XPPen Deco Series Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Introduction .........................................................................................................................................1
Product Overview ....................................................................................................................... 2
Included with your product ........................................................................................................ 3
Connection ..................................................................................................................................3
Compatibility ............................................................................................................................ 11
Product Settings ................................................................................................................................ 11
Driver Installation .....................................................................................................................11
Introduction to Driver ...............................................................................................................15
Device Settings ......................................................................................................................... 17
Work Area ................................................................................................................................. 17
Screen ............................................................................................................................... 18
Drawing Tablet ................................................................................................................. 20
Pen Settings .............................................................................................................................. 21
Application ....................................................................................................................... 22
Pen Settings ...................................................................................................................... 23
Shortcut Keys ........................................................................................................................... 26
Driver Settings ..........................................................................................................................27
Driver Uninstallation ................................................................................................................ 28
FAQs ................................................................................................................................................. 28

Introduction

Thank you for choosing XPPen Deco Series drawing tablet. This user manual is
specially designed to detail the product's functions and features. Please read this
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Deco Series and is the answer not in the manual?

Questions and answers

Related Manuals for XPPen Deco Series

Summary of Contents for XPPen Deco Series

  • Page 1: Table Of Contents

    Shortcut Keys ........................... 26 Driver Settings ..........................27 Driver Uninstallation ........................ 28 FAQs ..............................28 Introduction Thank you for choosing XPPen Deco Series drawing tablet. This user manual is specially designed to detail the product’s functions and features. Please read this...

  • Page 2: Product Overview

    manual before using the product to ensure safe and proper use. Due to the latest product improvements, content may differ from the final product and is subject to change without prior notice. Note: The pictures in the User Manual are for reference only. The User Manual supplied with the device may vary depending on the model.

  • Page 3: Included With Your Product

    *Images and list are for illustrative purposes only. Please refer to the actual product. Included with your product Drawing Tablet Stylus Pen Nibs Pen Clip USB Cable OTG Adaptor*2 Bluetooth receiver (for wireless model only) * The list is for illustrative purposes only. Please refer to the actual product. Connection You can connect the device to your computer via the following methods.
  • Page 4 A. Download APP Search "ibis Paint X" or "ibis Paint" in the app store, and download and install it. It is recommended to update it to the latest version to be compatible with XPPen. * Please visit use of the APP.
  • Page 5 Turn on iOS device Bluetooth, and select the drawing tablet to complete pairing (blue light on upon successful pairing). Set APP...
  • Page 6 Connect XPPen Drawing Tablet. Open ibis Paint, and click "Settings". Find "Supported Handwrite Stylus" in Settings, and select XPPen Pen Tablet.
  • Page 7 Set pen pressure Turn on the pen pressure function.
  • Page 8 Drag the dot on the pressure sensitivity line to adjust pen pressure sensitivity.
  • Page 9 Set pen key functions Set functions corresponding to the pen key.
  • Page 10 Create a canvas and start your creation. Notes: The stylus has shortcut keys and pressure sensitivity functions which can be customized in the APP. The shortcut keys and wheel on the drawing tablet are temporarily unavailable. The driver settings are temporarily unavailable, so the mapping area cannot be customized.

  • Page 11: Compatibility

    Connect wirelessly via Bluetooth: Windows 10 or later macOS 10.10 or later Product Settings Driver Installation To ensure the device wroks properly, please install the driver before using. Please download the driver suitable for your product model from XPPen website (https://www.xp-pen.com). Notes:...
  • Page 12 1. Before installing the driver, please turn off all antivirus software and graphics software. 2. Uninstall drivers (if any) for other drawing displays/tablets before the installation. 3. Restart your computer after the installation is completed. 4. For the best performance for your device, we recommend you install the latest driver.
  • Page 14 If there is no PenTablet_Driver on the list, go to Resource Library -> Application Support -> PenDriver to add the driver manually. Linux: Deb: Enter command sudo dpkg -i. Drag the installation file to the window and execute the command; Rpm: Enter command sudo rpm -i.

  • Page 15: Introduction To Driver

    Tag.gz: Unzip file. Enter command sudo. Drag install.sh to the window and execute command. Introduction to Driver The driver will run automatically after being installed. If it does not run automatically, go to the driver folder to run it manually. Windows: Start ->...
  • Page 16 You can connect up to 3 devices via the driver at the same time. Customize a specific device's settings after switching to that device, and all changes made will only apply to that device. Configuration saving: After changing the configuration, click the "Store" button in the lower left corner of the driver interface, otherwise, the modified configuration is valid only for the time it is currently in use.

  • Page 17: Device Settings

    Device Settings You can set the drawing tablet functions, including: 1. Work Area 2. Pen Settings Shortcut Keys * Functions may vary depending on the model. Work Area Go to Work Area and define the mapping between the device's work area and the screen display area.

  • Page 18: Screen

    Screen You can set the mapping between the display area of the current monitor and the device. If multiple monitors are used in copy mode, the work area of the device will be mapped to all monitors. When the pen moves in the work area, the cursor on all monitors will move at the same time.
  • Page 19 2. Customize screen area: There are three ways to customize the work area. 1) Drag to select an area: Drag the cursor from one point to another on the Screen. 2) Use the cursor to select an area: Select "Click to set screen area", then click the upper left corner position and lower right corner position to select on the screen.

  • Page 20: Drawing Tablet

    3) Coordinates: Manually enter coordinates in the corresponding input boxes for X, Y, W and H. Show display number: Identify all connected monitors. The numeric identifier will be displayed in the lower left corner of each monitor. Drawing Tablet You can set the work area of current device here. The driver enables the following ways to set the work area of the device: 1.

  • Page 21: Pen Settings

    1） Drag to select an area: Drag the cursor from one point to another on the device. 2） Use the pen to select an area: Select "Click to set active area", then use stylus to click the upper left corner position and lower right corner position on your device.

  • Page 22: Application

    Application The driver allows you to set pen keys, shortcut keys and roller/touch functions for a specified application. Select an application from the list of applications at the top of the driver, tick the application, and then customize its pen keys, shortcut keys and roller/touch functions. For example, if you select an application and change its configuration in the driver, the change is valid only when you use the application.

  • Page 23: Pen Settings

    If you select all other applications, it will apply to other uncustomized applications. Pen Settings Click "Customize" in the drop-down menu to go to shortcut key settings and customize pen key functions. Before setting shortcut key functions, tick to select any of the options under Keyboard, Mouse Control, Others, and Run Application.
  • Page 24 You can set keyboard shortcut, for example, set it as “Alt+A” in 3D MAX, so the alignment tool can be used. You can set a combination of multiple keys such as Ctrl+C and Ctrl+V. When you press the combination key, the set shortcut keys will all run once. Windows (Command): You can add a combination key containing system key, for example: to enter Win(Cmd)+Shift+3, you can press Shift+3 and the driver will bring the system key automatically.
  • Page 25 Other: Precision mode: It limits the work area to a small area. This function allows you to draw more precisely in the area. Run Application: Run the selected application. Customized name: You can customize the name of the current key settings. Pressure settings: The sensitivity of pressure can be adjusted by adjusting the Output and Pen Pressure curve or moving the slider on the progress bar.

  • Page 26: Shortcut Keys

    Mouse mode: When you move your pen out of the work area, the cursor will stay where you leave, which is like operating a mouse. Select the mode and you can adjust the speed of the cursor on your device. If you do not select the mode, the pen mode applies by default. Windows Ink (for Windows only): Windows supports handwriting function.

  • Page 27: Driver Settings

    Customize: Click "Customize" in the drop-down menu to customize key functions. The setting steps are the same as pen key settings (see Pen settings). Driver Settings Disable Shortcut Key: Disable the functions and prompts of all keys of the device.

  • Page 28: Driver Uninstallation

    Disable Message: When you press a key, no key message will be displayed at the bottom of the screen. Disable Pressure: You will not feel the pressure of the stylus when using the stylus. Disable tilt: This will disable the tilt effect of the stylus. Import &...
  • Page 29 3、 The drawing software cannot sense the pen pressure while the cursor can move. a) Check if the drawing software supports pen pressure; b) Download the latest driver installation files from XPPen website, and check if the pen pressure is normal in the driver;...
  • Page 30 Email: service@xp-pen.com...
