Summary of Contents for SUN CAPSULE X7
-
Page 2: Fda Notice
Follow the exposure schedule based on the individual’s skin type. Failure to do so may result in over-exposure. The Sun Capsule is designed to be used by only one person at a time. This manual contains instructions for repairs, recommended replacement... -
Page 3: Exposure Schedule
THIS EXPOSURE SCHEDULE IS SPECIFIC TO THE SUNCAPSULE X7 54 LAMP 220WT VHR/HP DANGER - Ultraviolet radiation. Follow instructions. Avoid overexposure. As with natural " sunlight, overexposure can cause eye and skin injury and allergic reactions. Repeated exposure may cause premature aging of the skin and skin cancer. -
Page 4: Congratulations
Creative Marketing Concepts. Most importantly, when you have a question regarding the Sun Capsule, please do not hesitate to call us at 978-532-7517. We are here to help you make your Sun Capsule the most successful profit center within your business. Sincerely, Eugene G. -
Page 5: Table Of Contents
........Connecting a Data Base to the Sun Capsule . -
Page 6: Owners Manual
DANGER If you have been diagnosed by a doctor as being allergic to the sun or are currently taking photosensitive medications, consult your physician before using the Sun Capsule. IMPORTANT INFORMATION BEFORE YOU TAN Certain drugs do not mix well with ultraviolet light, either in its natural source or artificial. Below is a list of drugs, foods, and other substances which could make your skin super sensitive to sunlight;... -
Page 7: Allergic Reactions
– A good policy to adopt is; No children under 18 years of age without written consent from a parent, unless there are laws in your state or county that indicate otherwise. Keep young children away from the Sun Capsule. It is not a toy. -
Page 8: Connecting A Data Base To The Sun Capsule
Starting theTanning Session –The tanning session can be activated in two ways. (1)You can press the “START/STOP” button on the timer, or (2) your customer can press the “START” button in the Sun Capsule when they are ready to start tanning. -
Page 9: Venting/Ducting Of Fan
– It is important to keep the ambient temperature in the vicinity of the Sun Capsule between 73 F – 80 F . If you have very high ceilings or if your Sun Capsule sets in a very large open area, it may not be necessary to vent the exhaust air from the fan. -
Page 10: Tanningthe Lower Legs
REMEMBER: The tan produced by the Sun Capsule is a rich dark cosmetic tan. Make sure your customers understand that AN INDOORTAN WILL NOT PROVIDE ADEQUATE PROTECTION AGAINST OVER-EXPOSURETO NATURAL SUNLIGHT. -
Page 11: Lamp Rotation - 54 Lamp System
���� �������� ��� ���� �������� ���� ��� ������ � ��� ��� ���� �� ���������� �� ������ � ������� �������� �� ������������ ��� ����� ���� �� ���� ������������� ��� �� ��� ������ ����� ��� � ��� ��������� ���� �� ������ ������ ���... -
Page 12: Lamp Rotation - 49 Lamp System
���� �������� ��� ���� �������� ���� ��� ������ � ��� ��� ���� �� ���������� �� ������ � ������� �������� �� ������������ ��� ����� ���� �� ���� ������������� ��� �� ��� ������ ����� ��� � ��� ��������� ���� �� ������ ������ ���... -
Page 13: Lamp Rotation - 44 Lamp System
���� �������� ��� ���� �������� ���� ��� ������ � ��� ��� ���� �� ���������� �� ������ � ������� �������� �� ������������ ��� ����� ���� �� ���� ������������� ��� �� ��� ������ ����� ��� � ��� ��������� ���� �� ������ ������ ���... -
Page 14: Assembly Instructionstable Of Contents
....... . Installing #6 Lamp Fixture - Sun Capsule I Only . -
Page 15: Assembly Instructions
A voltage between 230 to 235 volts* is required WHEN THE UNIT IS RUNNING to attain peak performance. Most salons experience Sun Capsule I (Without Attached Dressing Room) a voltage drop of approximately 6 to 7 volts when the unit is in use. -
Page 16: Very Important
VERY IMPORTANT The 6 solid wall panels are used to create The Sun Capsule II has 11 corner pieces the dressing room portion of the unit. One including (2) reverse bend corner pieces of the solid panels has two pre-drilled and (1) doublewide corner piece. -
Page 17: Readyto Begin
CORNER CORNER RETAINING PIECE PIECE tanning lamps (and your customers) your MAGNET Sun Capsule must be kept a minimum of 6” MOUNTING HOLE PRE-DRILLED PRE-DRILLED away from any wall or obstruction. Keep in DOOR CORNER DOOR CORNER PIECE (green) -
Page 18: Attaching Wall Panel Standoffs
Attaching Wall Panel “Standoffs”: The four vented wall panels have four pre-drilled mounting holes. Insert 1⁄4” mounting bolts (Hardware List Item C) through wall panel and secure with stand off (Hardware List Item B) as shown in Fig 7 & Fig 8. Make sure standoffs are installed on interior white side of panel. - Page 19 Close Latch Install remaining vented wall panels. SUN CAPSULE I ONLY: Install two remaining corner pieces with pre-drilled holes for door assembly (green label). Make sure pre- drilled holes are mounted as shown in Fig 25.
-
Page 20: Ceiling Installation
SUN CAPSULE II ONLY (CONTINUED) COAT HOOK: Attach Coat Hook to wall panel as shown in Fig 21. Install wall panel with coat hook into remaining reverse bend corner piece. (Fig 1) Insert corner pieces on both wall panels &... -
Page 21: Installing Inside Fan Guard
(Fig 31). If necessary, do this to each corner before you attempt to secure the latches. WORKING TIP: If your Sun Capsule is being assembled on an uneven floor, you may have gaps between the Sun Capsule floor and the wall panel or the ceiling and wall panel. -
Page 22: Lamp Fixture Installation
(Fig 40). Install lamp fixture #4 repeating above procedures. Install lamp fixtures #3, #2 & #1 repeating above procedures. If you have a 220 Watt Sun Capsule II proceed to page 22 If you have a 160/200 Watt Sun Capsule II proceed to page 23... -
Page 23: Installing #6 Lamp Fixture - 220 Watt Scii Only
INSTALLING #6 LAMP FIXTURE: 220 WATT SUN CAPSULE II ONLY The following instructions should be NOTE: completed by two people. Remove screws from ceiling and floor.(Fig 41) Insert hinge pin into top hinge leaf on lamp fixture (Fig 42) Lift lamp fixture into dressing room portion of unit. -
Page 24: Installing #6 Lamp Fixture 160/200 Watt Scii Only
160 & 200 WATT SUN CAPSULE II ONLY Remove screws from ceiling & floor (Fig 47). Install top & bottom hinge pins. Do not overtighten (Fig 48 & 49). Make sure sleeve is installed on bottom hinge pin. (Fig 49). -
Page 25: Threshold Installation
(outer holes) and one wood screw (center hole). (Hardware List Item F) DOOR ASSEMBLY INSTALLATION: NOTE: All Sun Capsule I models must be mounted with hinge on left side. Sun Capsule II models are be mounted according to decorative package. -
Page 26: Installing #6 Lamp Fixture - Sun Capsule I Only
SUN CAPSULE I ONLY INSTALLING #6 LAMP FIXTURE: While one person steadies the door, the other person hangs the #6 lamp fixture on the door. (Fig 61). Use the heavy double support wires to lift fixture. IMPORTANT: Make sure you catch all four stand-offs Plug fixture #6 into fixture #1. -
Page 27: Installing Fan
FAN INSTALLATION: To avoid damage to fan blade, carefully place the upper fan assembly into hole on top of ceiling. Line up the pilot holes in ceiling with mounting holes in upper fan assembly, making sure power cord will be able to reach the junction box shown in Figure 68. -
Page 28: Mounting Junction Box
The plug can be inserted only one way. Do not force. FINAL ADJUSTMENTS: If your floor beneath the Sun Capsule is not level, the door will not be parallel to the ceiling framework. If this condition exists, the booth will need to be shimmed. -
Page 29: Peak Performance Voltage
VERY IMPORTANT There is NO NEUTRAL in any 60 Hz Sun Capsule VHR System!!! *50 Hz systems must operate between 220 volts and 225 volts. -
Page 30: Lamp Fixture Wiring Diagrams
TOP LAMP SOCKET STARTER HOLDER BALLAST BOTTOM LAMP SOCKET 4 LAMP FIXTURE WIRING... - Page 31 TOP LAMP SOCKET STARTER HOLDER BALLAST RECEPTACLE CAPACITORS BOTTOM LAMP SOCKET 10 LAMP FIXTURE WIRING...
- Page 32 TOP LAMP SOCKET STARTER HOLDER BALLAST RECEPTACLE CAPACITORS BOTTOM LAMP SOCKET 9 LAMP FIXTURE WIRING...
- Page 33 TOP LAMP SOCKET STARTER HOLDER BALLAST RECEPTACLE CAPACITORS BOTTOM LAMP SOCKET 8 LAMP FIXTURE WIRING...
-
Page 34: System Schematics
JUNCTION BOX On 50 Hz Systems these wires will be WHITE POWER SWITCH BLUE #6 RED 220 v ORANGE #6 BLACK 1 Ø RIGHT LEFT SPKR #6 GREEN GROUND GRAY FEMALE #14 BLK HEAD IMPORTANT #14 RED MALE PHONES This system EMER requires a STOP... - Page 35 JUNCTION BOX POWER SWITCH #6 RED BLUE ORANGE #8 BRN 3 Ø #6 BLK RIGHT LEFT SPKR #6 GRN GROUND GRAY #14 BLK FEMALE HEAD IMPORTANT MALE PHONES This system EMER requires a STOP CIRCUIT MINIMUM 5 WIRE BREAKER of 220 v CABLE 5 AMP and a...
-
Page 36: Trouble Shooting Guide
“Remote Timer” receptacle on the junction box. If the booth starts with the paper clip in place, either the timer or timer cord is faulty. If the booth does not start, then the problem lies within the unit. At this point call Sun Capsule Service at (978) 532-7517 One Lamp Will Not Start 1. - Page 37 Trouble Shooting Your Timer 1. If you are using your Sun Capsule timer as a stand alone timer, the timer functions and operations are very basic. Should you somehow enter into the programming modes of the timer (the digital display begins to flash a series of random numbers) you can reset the timer in two ways: First, simply press the “Start/Stop”...
- Page 38 5 lamp fixture is faulty. 3. There are two 5-amp circuit breakers on the control panel on the inside of the Sun Capsule. One of these breakers protects the fan motor. Check to see if one of the breakers is popped out. If so, push the breaker back in and restart the unit.
-
Page 39: Warranty And Warranty Card
Sun Capsule Limited Warranty Card ��� ����� ������ ���� ��� ���� ���������� ���� �������� ������������ ��� �������� ���� ���� ������� �� ���� �� ����������������������������������������������� ���� ������������������������ ���� �� ��������� ���� �� �������������������������������������������������������������������������������� ���������������������������������������������������������������� ������������������������ ���� �������� ���� ��� �������� ��������� ��������... - Page 40 96 AUDUBON ROAD WAKEFIELD MA 01880 TEL: 978/532-7517 FAX: 978/532-8168 www.suncapsule.com...
