A. General
The KAA07110 is the latest, state of the art Telephone Handset for BK KNG-M series mobile transceivers. Its
ruggedized design allows its use for the most demanding and harsh environments and still maintain a more private
communication for the end user.
B. Included in the Box
Telephone Handset – 1x
1.
Handset Cradle – 1x
2.
Cradle Mounting Screws – 3x
3.
Cradle Mounting Nuts – 3x
4.
5.
Mounting Plate
Mounting Plate Screws – 3x
6.
DB25 Mic Interface Cable Assy. – 1x
7.
Cable Clamp – 2x
8.
C. Controls
Volume Control:
Receive audio
volume is adjusted
using this Up and
Down button.
PTT Button:
Push to talk.
Release to listen.
Rev. 06-20
KAA07110
KNG-M Series Telephone Handset
1 of 2
5
6
1
3
4
2
Emergency Button:
When configured in the radio, the
Emergency Button function is
extended to the microphone for
Speaker
Microphone
7001-31079-600
7
8
easy access.
Advertisement
Table of Contents
Summary of Contents for BK TECHNOLOGIES KNG-M Series
- Page 1 KNG-M Series Telephone Handset A. General The KAA07110 is the latest, state of the art Telephone Handset for BK KNG-M series mobile transceivers. Its ruggedized design allows its use for the most demanding and harsh environments and still maintain a more private communication for the end user.
- Page 2 10. Plug the RJ45 connector from the Handset into the RJ45 jack in the DB25 Mic Interface. 11. Install the cable clamp on the side of the Remote mounting bracket to hold the Handset cable in place. BK Technologies 1-800-648-0947 www.bktechnologies.com...
