  • Page 1 Baxter (Model 9100) Installation Manual – – … …...
  • Page 2 Note: There are two different sets of pillars, large and small connectors. Place the similar pillars diagonally across from each other.
  • Page 3 1 Getting Started Baxter is the world’s smallest automated desktop loading system that could fit perfectly in any office space. Its patented tray enables users to duplicate 12cm, 8cm and business-card discs with one easy turn of the disc pillars. ’...

  • Page 4: Hardware Installation

    2 Hardware Installation 1. Robotic Arm 2. Status indicator Green: Ready Yellow: Burning Red: Error 3. Output Bin 4. CD/DVD Burner 5. Input Bin 6. Rejects – Baxter discards rejects over the top of (3) Output Bin 1. Fan 2. USB Connector 3.
  • Page 5 Please follow the procedures to set up: Step 1: Install the four pillars on the Input bin Note: There are two different sets of pillars, large and small connectors. Place the similar pillars diagonally across from each other. Step 2: Attach the Input bin to Baxter Note: Before turning on the power, please make sure that you have tightly...
  • Page 6 Step 3: Rotate the four pillars as shown in the pictures below to use 12cm, 8cm and card size medias for duplication. 8 cm 12 cm Card Size Step 4: Connect your USB cable A-male end to Baxter USB slot and B-male end to your PC USB slot.
  • Page 7 Baxter Driver Installation After connecting the USB cable to Baxter and your PC, Turn on the power. You will receive a message “Found New Hardware” and the Hardware Wizard will start. (figure 1) figure 1 Highlight the install software automatically button. The driver will be installed automatically.
  • Page 8 After the driver installation is complete you will receive a complete message (figure 2) figure 2 Click Finish. Congratulations, Baxter has been installed.
  • Page 9 Install The Scribe PC Software Prior to Premium Utilities Installing the SCRIBE PC Software Insert the SCRIBE PC software CD. From the CD ROM drive of the computer, click Install SCRIBE Software. (fig. 1) Click Next (fig. 1). Accept the license agreement and click Next (fig.
  • Page 10 (fig. 4) Installing Riptastic Riptastic must be installed using the installation wizard prior to Scribe Launch. Insert the Riptastic CD. and run the setup file from windows. You will receive the message “ Would you like to install Riptastic now? (fig1) fig 1 Click Yes to Install.
  • Page 11 Click Next. The License agreement screen will appear. Click I agree. Next you the Customer Information Screen will appear.
  • Page 12 Type your name and company information and click next. Select the directory for the installation and click next. The confirm installation screen will appear. Click Next to continue.
  • Page 13 After the program installs, you will receive an Installation Completed message. Click the close button. The Riptastic Installation is complete. Launch Riptastic via Scribe Launch Tab. At startup install the supplied License number and Riptastic is ready to use. Software Questions Related to Riptastic Software, Please Visit http://www.riptastic.com/support/faq.htm Installing The Backup Platinum Software...
  • Page 14 Insert the Backup Platinum and run the setup file from windows. Backup Platinum must be installed using the installation wizard prior to Scribe Launch. The Welcome To Backup Platinum screen will appear. Click the Next button. You will receive the Read Me Screen.
  • Page 15 After reading, click the Next button. The license Agreement screen will appear. Highlight the I accept this agreement and click Next. The Choose Destination Folder will appear.
  • Page 16 Select the directory that you want to install Backup Platinum to and click next. The Start Installation Screen will appear. Click the Next button to continue. You will receive the Installation Complete message.
  • Page 17 Backup Platinum Has Been Installed. Launch Backup Platinum via Scribe Launch Tab. At startup install the supplied License number and Backup Platinum is ready to use. Software Questions Related to Backup Platinum Software, Please Visit http://www.backup-platinum.com/help.shtml...
  • Page 18 Troubleshooting 1. The Scribe PC program did not recognize Baxter. a. Check the power cable on the back of the Baxter. b. Make sure the power switch on Baxter is turned ON. c. Check the USB cable connection between Baxter loader and the host PC (page # 5).
