- Page 1 Vehicle Security INSTALLATION MANUAL Model: PLUS-3000 For Technical Assistance (800) 638-3600 For Fax on Demand Technical Assistance (800) 994-9977 (Must be a Registered Dealer to Use Fax on Demand System) © Copyright 2000 Magnadyne Corporation...
-
Page 2: Table Of Contents
Index Step 1: Component Installation ..........Step 2: 10-Pin Main Harness Installation . -
Page 3: Step 2: 10-Pin Main Harness Installation
Step 2: 10-Pin Main Harness Installation The main wire harness contains 8 wires which all have a specific purpose. Follow the wiring recommendations enclosed for each wire. Wires not used should be released from the harness connector or taped off to prevent accidental shorting. Included with the 10-pin wire harness are two loose wires, an orange wire and a white wire with black stripe. -
Page 4: Step 3: 5-Pin Power Harness Installation
Step 2: 10-Pin Main Harness Installation (Continued) Red / White: (Pulsed Parking Light Relay Output) Connect the red/white wire to the parking light wire coming from the headlight switch. (Do not connect the red/white wire to the dashboard lighting dimmer switch. Damage to the dimmer will result) use a volt meter to test the connection point before connecting the red/white wire. -
Page 5: Step 5: Optional Accessory Connections
Step 5: Optional Accessory Connections Single Zone Electronic Sensor Plug Red Wire: +12 Volt Sensor Power Supply Black Wire: Sensor Ground Supply Blue Wire: Sensor Alarm Trigger Input Green Wire: No Connection 4 Pin White Plug Power Door Lock/Unlock Activation 3 Wire Ground Trigger Door Lock System Lock Control 3 Pin Black... - Page 6 Step 5: Optional Accessory Connections (Continued) Mercedes Door Lock Activation Unlock Red Wire: Lock Door Lock Switch Orange Wire: No Connection Lock Lock Black Wire: Unlock To +12 Volts 3 Pin (Battery +) Black Plug Door Lock Unlock Compressor Newly Installed Power Door Lock Motors Red Wire: Lock Orange Wire: No Connection Black Wire: Unlock...
- Page 7 Step 5: Optional Accessory Connections (Continued) Starter Disable Wiring Using Optional ALA-RPS Relay Pack Using the wiring information and diagram below, connect the optional starter disable relay as follows: A. Locate the “Start Only Wire” coming from the ignition key switch and cut it. B.
- Page 8 Step 5: Optional Accessory Connections (Continued) Flashing Parking Lights Headlight Switch Piggyback Parking Connection Red Wire with White Stripe Lights Output from Alarm Only #2 Button Power Trunk Activation Using Optional ALA-RPT Relay Pack Insert Red Wire into the First Socket Insert Black Wire into the Eighth Socket Orange Wire Output to Trunk Switch...
-
Page 9: Step 6: Transmitter Programming
Step 6: Transmitter Programming Note: Transmitters are pre-programmed so there is no need to program the transmitters. To program additional or replacement transmitters follow the instructions below. S t e p 1 S t e p 2 Valet/Override Switch Switch in Switch in “Off”... -
Page 10: Step 7: Remote Feature Programming
Step 6: Transmitter Programming S t e p 7 S t e p 8 To Code #2 Button Switch the Valet Switch Push the “#2” Button On then Off 1 Time The LED will begin flashing slowly and the horn/siren will chirp 2 times. The LED will be solid red and the horn/siren will chirp 1 time. - Page 11 Step 7: Remote Feature Programming (Continued) S t e p 3 S t e p 4 Turn On the Ignition Switch the Valet Switch On then Off 6 Times The LED will remain off. The LED will be on solid and the horn/siren will emit 1 long then 1 short chirp. You are now in the “Remote Feature Programming”...
-
Page 12: Step 8: Multiple Car Programming
Step 8: Multiple Car Programming About Multiple Car Programming: Note 1: Regular Carbine transmitters with 2 buttons can operate 2 Carbine alarm systems. (Alarm models do not have to be the same) Note 2: Code Hopping Carbine transmitters will only operate 1 Carbine alarm system. To perform multi-car programming, all transmitters must first be marked to indicate which car/alarm they are for. -
Page 13: Step 10: Speciality Feature And Optional Equipment Testing
Step 10: Speciality Feature and Optional Equipment Testing Each specialty feature listed operates in the same manner regardless of the alarm model. Test each feature by following the procedures enclosed to insure proper operation. Remote Panic: 1. Press and hold the arm/disarm (for regular transmitters) or panic button (for code hopping transmitter) down for approximately 3 seconds. - Page 14 Step 10: Speciality Feature and Optional Equipment Testing Valet Operation: (The security system is already disarmed) 1. Make sure that the valet switch is in the “off” position. 2. Turn the ignition key to the “on” position. 3. Within 5 seconds of turning the ignition key, place the valet switch to the “on” position. 4.
-
Page 15: Specifications
Step 10: Speciality Feature and Optional Equipment Testing RF Tamper Re-Arm: Note: This feature is activated automatically when the alarm is programmed for automatic arming. See “Remote Feature Programming” for details. (Page 10-11) 1. Alarm must be programmed for automatic arming. 2. -
Page 16: Wiring Diagrams
Wiring Diagram PLUS-3000 Auxilliary Interrupt Green Wire Loop Back View of Housing Cut to Eliminate Socket (Orange) Loop Wires Current Sense Trigger (See Optional Accessory Connection) Plug-In LED White Wire Loop (White) Cut to Prevent the Valet/Override Socket Door Locks from Locking (Blue) Power when Alarm Automatically...
