- Page 1 Wireless LAN INTERNET RADIO MD 85651 Schnellstartanleitung Quick Start Guide Instructions de démarrage rapide Guida rapida Manual de inicio rápido Snelstarthandleiding Lynstartvejledning www.medion.com...
- Page 2 Wireless LAN INTERNET RADIO MD 85651 INSTRUCTION MANUAL...
-
Page 3: Table Of Contents
Restricted Warranty ..........37 MD 85651... -
Page 4: Safety Instructions
Any condensation which forms could damage the unit. The device can be operated as soon as the unit has reached room temperature. Thunder storms Unplug the device if you are away for a long period of time or there is a storm. MD 85651 EN-2... - Page 5 If battery acid leaks out it is essential to avoid contact with the skin, eyes and mucous membranes! If the acid does come into contact with skin, immediately rinse the affected areas with plenty of clear water and contact a doctor immediately. MD 85651 EN-3...
-
Page 6: Preparation
Betrieb des UKW-Radios: Stecken Sie die mitgelieferte UKW-Antenne in die Buchse FM-ANT (2). Netzadapter: Verbinden Sie den Gerätestecker des mitgelieferten Netzadapters mit dem Anschluss PO- WER und den Netzstecker mit einer Steckdose 230 V ~ 50 Hz. MD 85651 EN-4... -
Page 7: Overview
(suche as a stereo system or loudspeakers) 17.STATUS: status LED (flashes when no cable is connec- ted; lights up permanently when an Ethernet cable is con- nected) 18.Socket for Ethernet cable (RJ45) 19.Socket for W-LAN antenna MD 85651 EN-5... -
Page 8: Remote Control
REW: during playback of audio titles: fast backward MEDIA PLAYER: select Media Player operation RADIO IP: select IP Radio operation STOP: open main menu; during playback of audio titles: stop playback Light: switch display light on and off MD 85651 EN-6... - Page 9 Launches 15, 30, 45, or 60 min STOPS the No function timer to stop current music source music (Goes back (Goes back to clock screen with to clock screen & timer icon ON). reactivates alarm after 10 min.). MD 85651 EN-7...
- Page 10 If radio FM (direct access) : Goes back to the menu list. Otherwise: Goes back to radio list. Media First press: Identical. Server Goes back to song playing screnn. MP3 Player Second press: Goes back to songs list. MD 85651 EN-8...
-
Page 11: Menüstruktur
Internet Radio Station List Location Genres New Stations Popular Stations Favorite Stations Genre Location FM Radio FM Sensitivy High Station List Favorite Stations Update List Direct Access Media Server MP 3 Player Alarm Alarm 1 Alarm 2 MD 85651 EN-9... - Page 12 Language Backlight Always ON 1 Minute 3 Minutes 10 Minutes 30 Minutes Equalizer Normal Classic Rock Jazz Advanced Setup Network Setup Configure Network Reset to Default Clear Favorites Device MAC Address Firmware Version F/W Upgrade (thru. USB). MD 85651 EN-10...
-
Page 13: Installation
... 3. There is a wireless router device in your home, the Wi-Fi IP Radio device will be able to operate with your home network. Moreover, the Wi-Fi IP Radio allows to play the music loaded in your PC, this one being connected to the same router. MD 85651 EN-11... -
Page 14: Configuration As A Wireless Client
Scanning for available APs. " " button " " button Select the AP that you can (once) or "OK" button connect to your router device. Numeric key "OK" button Enter the encryption key if pads the AP is encrypted. MD 85651 EN-12... - Page 15 " " button " " button (4 times) or "OK" button " " button " " button (once) or "OK" button " " button Manually select the wireless client or "OK" button mode. Scanning for available APs. MD 85651 EN-13...
-
Page 16: Configuration As A Wired Client
(A) Using the device for the first time, without an Ethernet cable connection: If the radio is switched on after a reset, wireless client mode will be chosen, even if Ethernet cable has already been plugged in. Screen on the Screen shot Next screen Comment right Initial screen MD 85651 EN-14... - Page 17 "OK" button " " button " " button Manually select the wired client (once) or "OK" mode. button " " button " " button Select the DHCP for auto (once) or "OK" configured IP address. button MD 85651 EN-15...
-
Page 18: Configuration As A Wireless Access Point (Ap)
Manually set to the Wireless AP Mode: Screen on the Screen Next screen Comment right "OK" button Initial screen " " button " " button (4 times) or "OK" button " " button " " button (once) or "OK" button MD 85651 EN-16... - Page 19 Enter the encryption key if the AP is encrypted. "OK" button Confirm the settings above. Apply new settings. The device is in wireless AP mode now. The device is already connected to your network and can now operate. MD 85651 EN-17...
-
Page 20: Using The Ip Radio As A Media Client
Press the 'OK' button to try to connect to the server. The Wi-Fi IP Radio screen will read "Connecting…." and will then display the following list: You can browse the "Music" list and play the music of your choice. MD 85651 EN-18... -
Page 21: Listening To Music
It takes few seconds to get the list from the Internet. The next screen is as follows. It means the Wi-Fi IP Radio has successfully connected to the Internet server and has retrieved information from the server. MD 85651 EN-19... - Page 22 " " button . " " button Press the " " button to add the or "OK" button current station to the list of favorites for quick access in future. Try to connect to the radio station. MD 85651 EN-20...
-
Page 23: Listening To Fm Radio
Commands from the remote control: Frequency choice mode: Forward/backward in frequency range (step of 0.05Mhz). Auto scanning to previous/next. Back to menu. Vol -, Decrease the volume. Vol +, Increase the volume. Add (or remove) the station (to the) from favourites. MD 85651 EN-21... - Page 24 There are 15 stations tuned. " " button " " button Press the " " button to add or "OK" button the current station to the list of favorites for quick access in future. Tuned to station and music playing… MD 85651 EN-22...
-
Page 25: Listening To The Music In Your Computer
Please check to ensure you have activated the media server on your computer. If, after that, there are still no media servers on the list, please refer to the troubleshooting chapter to identify the problem and solve it step by step. MD 85651 EN-23... - Page 26 Wait until end Music playing. of song, or press " " for next song. Next song playing. Once the music starts, you can use the playback buttons, as you would with a traditional stereo or CD player. MD 85651 EN-24...
-
Page 27: Listening To The Music On Your Usb Drive
The following screen shots illustrate the sequence used to listen to the music in the folder "Diamonds Love Song" in the attached USB drive. Screen on the Screen shot Next screen Comment right " " button Initial screen or "OK" button MD 85651 EN-25... -
Page 28: The Playback Screen
& artist, and the music progression. There is also a status line at the bottom of the screen. This shows the current state of the wireless signal, the connection quality, the connection status, and the playback status. This information can help with troubleshooting if you encounter problems while listening to the music. MD 85651 EN-26... -
Page 29: Alarm
" " and " " buttons to switch between the items to be altered. The selected item will flash. b.Use the " " and " " buttons to alter the value selected. c.Press the "OK" button to confirm. MD 85651 EN-27... -
Page 30: Alarm Settings
"OK" button Initial screen "OK" button " " button "OK" button Enable alarm 1. (Once) "OK" button Use the 4 directional buttons to set the time; " " button Set Internet radio as alarm source. or "OK" button MD 85651 EN-28... - Page 31 10 minutes later. You can press the "STOP" button to switch the alarm and music off completely. In rest position, there is no icon displayed to indicate that alarm is on. MD 85651 EN-29...
-
Page 32: Snooze
Comment right "OK" button Initial screen " " button " " "OK" button " " button " " Countdown "OK" button " " "OK" button You can also press the "SNOOZE" key on the remote control repeatedly. MD 85651 EN-30... -
Page 33: Miscellaneous Setup Functions
You may choose the IP radio and V-tuner languages. Choice of main language (IP radio): Choice of V-Tuner language: Equalizer Settings You can adjust the equalization from Radio, media server and MP3 menus. Once the selected station screen, or file is selected, press OK. MD 85651 EN-31... -
Page 34: Reset To Factory Default Settings
This function will allow you to proceed the software updating by mean of an USB2 key containing the programm file. Check the MEDION website to see whether there is any new firmware for this device to upgrade it. If any new firmware has been released, download it and follow the upgrade procedure below to upgrade the firmware on your device. -
Page 35: Appendix
Not able to get IP Address. DNS no response. Please ping the IP address of the DNS to check if this is the case. DNS doesn't have the record of the vTuner server or radio station that you are trying to connect. MD 85651 EN-33... - Page 36 There is some buffering trouble on the internet. The available band- and the radio station was OK. width is not good enough to have the stable streams from the radio station. BUT: ONLY FOUR BARS IN THE RA- DIO STATION LOGO MD 85651 EN-34...
-
Page 37: Technical Data
Ethernet Port RJ 45 WiFi antenna: 2dBi, external FM antenna: 3,5 mm socket LINE OUT: AV cinch sockets, stereo Head phone: 3,5 mm socket, stereo USB connection: Readable audio formats: *.mp3, *.wma, *.wav Subject to technical changes! MD 85651 EN-35... -
Page 38: Disposal
At the end of its life, the device must not be disposed of in household rubbish. Seek the advice of your local authority on correct, environmentally-friendly disposal. Dispose of the unit and the batteries separately. Batteries Do not put used batteries in the household rubbish. Batteries should be deposited at a collection point for used batteries. MD 85651 EN-36... -
Page 39: Restricted Warranty
This warranty shall be void and you may be required by MEDION to reimburse MEDION for the reasonable costs of postage and packaging before MEDION will return the product to you. If so and you would still like MEDION to repair or replace the product, MEDION may do so but you will be charged MEDION's standard rates for repair and replacement for this service. - Page 40 Incomplete contents of the returned package may lead to a delay in the repair or replacement. MEDION does not accept any liability for any additionally submitted material(s) which were not supplied with the original MEDION product.
- Page 41 100% accuracy of the maps provided with the Navigation device. It may be necessary to delete all data in the product in order to repair the MEDION product. PLEASE MAKE SURE THAT YOU HAVE A BACKUP COPY OF ALL DATA ON THE PRODUCT BEFORE RETURNING THE PRODUCT TO MEDION.
- Page 42 You are responsible yourself for restoring the application software after the repair services have been carried out by MEDION or its authorised personnel. You must take all other necessary steps to enable MEDION or its authorised personnel to carry out your or- der properly.
- Page 43 www.medion.com...
