Instruction Manual
Battery Charger Extender
Model 117435, Battery Charger Extender (North America only)
Do not use 117435 extender with Australian 4-bay
charger (120107).
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
CAUTION
The Graco Matrix Battery Charger Extender must
only be used with the Matrix Fluid Management Sys-
tem. The Graco warranty is void if the battery
charger, extender, or batteries are used with a
non-Graco product.
Contents
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manual Conventions . . . . . . . . . . . . . . . . . . . . . . . . .2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . .6
Graco Phone Numbers . . . . . . . . . . . . . . . . . . . . . . .6
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2002, Graco Inc. is registered to I.S. EN ISO 9001
309499 rev.C
Model 117435 Battery Charger
Extension Shown
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Matrix 117435
-
Page 1: Table Of Contents
Instruction Manual Battery Charger Extender 309499 rev.C Model 117435, Battery Charger Extender (North America only) Do not use 117435 extender with Australian 4-bay charger (120107). Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. CAUTION... -
Page 2: Symbols
Symbols Symbols Manual Conventions CAUTION WARNING CAUTION indicates a potentially hazardous situation which, if not avoided, may result in property damage or destruction of equipment. WARNING indicates a potentially hazardous situation Note which, if not avoided, could result in death or serious injury. -
Page 3: Overview
Battery Charger Model 117429. Adding added to Model 117429 is two, turning the four bay into a one or two extenders (Part # 117435) can turn a four bay six bay charger. unit (Model 117429) into a five or six bay unit. -
Page 4: Assembly
Installation Assembly Note: The charging board (H) may need to be reposi- tioned within the charger cover (G) before the charger 1. Remove the extender unit parts from the shipping cover can be attached to the flat metal plate. Slide the box. -
Page 5: Parts
Parts Parts Part No. 117435 Extension Unit 6-32 x 1/2 in. Phillips Head Screws (2) Technical Data Weight Single Bay Extender 2.12 lbs (0.96 kg) Operating Voltage 120 VAC Operating Temperature Range 0° to 50°C (32°F to 122°F) Storage Humidity Range... -
Page 6: Graco Standard Warranty
Graco Standard Warranty Graco warrants all equipment manufactured by Graco and bearing its name to be free from defects in material and workmanship on the date of sale by an authorized Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twenty-four months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
