Summary of Contents for REDATOM RED-EXT-4K-HDBASET
- Page 1 RED-EXT-4K-HDBASET Product Manual HDMI 2.0 Extender 40M 4K30 4:4:4/4K60 4:2:0 HDBaseT www.redatomproducts.com...
-
Page 2: Included In The Box
Introduction The RED-EXT-4K-HDBASET is an HDMI extender featuring HDBaseT technology, allowing for the extension of 4K HDR HDMI signals up to 40 Meters. Equipped with Bi-directional POC and IR extension the RED-EXT-4K-HDBASET makes extension easy by transmitting video, control, and power over a single piece of Category cable. -
Page 3: Panel Descriptions
Panel Descriptions Transmitter Front Panel: • SERVICE USB input — For service & firmware updates only; Do not use. • IR Transmitter input • IR Receiver input • HDMI IN input • SYNC LED Light On — HDMI Source is Active on the HDMI input Light Off —... -
Page 4: Receiver Front Panel
Panel Descriptions Receiver Front Panel: • SERVICE USB input — For service & firmware updates only; Do not use. • IR Transmitter input • IR Receiver input • HDMI OUT input • SYNC LED Light On — HDMI Source is Active on the HDMI input Light Off —... -
Page 5: Connections And Operations
Receiver HDBT IN input 4. Insert the DC end of the power supply into either the Transmitter or the Receiver of the RED-EXT-4K-HDBASET — the opposite unit does not need to be plugged in as it features Power over Cable (PoC) 5. -
Page 6: Troubleshooting
Troubleshooting TRANSMITTER No power LED • Ensure power supply unit is sending proper voltage • If using POC, ensure that the unit sending POC is connected to power • If using POC, try powering the unit directly to ensure unit operates stand alone No HDMI LED •... -
Page 7: Warranty Information
Troubleshooting (continued) IR TRANSMISSION • The Visible IR Emitters can be used to ensure signal is being sent from one point to the other Warranty Information • This warranty applies to US Residents who purchase from an authorized RED ATOM Dealer. RED ATOM media distribution products are covered against defects in materials and workmanship for 1 year from date of purchase. - Page 8 www.redatomproducts.com Questions? Contact us at info@redatomproducts.com...
