ZU-PW10W, ZU-PW70W
Power supply units for bmcm hardware
Well supplied.
The power supply units of the ZU-PW series pro-
vide a low voltage in the amount of 12V (ZU-
PW10W) and 24V (ZU-PW70W) to supply
bmcm devices.
Clearly safe.
Due to the galvanic isolation of the DC supply
voltage from the 230V AC power line, measure-
ment hardware and the PC are perfectly pro-
tected.
Functional diagram
Get connected.
The power supply units are delivered with a stan-
dard screw coupling. The assignment of the con-
nector goes with all bmcm devices that are sup-
plied by low voltage. If using a device without a
low voltage connector (e.g. AP8a), the screw
coupling must be removed from the power sup-
ply.
Advertisement
Summary of Contents for bmcm ZU-PW Series
- Page 1 ZU-PW10W, ZU-PW70W Power supply units for bmcm hardware Well supplied. The power supply units of the ZU-PW series pro- vide a low voltage in the amount of 12V (ZU- PW10W) and 24V (ZU-PW70W) to supply bmcm devices. Clearly safe. Get connected.
- Page 2 ZU-PW10W, ZU-PW70W Installation First connect the ZU-PW10W or ZU-PW70W to the power supply plug of the bmcm device. Attach the IEC cord of ZU-PW10W to the power supply and then plug the wall power supply or the mains plug into the socket outlet.
