Pioneer HTV-SW2 KUCXC Service Manual

Speaker system

Advertisement

Quick Links

SPEAKER SYSTEM
HTV-SW2
This product is component of system.
For the operating instructions, refer to the service manual RRV1978 for HTV-C2.
65S
This service manual is intended for qualified service technicians; it is not meant for the
casual do-it-yourselfer. Qualified technicians have the necessary test equipment and
tools, and have been trained to properly and safely repair complex products such as
those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability
of the product and may void the warranty. If you are not qualified to perform the repair
of this product properly and safely, you should not risk trying to do so and refer the
repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals
which are known to the state of California to cause cancer, birth defects or other
reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
PIONEER ELECTRONIC CORPORATION
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Wheelock Place, Singapore 238880
PIONEER ELECTRONIC CORPORATION 1998
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The woofer is attached to the baffle by 4 external screws.
To detach it, unfasten those screws. When attaching it, face its
terminal backward.
The Amp is attached to the back board by 9 external screws.
To detach it, unfasten those screws and pull straight it toward
back. To detach it, first remove connector on bottom side. Then
remove it.
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
KUCXC
T-ZZW JUNE 1998 Printed in Japan
ORDER NO.
RRV1970
