Table of Contents
Summary of Contents for ARJAY ENGINEERING 2852-PCD
- Page 1 MODEL 2852-PCD Plugged Chute Detector User Manual Technical Support Continental North America Toll Free 1-(800) 387-9487 Ph: +1 (905) 829-2418 Fx: +1 (905) 829-4701 A Product of Arjay Engineering Ltd. Oakville, Ontario, Canada www.ArjayEng.com MODEL: HARDWARE NO.: SOFTWARE NO.: SERIAL NO.:...
-
Page 2: Table Of Contents
Model: 2852-PCD User Manual Rev: 2.1 TABLE OF CONTENTS INSTRUMENT OVERVIEW .................... 3 Features ......................3 Model Number vs. Voltage Input ................ 3 Specifications ..................... 4 INSTALLATION ....................... 6 ... -
Page 3: Instrument Overview
The sensor uses an RF Capacitance technology that does not require moving parts. The complete 2852-PCD system consists of the flush mount sensor, the PMC card mounted at the sensor, and the 2852 controller. -
Page 4: Specifications
Model: 2852-PCD User Manual Rev: 2.1 Specifications 12 VDC +15% /-10% or 24 VDC +15% /-10%, 250mA maximum Power Input: 100VAC – 240VAC +/- 10%, 50/60 Hz, 150mA maximum Note: DC input models must be supplied by Limited Energy power source. - Page 5 Model: 2852-PCD User Manual Rev: 2.1 Refer to Dimensional Drawing Mechanical Specification: Enclosure Rating Type 4 / IP65 Painted Steel (Blue) Type 4x / IP66 Polycarbonate (Gray) Type 4x / IP66 316 Stainless Steel Options on Enclosure Buzzer Pilot Light OR Strobe/Beacon Custom alarms ...
-
Page 6: Installation
User Manual Rev: 2.1 INSTALLATION NOTE: If any damage to the instrument is found, please notify an Arjay Engineering representative as soon as possible prior to installation. Controller Installation Choose the mounting location in accordance with good instrument practice. Extremes of ambient temperature and vibration should be avoided (see specifications and installation drawing). -
Page 7: Sensor Installation
Model: 2852-PCD User Manual Rev: 2.1 Sensor Installation The controller is tuned to the capacitance field in front of the sensor during normal process conditions. A plugged condition will displace the air & product mix in front of the sensor with solid product. -
Page 8: Electrical Installation
Model: 2852-PCD User Manual Rev: 2.1 Electrical Installation Figure 1 – Electrical Installation Overview TB1/TB2 - Relay Output 2 SPDT relay, Dry, N.O. Contact 5A @ 250 VAC (Resistive) and N.C. Contact 3A @ 250VAC (Resistive), selectable failsafe or non-failsafe, selectable high or low acting alarm, programmable time delay: 0 –... -
Page 9: Input / Output Terminal Specification
Model: 2852-PCD User Manual Rev: 2.1 2.3.1 Input / Output Terminal Specification Input Terminals – Power Source Terminal Overvoltage Rated Voltage (V) Rated ___ HZ or Specified category Current/power Mains (A/W/VA) fluctuation 100-240V 150mA 50/60Hz 12 OR 24V 250mA ... -
Page 10: Glossary Of Symbols
Model: 2852-PCD User Manual Rev: 2.1 Glossary of Symbols Attention, consult accompanying documents Attention, veuillez consulter les documents ci-joints. Protective Earth Fuse Terre de protection Coupe-circuit; fusible Direct Current (DC) Normally open relay contacts Courant continu Contacts travail Normally closed relay contacts... -
Page 11: Startup And Calibration
The unit is pre-configured and tested at the factory. However, a quick field calibration is required after power up to tune the sensor to the installation conditions. See section 3.3 to calibrate the 2852-PCD. Menu Flow Chart Background Information The control setup, diagnostics, and calibration are accessed using the display and keypad on the controller. -
Page 12: Data Entry
Normal Screen 3.3.1 Site Calibration A factory pre-configuration and set-up has been defaulted into the 2852-PCD. As such, a user set-up is not required in the field. A basic calibration is only required. Be sure the sensor is wired and installed into it’s final location before calibrating. The process must be operating so that the sensor face is looking at normal process conditions. -
Page 13: Setup And Alarms
Model: 2852-PCD User Manual Rev: 2.1 SETUP ALARMS 2852 Controller Setup The 2852 controller has the following Setup parameters: 1. Sensitivity The sensitivity determines the amount of pF change required to cause an alarm. The factory default setting is 1.0 pF. This is the most sensitive setting. Increasing the pF value will increase the amount of product required to cause an alarm. -
Page 14: 2852 Controller Network
Model: 2852-PCD User Manual Rev: 2.1 2852 Controller Network The 2852 Controller may be monitored and calibrated via RS-485 protocol compatible digital communications. Typical features are: 1. Ease of wiring in multiple level point monitoring: Up to 255 Model 2852's (or other Arjay 2800 Series level monitors) may be connected together... -
Page 15: 2800 Series Modbus Register Mapping
Model: 2852-PCD User Manual Rev: 2.1 4.3.2 2800 Series Modbus Register Mapping Zero No. of Based DESCRIPTION TYPE 40001 Serial Number float 40003 Hardware Rev / Software Rev byte 40004 Sensitivity / Mode byte 40005 Instrument Status 40006 Model / Modbus Address... -
Page 16: Maintenance
Model: 2852-PCD User Manual Rev: 2.1 MAINTENANCE There is no routine cleaning required for this controller. -
Page 17: Troubleshooting
Adjust the sensitivity to the next higher value. Test after any changes to confirm an alarm Make sure the product materials and moisture conditions are the same as when calibrated. ARJAY ENGINEERING TECHNICAL SUPPORT (800) 387-9487 +1 (905) 829-2418 www.arjayeng.com... -
Page 18: Flow Charts
Model: 2852-PCD User Manual Rev: 2.1 FLOW CHARTS... - Page 19 Model: 2852-PCD User Manual Rev: 2.1...
- Page 20 Model: 2852-PCD User Manual Rev: 2.1...
