Model: Aouh12Luas1 - Fujitsu ACUH12LUAS1 Design & Technical Manual

6-2. Model: AOUH12LUAS1

NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Indoor unit is higher than outdoor
unit *1
Indoor unit is lower than outdoor
unit *2
HEATING
Indoor unit is higher than outdoor
unit *1
Indoor unit is lower than outdoor
unit *2
6-2. Model: AOUH12LUAS1
m 5
ft 16
15 49 -
10 33 -
7.5 25 -
5 16 1.017
0 0 1.025
-5 -16 1.025
-7.5 -25 -
-10 -33 -
-15 -49 -
m 5
ft 16
15 49 -
10 33 -
7.5 25 -
5 16 1.017
0 0 1.017
-5 -16 1.012
-7.5 -25 -
-10 -33 -
-15 -49 -
- 83 -
Pipe length
7.5 10 15
25 33 49
- - 0.877
- 0.956 0.891
0.988 0.960 0.895
0.992 0.964 0.899
1.000 0.971 0.906
1.000 0.971 0.906
1.000 0.971 0.906
- 0.971 0.906
- - 0.906
Pipe length
7.5 10 15
25 33 49
- - 0.933
- 0.981 0.933
1.000 0.981 0.933
1.000 0.981 0.933
1.000 0.981 0.933
0.995 0.976 0.928
0.993 0.974 0.926
- 0.971 0.923
- - 0.914
6. Capacity compensation rate for pipe length and height difference
20
66
0.874
0.888
0.892
0.895
0.902
0.902
0.902
0.902
0.902
20
66
0.925
0.925
0.925
0.925
0.925
0.920
0.918
0.916
0.906
