etrailer e98988 Owner's Manual & Safety Instructions

Atv utility 12 v electric winch - 2500 lb.

Advertisement

Quick Links

LIT-00114, Rev -
e98988
etrailer.com ATV Utility 12 V
Electric Winch - 2500 Lb.
e98988

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e98988 and is the answer not in the manual?

Questions and answers

Summary of Contents for etrailer e98988

  • Page 1 LIT-00114, Rev - e98988 etrailer.com ATV Utility 12 V Electric Winch - 2500 Lb. e98988...
  • Page 2: Specifications

    43.1′ (13.1m) 1184 lb. (537 kg.) 50′ (15.2m) First Layer of Wire Rope Performance Line Pull Line Speed Amp Draw lb. (kg.) fpm (mpm) (@ 12V) 13.3 (4.1) 1000 (454) (2.5) 2000 (907) (1.2) 2500 (1134) (0.8) e98988 Page 2...
  • Page 3 Classifies the degrees of protection Fingers may be caught and get provided against the intrusion of solid pulled into fairlead or drum. objects, dust, accidental contact, and water. Pull hook using strap only. Grade 8 A fastener strength rating. e98988 Page 3...
  • Page 4: Important Safety Information

    13. Install winch and fairlead in underwind orientation, so 6. Do not route electrical cables near sharp edges, that the winch rope enters and exits the moving parts, or hot equipment. winch at the bottom of the drum. e98988 Page 4...
  • Page 5: Operation Precautions

    16. Do not operate winch if less than 5 full turns of winch rope are on drum. 17. Ensure that winch rope is taut before beginning winching operation. Failure to do so can lead to binding of the winch rope on the drum. SAVE THESE INSTRUCTIONS. Page 5 e98988...
  • Page 6: Installation And Setup

    Wires between winch components can be routed without contacting sharp edges, moving parts, or 3. Secure in place with mounting screws. hot equipment. b. Normal operation of vehicle components are not affected. c. Backside of mounting holes are clear of equipment and obstruction. Page 6 e98988...
  • Page 7: Clutch Operation

    Pull clutch knob out. the clutch is engaged. b. Turn it 90° while it is pulled out, then release it. Shaft If the pin rests on top of the end of the Drum drum the clutch is released. e98988 Page 7...
  • Page 8: Troubleshooting

    3. Use only supplied power cords. 3. Incorrect power cords. Motor runs in one 1. Defective or stuck solenoid. 1. Tap solenoid to loosen contacts. direction only. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. Page 8 e98988...
