e-Sense Actilume
Functions and benefits
• Actilume is a control system based on the DALI protocol for
maximum comfort and up to 75% energy conservation. This
allows for a quick return on your investment.
• Actilume is a plug and play system, which does not require the
user to be specially trained in lighting control.
• Actilume consists of three small special sensors in a single case,
which are connected to a control unit with preprogrammed
modes.
• The two most common system functions, open plan office or
office room, can be selected with a push button on the sensor
unit.
• The light sensor is adapted and sensitive to visible light, like
the human eye. This allows for automatic energy conservation
by means of daylight adjustment, with no inconvenient side
effects for the user.
Deployment with service button on the sensor
Startup
• Requirement: Fixture correctly positioned, e.g. over the work-
space.
• Power up the fixture.
• The light will switch on after approximately 15 seconds via the
proximity sensor.
Automatic setup of daylight adjustment to approx. 5–600 lux
1. Press down the button on the sensor for more than three se-
conds, or until the light flashes once. The light will now adjust
to approximately 80 %. Make sure there is nothing preventing
the sensor from reading a neutral surface.
NOTE! No interference from daylight!
2. After 30 seconds, the Actilume system will save the light
level to a new reference value, or setpoint. This is indicated by
a flashing light. The 30-second delay is there to allow time for
the user and any items, such as a ladder, to be moved out of
the way.
Manual setting of daylight
A new value can be saved by adjusting the light manually to
the desired level using a pull cord, push button or IR transmit-
ter, then quickly pressing the service button within 30 seconds.
Instructions for manually setting a new value with an IR trans-
mitter can be found on the following pages.
Dokumentet kan ändras utan föregående meddelande. Subject to change without notice.
• The proximity sensor is very sensitive to human movement,
and, in combination with an optional time delay, it is adapted
for optimum performance in an office environment.
• The lighting can easily be operated manually using one or
more spring-return push buttons or pull switches. On/off and
dimming functions are available. The same functions are also
available with remote control. In this way, the light can always
be adjusted to the user's preferences.
• In addition, Actilume can easily be programmed to additional
special modes. These are specially designed in line with the
latest lighting installation directive, EN 12464. These additional
modes are easily programmable with a push of the IRT 9090/00
IR transmitter. The Actilume system always switches to the
maximum light level before daylight adjustment begins.
After automatic/manual setup
One of the two standard modes (Mode 1 or Mode 2) can now
be selected easily in Actilume with a press of the button on the
sensor unit (press for less than 3 seconds). When the button is
released, the light will flash once or twice.
