Summary of Contents for SunDome XL48
- Page 1 USER MANUAL XL48 24383-0lA...
- Page 2 For 6 months from the date of purchase, SunDome will provide replacements for parts that prove to be defective in material or workmanship. Acrylic shields, fluorescent lamps, and lamp starters are excluded from this warranty.
-
Page 3: Table Of Contents
kome. _____________ _ Congratulations on your purchase of this technologically advanced sun tanning unit. It has been designed to provide years of dependable service for you. Please read all the instructions in this booklet before installing and using the unit. Always be sure to observe all safety precautions. - Page 4 ifety In fo rmation ______ � Labels are affixed on all systems to inform the user of possible dangers. Regulations are stated in 21 CFR, Section LABELING NOTICE: 1040.20, and require that all products manufactured after September 8, 1986 which use sunlamps must display the following: DANGER Ultraviolet radiation.
-
Page 5: Safety Information
Safety Information II Peou doire lV Peou foncee DANGER Rayonnement ultraviolet. Veuillez suivre !es instructions. Evitez une exposition excessive; tout comm e pour les rayons du soleil, une exposition excessive peut causer des blessures aux yeux et a la peau et provoquer des reactions allergiques. -
Page 6: Installation
Unpacking and Inspection As you unpack your boxes you should find the following: • Pedestal (box 1 ) The SunDome® comes in seven boxes. • Control Module (box 2) For ease of assembly, after inspection • Bag containing necessary assembly... -
Page 7: Pre-Installation Planning
Disc �� nect power before serv1cmg. the booth and could cause damage and void the warranty. • SunDome® XL48 operates from a 220V AC power source. The unit A CAUTION should be hardwired directly to a junction box on a dedicated circuit... -
Page 8: Tools Required
Installation - Tools Required Tools Required Hardware Inventory You will need the following tools to assemble your booth. Open the hardware bag and remove the hardware. Make sure you have the follow ing items. 1 /4-20 3/4" Hex Head Bolt Quantity - 9 1 /4"... - Page 9 Installation Hardware Inventory Hinge Locking Pin Additional hardware found in Box 7 Quantity - 4 #10-32 x 1 /2" Scre w Quantity - 4 Magnet Strike Plate #8-32 x 1/2" Screw Quantity 2 Quantity 4 Shim Washer #10 x 1 /2" Screw Quantity 4 Quantity - 4 �...
-
Page 10: Assembly Procedures
Assembl y Procedures ...,. Installation - Assembly Procedures Put the pedestal (found in box 7) in the general area you want the booth. Leave some space around the pedestal to work. FRONT... - Page 11 lmtallation - A,sembl:y Procedures • Parts needed: CONTROL MODULE Control Module (box 2) (box (with power cable on back) Left Module (box Right Module Remove these two screws and lift the grill from the unit Repeat other gr ills. LEFT MODULE NOTE: Wiring has been deleted to...
- Page 12 Parts needed: Control Module Left Module Right Module 9 1/4-20 x 3/4" Hex Head Bolts 9 - 1 /4" Flat Washers Attach modules to pedestal with three bolts and washers each, as shown. Attach the Control Module {center module) first, then the other two.
- Page 13 �•..,., --a:- Installation - Assembly Procedures � Parts needed: 2 - Joint Plates Remove these four 2 - Wire Clamps screws and secure the joint plate with them as shown at left. Secure one wire clamp to each ·oint plate. Joint Plate in place.
- Page 14 • Installation - Assembly Procedures Parts needed: 2- Inside Door Handles 4 - # 10-32 x 1 Screws 1 _______ _ If not al ready done, you wi I l need to remove the grills from both doors. 2 _______ _ Secure handles with screws through the double grid pattern on...
- Page 15 Parts needed: Grills (removed earlier) 2 Trim Profiles Reinstall the grills. Insert trim profiles into space between right and control module, and between left and control module. NOTE: Wiring has been deleted to show detai Is. Installation - Assembly Procedures •...
- Page 16 • Parts needed: Timer Assembly (box 7) Attach the Timer Bracket to the unit, as shown, Timer Bracket using two #8-32 x 1 /2" screws. Secure the Timer 4 - #8-32 x 3/4" Screws Box to the bracket with the same type screws, making sure the cables coming out the back of the Timer Box run over the bracket.
- Page 17 lmtallation - Assembly Procedures • Parts needed: Long Handles 8 - #10-32 x 1/2" Screws 4 #10-32 Nuts The handles attach with two screws to the top of the right and left modules and with two screws with nuts through the double grill wire at the bottom, as shown.
- Page 18 Imtallation Assembly Procedures • 1------ - Parts needed: lnsert bronze bushings Left Door (box 5) into hinge holes. Right Door (box 6) 2- - -- - - 4 - Hinge Bushings lnsert door hinge 4 - Hinge Locking Pins �� post into bronze bushing.
