for more detailed advice, Spendor recommends you consult with your Spendor Bass 60-250 Hz Authorised Retailer/Installer. Low Midrange... - Page 10 RU N N I N G - I N CONNECTIONS Your Spendor loudspeakers will benefit from a period of ‘running-in’. During this period, the stresses in the suspension Set your amplifier to minimum volume and switch off system will relax and stabilise. This period is dependent on the power.
- Page 12 SPENDORAUDIO.COM M AY 2 0 2 3...
