Summary of Contents for Toyota TACOMA 2022
- Page 1 QUICK REFERENCE GUIDE 2022...
- Page 2 Owner’s Manual. Each box contains operating instructions to help you avoid injury or equipment malfunction. All information in this Quick Reference Guide is current at the time of printing. Toyota reserves the right to make changes at any time without notice.
- Page 3 Rear differential lock BLUETOOTH ® DEVICE 46-48 PAIRING SECTION Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. ® HomeLink is a registered trademark of Gentex Corporation.
- Page 4 OVERVIEW Instrument panel Voice command switch Meter control switches Audio control switches Dynamic Radar Cruise Control (DRCC) vehicle-to-vehicle distance switch Dynamic Radar Cruise Control (DRCC) switch Lane Departure Alert Telephone control Steering wheel controls (LDA) switch switches Windshield wiper and washer control Multi-Information Display (MID) Meters Headlight/turn signal/front fog...
- Page 5 If equipped. Manual transmission only. Automatic transmission only. For details, refer to the “Navigation and Multimedia System Owner’s Manual” or visit www.toyota.com/ audio-multimedia for additional resources. Four-wheel drive control switch Audio/navigation system Emergency flasher switch Air conditioning/heating controls Qi Wireless charger switch...
- Page 6 OVERVIEW Instrument cluster Multi-Information Display (MID) Outside temperature Odometer/trip meter Speedometer Tachometer Engine coolant temperature gauge Fuel gauge Shift position and shift range (vehicles with an automatic transmission) “ODO/TRIP” and instrument panel light control button Service indicators and warning lights Indicator symbols For details, refer to “Warning lights and indicators,”...
- Page 7 If the indicator does not turn off within a few seconds of starting the engine, there may be a malfunction. Have the vehicle inspected by your Toyota dealer. If the indicator flashes, there may be a malfunction. Refer to the Owner’s Manual.
- Page 8 OVERVIEW Keyless entry (if equipped) UNLOCKING OPERATION Smart Key Carry Smart Key remote Driver door unlock* Grasp Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. LOCKING OPERATION Smart Key Carry Smart...
- Page 9 Smart Key system (if equipped) START FUNCTION Push NOTE: The Smart Key must be carried to enable the start function. With the shift lever in Park and the brake pedal depressed, push the power button. POWER (WITHOUT STARTING ENGINE) Without depressing the brake pedal, pressing the power button will change the operation mode in succession from: Off - All systems OFF.
- Page 10 OVERVIEW Fuel tank door release and cap Turn to open Pull NOTE: Tighten until one click is heard. If the cap is not locked or tightened enough, the Check Engine indicator “ ” may illuminate. Hood release Pull Pull up latch and raise hood Instrument panel light control Brightness control...
- Page 11 Engine maintenance 4 CYLINDER (2TR-FE) ENGINE Engine oil filler cap Engine coolant reservoir Power steering fluid reservoir Washer fluid tank Engine oil level dipstick 6 CYLINDER (2GR-FKS) ENGINE Engine oil level dipstick Engine coolant reservoir Power steering fluid reservoir Washer fluid tank Engine oil filler cap NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance.
- Page 12 FEATURES & OPERATIONS Automatic transmission (if equipped) + (“S” mode) Park* Reverse Neutral Drive “S” mode - (“S” mode) * The vehicle must be on and the brake pedal depressed to shift from Park. “S” MODE (upshifting) (downshifting) The initial shift range in “S” mode is set automatically to 5 or 4 according to vehicle speed.
- Page 13 Manual transmission (if equipped) Four-wheel drive (if equipped) Turn Turn Push and turn High speed (2WD) Normal driving on dry hard-surfaced roads. High speed (4WD) For driving only on roads that permit the tires to slide, like off-road, icy or snow- covered roads.
- Page 14 FEATURES & OPERATIONS Multi-terrain select (if equipped) Multi-terrain Select indicator Mode indicator Mode selector dial Multi-terrain Select on/off switch Multi-Information Display (MID) Improves driveability in off-road situations. Select one of five modes that most closely matches the terrain on which you are driving. Brake control can be optimized in accordance with the selected mode.
- Page 15 Clutch start cancel switch (if equipped) The vehicle must be in the “ON” position. The clutch start cancel switch allows you to start the engine and drive out of difficult situations where the vehicle should not be allowed to roll backwards. Refer to the Owner’s Manual for more information.
- Page 16 FEATURES & OPERATIONS Seats-Head restraints ACCESS CAB MODELS Separate seats-Front Separate-Rear Vertical adjustment Folding Pull Lock release button Lock release lever DOUBLE CAB MODELS Separate seats-Front Center-Rear Outer-Rear Vertical adjustment Vertical adjustment Folding Lock release button Lock release button Lock release button Seats adjustments-Front MANUAL SEAT POWER SEAT* (DRIVER’S SIDE ONLY)
- Page 17 Rear seats-Folding RAISING - ACCESS CAB MODELS Pull Stow the seat belt buckles. Raise the bottom cushion up while pulling the lever until it locks. FOLDING - DOUBLE CAB MODELS Remove head restraints and lift up Pass the seat belt through the seat the bottom cushion.
- Page 18 Automatic High Beams (AHB) system Automatically switches between high and low beams as appropriate to enhance vision at night. Refer to Toyota Safety Sense™ P (TSS-P) in this guide or the Owner’s Manual for more details on the Automatic High Beams feature.
- Page 19 FRONT FOG LIGHTS (IF EQUIPPED) TURNING SIGNALS Right turn Lane change* Lane change* Left turn Front fog lights come on when the parking * Move lever partway and lights are on or the headlights are on in low release. The signals will flash beam.
- Page 20 Refer to the “Navigation and Multimedia System Owner’s Manual” or visit www.toyota.com/audio-multimedia for additional resources. NOTE: Always use safe driving practices and follow all traffic rules. ® Garage door opener (HomeLink...
- Page 21 Steering wheel switches ® & telephone controls (Bluetooth “ ” Use to search within the Volume controls selected audio feature. “MODE/HOLD” Push to change audio mode. Push and hold to mute or pause the audio. Voice command switch Start call End call Type A (without moonroof) Type B (with moonroof)
- Page 22 FEATURES & OPERATIONS USB media port Connecting a compatible device and cable into the USB media port will support charging and music playback through the audio multimedia system. USB charge ports (Charge-only) The vehicle must be in the “ACC” or “ON” position (without Smart Key) / “ACCESSORY”...
- Page 23 Qi Wireless charger (if equipped) Charging can only be performed with the vehicle in the “ACC” or “ON” position (without Smart Key)/ ACCESSORY or IGNITION ON mode (with Smart Key) and only on mobile devices with the “ ” logo. Place (2) Press Place device nearest in the center of charging...
- Page 24 FEATURES & OPERATIONS Multi-Information Display (MID) “ ” “ ” Enter/Set: Press to select an item/change Press to enter/set, pages press and hold to reset Return to the previous screen Switch menus/Display top screen Press meter control switches to change and select information in the following: Drive information Navigation system-linked display (if equipped) Audio system-linked display...
- Page 25 Air conditioning/heating AUTOMATIC AIR CONDITIONING (IF EQUIPPED) Display Fan speed Air flow vent mode Temperature (driver and passenger) Selectors and switches Fan speed control Windshield defogger (outside air only) Recirculate cabin air (outside air when OFF) Temperature control (driver side) Temperature control (passenger side) Outside rear view mirror defogger...
- Page 26 FEATURES & OPERATIONS Heated seats (if equipped) Driver side Passenger side Press to Hi (ON)>Mid>Lo>OFF The vehicle must be on for use. Clock Select to change the time zone. Select to set daylight saving time ON/OFF/AUTO Select to set automatic adjustment of the clock by GPS on/off.
- Page 27 Power outlet-12V DC The vehicle must be in the “ACC” or “ON” position (without Smart Key) / “ACCESSORY” or ”IGNITION ON” mode (with Smart Key) for use. Power outlet-120V AC (if equipped) Main switch Power outlet socket (deck) 120 V AC/100 W 120 V AC/400 W The power outlet can be used when the engine is running.
- Page 28 FEATURES & OPERATIONS Active traction control (if equipped) The active traction control system automatically helps prevent the spinning of four wheels when the vehicle is started or accelerated on slippery road surfaces. Refer to the Owner’s Manual for more information. Vehicle Stability Control (VSC)/TRAC/ Trailer sway control OFF switch The VSC OFF switch is used to switch between modes related to the TRAC, VSC...
- Page 29 Rear differential lock (if equipped) Use ONLY when wheel spinning occurs in a ditch, or on slippery or unpaved surfaces. DO NOT USE THE REAR DIFFERENTIAL LOCK IN CONDITIONS OTHER THAN THOSE SPECIFIED IN THE OWNER’S MANUAL. UNLOCK THE DIFFERENTIAL ONCE THE VEHICLE MOVES OUT OF THE TROUBLE SPOT. Refer to your Owner’s Manual for complete details on this system before attempting to use it.
- Page 30 FEATURES & OPERATIONS Power Sliding Rear window (if equipped) Open Close The vehicle must be on for use. Intuitive parking assist (if equipped) Push Rear corner Rear corner Rear sensor sensor center sensor If the sensors detect an obstacle, the buzzer and MID inform the driver of the approximate position and distance of the obstacle by illuminating continuously (near) or blinking intermittently (far).
- Page 31 Rear view monitor system The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The camera for the rear view monitor system is integrated in the tailgate handle. To adjust the image on the rear view monitor screen, press the “MENU” button and select “Display.”...
- Page 32 TOYOTA SAFETY SENSE ™ Quick overview-Toyota Safety Sense™ P (TSS-P) Toyota Safety Sense P (TSS-P) is a set of active safety technologies designed ™ to help mitigate or prevent collisions across a wide range of traffic situations, in certain conditions. TSS-P is designed to help support the driver’s awareness, decision making and vehicle operation contributing to a safe driving experience.
- Page 33 Refer to the Toyota Owner’s Manual for a list of additional situations in which the system may not operate properly. See www.toyota.com/safety-sense for more information.
- Page 34 As part of the Pre-Collision System, this function is also designed to first provide an alert and then automatic braking if needed. Refer to the Toyota Owner’s Manual for additional limitations and information. CHANGING PCS ALERT TIMING Middle...
- Page 35 Departure Alert (LDA) is designed to issue an audio/visual alert if an inadvertent lane departure is detected. See www.toyota.com/safety-sense for more information. Refer to the Toyota Owner’s Manual for a list of additional situations in which the system operation may be limited.
- Page 36 TOYOTA SAFETY SENSE ™ TURNING THE LDA SYSTEM ON/OFF Lane Departure Alert Unavailable Below Approx. 32 MPH Press the LDA switch to turn the LDA system on. Depress again to turn it off. Note: Operation of the LDA system and setting adjustments continues in the same condition regardless of Ignition cycle until changed by the driver or the system is reset.
- Page 37 LANE DEPARTURE ALERT (CONTINUED) The LDA function displays when the Multi-Information Display (MID) is switched to the driving assist system information screen. (1) The system displays solid white lines on the LDA indicator when visible lane markers on the road are detected. A side flashes orange to alert the driver when the vehicle deviates from its lane.
- Page 38 Note: Operation of the LDA system and setting adjustments continues in the same condition regardless of Ignition cycle until changed by the driver or the system is reset. Refer to the Toyota Owner’s Manual for additional information on LDA operation, settings adjustments, limitations, and precautions before attempting to use it.
- Page 39 See www.toyota.com/safety-sense for more information. Refer to the Toyota Owner’s Manual for a list of additional situations in which the system operation may be limited. Indicators...
- Page 40 TOYOTA SAFETY SENSE ™ ADJUSTING DISTANCE LONG SHORT MIDDLE (default setting) To change the vehicle-to- Preceding vehicle distance: vehicle mark Push the “ ” switch to cycle through the settings, which will change progressively. This mode employs a radar sensor to detect the presence of a preceding vehicle...
- Page 41 SETTING CONSTANT SPEED (CRUISE) CONTROL To adjust speed or cancel, see steps (2) and (3) of ADJUSTING SET SPEED on page 37. Refer to the Toyota Owner’s Manual for additional information on DRCC operation, settings adjustments, limitations, and precautions before attempting to use it.
- Page 42 See www.toyota.com/safety-sense for more information. Refer to the Toyota Owner’s Manual for additional information on AHB operation, settings adjustments, limitations, and precautions before attempting to use it. ACTIVATING THE AHB SYSTEM (1) Push the lever away from you with the headlight switch is in the “...
- Page 43 Positioning System (GPS) data and embedded cellular technology to provide safety and security features to subscribers. Safety Connect is staffed with live agents at the Toyota response center, which operates 24 hours per day, 7 days per week. Services for subscribers include: •...
- Page 44 Multi-Information Display. (Available on select grades.) If the tire pressure indicator flashes for 1 minute and then remains on, take the vehicle to your local Toyota dealer. Refer to the load label on the door jamb or the Owner’s Manual for tire inflation specifications.
- Page 45 Spare tire & tools TOOL LOCATION Double Cab models -under the rear seat Tool bag Jack Access Cab models -under the rear seat Tool bag Jack REMOVING THE SPARE TIRE Insert the jack handle end Assemble the jack handle. into the lowering screw. Turn the jack handle counterclockwise.
- Page 46 ANTI-LOCK BRAKE SYSTEM (ABS) Toyota’s Anti-lock Brake System detects which wheels are locking up and limits wheel lockup by “pulsing” each wheel’s brakes independently. Pulsing releases brake pressure repeatedly for fractions of a second. This helps the tires attain the traction that current road conditions will allow, helping you to stay in directional control.
- Page 47 Traction Control helps maintain traction on loose gravel and wet, icy, or uneven surfaces by applying brake force to the spinning wheel(s). Toyota’s TRAC sensors are activated when one of the drive wheels starts to slip. TRAC limits engine output and applies the brakes to the spinning wheel. This transfers power to the wheels that still have traction to help keep you on track.
- Page 48 BLUETOOTH DEVICE PAIRING ® SECTION Do not attempt the Bluetooth Pairing process while driving. ®...
- Page 49 Bluetooth Pairing for your phone Pairing your phone is the first step in connecting with your Toyota. This pairing process is quick and easy. All you have to do is setup the phone and multimedia system to form a connection.
- Page 50 BLUETOOTH DEVICE PAIRING ® ® Bluetooth Pairing for your phone (cont.) "Connecting" displays while Enable Notifications (text STEP 6 STEP 7 phone is forming the connection message). While pairing your to the multimedia system. phone, a message will be displayed: "You may need to allow message access on your phone."...
- Page 52 Quick Reference Guide 2022 00505QRG22TAC Printed in U.S.A. 8/21 toyota.com 21-MKG-15675...
