- Page 1 Smart Button - SBTZB-110 Technical manual Revised 29.07.2021...
-
Page 2: Table Of Contents
Smart Button - SBTZB-110 – Technical manual Content Cautionary notes ............................................5 Features ................................................ 6 Smart Button - SBTZB-110 ......................................6 Key features ............................................6 Endpoints............................................... 7 ZigBee Device Object (ZDO) ......................................7 Combined Interface .......................................... 7 IAS Zone ..............................................7 Develco Utility ............................................ - Page 3 Smart Button - SBTZB-110 – Technical manual 4.2.5.2 Commands ..........................................12 4.2.5.3 OTA Upgrade Messages Diagram ................................13 4.2.6 Time – Cluster id 0x000A ....................................14 4.2.6.1 Attribute ..........................................14 IAS Zone Device – EP 0x23 ......................................15 4.3.1 IAS Zone - Cluster id 0x0500 ..................................15 4.3.1.1...
- Page 4 Develco Products assumes no responsibility for any errors, which may appear in this manual. Furthermore, Develco Products reserves the right to alter the hardware, software, and/or specifications detailed herein at any time without notice, and Develco Products does not make any commitment to update the information contained herein.
-
Page 5: Cautionary Notes
Develco Products A/S reserves the right to make changes to any product to improve reliability without further notice. Develco Products A/S does not assume any liability arising out of the application or use of any product or circuit described herein; neither does it convey any license under patent rights or the rights of third parties. -
Page 6: Features
Smart Button - SBTZB-110 – Technical manual 2 Features Smart Button - SBTZB-110 The Smart Button is a programmable, Zigbee-based button that can be used for multiple purposes. For example, the Smart Button can be used as a door lock button, or as a switch for lights or “all on/ off” functionality that enables the user to switch multiple home appliances on or off in the press of a single button. -
Page 7: Endpoints
Smart Button - SBTZB-110 – Technical manual 3 Endpoints The device implements the following standard HA devices on different end points. ZigBee Device Object (ZDO) • End point number 0x00 • Application profile Id 0x0000 • Application device Id 0x0000 •... -
Page 8: Supported Clusters
The ZCL “General Function Domain” clusters in this section are implemented as server clusters. 4.1.1 Basic – Cluster id 0x0000 Only the first set has mandatory attributes, also the optional attributes that can be relevant to a Develco device are all in set 0x000. -
Page 9: Combined Interface - Ep 0X20
The On/Off cluster has 1 attribute set defined. The cluster is implemented as a client cluster. 4.2.2.1 On/Off Cluster – Manufacture Specific Attributes The On/Off cluster support the following manufacture specific attributes NOTE: ZCL header setting – Manufacturer code for Develco Products is 0x1015 Name Type Range Relevance and ref. -
Page 10: Binary Input Cluster - Cluster Id 0X000F
Not used 4.2.3.2 Manufacture Specific Attribute The Binary Input cluster support the following manufacture specific attributes. NOTE: ZCL header setting – Manufacturer code for Develco Products is 0x1015 Name Type Relevance and ref. Enables the IAS Zone endpoint (0x23) and enrolls the button as the chosen device type. -
Page 11: Poll Control - Cluster Id 0X0020
Smart Button - SBTZB-110 – Technical manual 4.2.4 Poll Control - Cluster id 0x0020 The poll control cluster is described in ZigBee Cluster Library Specification This cluster provides a mechanism for the management of an end device’s MAC Data Request rate. For the purposes of this cluster, the term “poll”... -
Page 12: Attributes
Smart Button - SBTZB-110 – Technical manual 4.2.5.1 Attributes Name Type Range Man/Opt Relevance and ref. IEEE 0x0000 UpgradeServerID Address 0x0001 FileOffset Uint32 Type range 0x0002 CurrentFileVersion Uint32 Type range 0x0003 CurrentZigBeeStackVersion Uint16 Type range 0x0004 DownloadedFileVersion Uint32 Type range... -
Page 13: Ota Upgrade Messages Diagram
Smart Button - SBTZB-110 – Technical manual 4.2.5.3 OTA Upgrade Messages Diagram Develco Products A/S Tangen 6 http://develcoproducts.com DK-8200 Aarhus N info@develcoproducts.com... -
Page 14: Time - Cluster Id 0X000A
Smart Button - SBTZB-110 – Technical manual 4.2.6 Time – Cluster id 0x000A The Time cluster is a general cluster for time it is based on a UTC time in seconds since 0 hrs 0 mins 0 sec on 1st January 2000. -
Page 15: Ias Zone Device - Ep 0X23
Smart Button - SBTZB-110 – Technical manual 4.3 IAS Zone Device – EP 0x23 4.3.1 IAS Zone - Cluster id 0x0500 The IAS Zone cluster is described in ZigBee Cluster Library Specification. 4.3.1.1 Attribute Name Type Man/Opt Relevance and ref. -
Page 16: Commands
Smart Button - SBTZB-110 – Technical manual 4.3.1.2 Commands The IAS Zone cluster has 2 commands as server. Name Payload Man/Opt Relevance and ref. Zone Status Change 0x00 Uint16 – bit mask Notification Bits Data type 16 bit enum UINT16... -
Page 17: Mmi User Guide
Smart Button - SBTZB-110 – Technical manual 5 MMI user guide The MMI menu allows the user to perform various operations on the device. Its use is explained in section 5.2 Push Button Menu Accessing and re-enabling MMI menu The MMI menu is accessible while the device is initially scanning for a network. When the device joins a network, the MMI menu is accessible for an additional 60 seconds. -
Page 18: Ez Mode - Initiator
Smart Button - SBTZB-110 – Technical manual 5.2.1 EZ mode - Initiator If the devices is not on the network EZ-Mode Network Steering is invoked when the user enter this menu. The led blinks once every 1 sec until the devices has joined the network. If the device was already on the network it will broadcast the PermitJoin messages. - Page 19 Smart Button - SBTZB-110 – Technical manual If a device has joined a network and is powered down, it will attempt to rejoin this network upon power up. For the first 30 seconds hereafter, the device will be available for communication. This time can be expanded using the poll control cluster functionality.
-
Page 20: General Network Behaviour
Smart Button - SBTZB-110 – Technical manual 6 General network behaviour Installation When the device is virgin and powered for the first time it will start looking for a ZigBee PAN Coordinator or router to join. The device will scan each ZigBee channel starting from 11 to 24. The LED will flash once every second until it joins a device. -
Page 21: Specifications
Smart Button - SBTZB-110 – Technical manual 7 Specifications General Dimensions (L x B x H) 40 x 53 x 10,8 mm Colour White – Optional Orange marking on the button Battery Battery: CR2450 (Coin Cell) Battery life Up to 3 year... -
Page 22: Contact Information
Smart Button - SBTZB-110 – Technical manual 8 Contact Information Technical support: Please contact Develco Products for support. products@develcoproducts.com Sales: Please contact Develco Products for information on prices, availability, and lead time. info@develcoproducts.com Develco Products A/S Tangen 6 http://develcoproducts.com DK-8200 Aarhus N...
