Philips 43PFH4082/96 Service Manual
  1. Manuals
  2. Brands
  3. Philips Manuals
  4. TV
  5. 43PFH4082/96
  6. Service manual

Philips 43PFH4082/96 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
4082
Chassis name
Platform
Model name
4082
MSD3463
43PFH4082/96
Published by Yingqun.Wen 4082 Quality
Subject to modification
2017-Nov-25
2017
TP Vision Netherlands B.V.
©
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 43PFH4082/96 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips 43PFH4082/96

Summary of Contents for Philips 43PFH4082/96

  • Page 1 Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 2: Table Of Contents

    Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.

  • Page 3: Product Inforamtion

    1. Product information Product information is subject to change without notice. For detailed product information，please visit www.philips.com/support Display Type Diagonal screen size • 43PFH4082/96: 42.51 inch Display resolution • 43PFH4082/96 : 1920*1080p Input resolution • 800 x 600p - 60 Hz •...
  • Page 4 PC input (VGA) AV （input） Headphone Video and Audio out Digital audio out (SPDIF) Co-axial Out co-axial/Optical RJ45 DLNA/ Certification WiFi EasyLink (HDMI-CEC) Antenna Tuner /Satellite tuner Antenna Tuner(down) Wireless connections Wi-Fi Band Concurrent Bluetooth for subwoofer/RC (do not claim commercially) MHL(Version ) HDMI-1...
  • Page 5 Power Product specifications are subject to change without notice. For more specification details of this product, see www.philips.com/support Power • Mains power : AC 100-240V 50/60Hz • Standby Energy Consumption:≤0.5W • Ambient temperature : 5°C to 40°C...

  • Page 6: Connections Overview

    2. Connections Overview...

  • Page 7: Mechanical Instructions

    3. Mechanical Instructions 3.1 Cable Dressing Serial no part description function Backlight wire Connect to PJ2 Power wire Connect to PCN105 LVDS wire Cn401 to T-CON board Speaker wire CN203 to speaker (yellow black wire) Speaker wire CN201 to speaker (red black wire) two-terminal wire CN104 to IR board two-terminal wire...
  • Page 8 3.2.3 Disassemble Back Cover-2 Take off screws with electric screwdriver. Figure 1 2. Categorize and place removed screws at the appointed material box. Do not mix with other material. 3. Both hands respectively grasp the middle of left and right sides of back cover-M,lift the right side of back cover to separate the buckle on lower right side of back cover-M,from back cover-L.Then Pushing back cover-M toward right and up to make the buckle on the lower left side of back cover-M separate from back cover-R.
  • Page 9 Figure 2 3.2.4 Disassemble Wire 1. Use diagonal pliers to cut off 2pcs cable ties from the baffle and place them at appointed position. Figure 1 2. As figure show,tear off fabric tapes from wires and place them at appointed position. Figure 1 3.
  • Page 10 3.2.5 Dismantle left/right back cover 1. Use electric screwdriver to dismantle 2pcs Ф3×6mm screws from back cover. Figure 1 2. Place removed screws at the appointed material box. Do not mix with other material 3. Take down back cover-L and back cover-R respectively,and place them at appointed position. 4.
  • Page 11 3.2.6 Dismantle speaker & key module 1. Unplug speaker's wire from the buckle of back cover-L,as Figure1 show. Then take down speaker from its plastic pillar. Figure 1 2. Unplug speaker's wire from back cover-R by the same way. Figure 1 3.
  • Page 12 3.2.8 Dismantle IO baffle 1. Use electric screwdriver to dismantle 4pcs Ф3×3mm screws from IO baffle. Figure 2 2. Put removed screws in the material box. Do not mix with other materials. 3. Take down IO baffle from right side and lower side,and place them at appointed position orderly. 4.
  • Page 13 3.2.11 Dismantle lower bracket 1. Use electric screwdriver to dismantle 7pcs Ф3×3mm screws from lower bracket. Figure 1 2. Put removed screws in the material box. Do not mix with other materials. 3. Take down lower hardware and hardware bracket,put them at appointed position orderly. 3.2.12 Dismantle mylar film and hexagonal screw 1.
  • Page 14 2. Tear off mylar film and put it at appointed position. 3. Use electric screwdriver to dismantle 4pcs hexagonal screws from back plate,as figure show. Figure 2/A 3.2.13 LCD Panel 1. Remove the SSB as described earlier. 2. Remove the PSU as described earlier. Remove the keyboard control panel as described earlier.

  • Page 15: Factory Modes

    4. Factory Mode Purpose Press the following key sequence on a standard RC transmitter: “1999” directly followed by MENU, To perform extended alignments.  Primary menu Secondary menu Value,remark VGA/YPBPR(SD)/YPBPR(HD) MDOE ,Selection R-GAIN G-GAIN Front-end gain adjustment ADC ADJUST B-GAIN R-OFFSET G-OFFSET Clamp level adjustment...
  • Page 16 Backlight Adjust backlight Overscan_resolution Reselution select Overscan_hsize Adjust overscan H size OverScan Overscan_hposition Adjust overscan H position Overscan_vsize Adjust overscan V size Overscan_vposition Adjust overscal V position HDCPKey usb upgrade HDCPKey usb upgrade SW information SW information MODE Feature Selection OSD 0 OSD 25 Non-linear...

  • Page 17: Software Upgrading And Panel Code

    5. Software Upgrading and Panel Code Software Upgrading Operations and procedure of software upgrading: 1). Changed the file name to "MERGE.bin", then stored software in the FA T32 format blank U disk. 2). Insert USB flash disk into the USB upgrade port, upgrade the software according to the following the operating instructions: Select AIR or DTV signal source, press Menu key to pop up the main menu, then choose.
  • Page 18 Press the following key sequence on a standard RC transmitter: “1999” directly followed by MENU, can see the panel type information from factory menu, see the Panel PN from the configuration table CTN_ALT BOM# Panel Type Panel PN 43PFH4082/96 K430WDK3-LA260A4 7422-430LGK-385AK041-F...

  • Page 19: Circuit Descriptions

    6.1 Introduction The 4082 is covered by MSD3463 platform. The major deltas versus its predecessor support DVB-T, with also multi-media, Video out The 4082 chassis comes with the following stylings: Series 4082 43PFH4082/96  6.1.1 Implementation Key components of this chassis are: TUNER POWER AS1117 ...
  • Page 20 Always replace a defective fuse with one with the correct specifications! This part is available in the regular market. Consult the Philips Service web portal for the order codes of the boards. Important delta’s with the platform are: •...
  • Page 21 6.3 DC/DC Converters The on-board DC/DC converters deliver the following voltages(depending on set execution): • +5V-SB, permanent voltage for the Stand-by Power system • +3V3-STANDBY,voltage for IR/Key board • +12V, input from the power supply for the panel common(active mode) •...
  • Page 22 6.3.2 Power layout SSB PU11 Back L405 5V light for USB MP3394S Main power chip 5269 L111 for Panel L404 5V PU12 for USB Change to5V L207 L210 U105 1.2V for 12V for Audio MSD3463 U114 3.3V MSD3463&FLASH U8 1.5V for MSD3463 U1001 3.3V...
  • Page 23 SI2151 6.5 HDMI Refer to below for the application. The following HDMI connector can be used: • HDMI 1: HDMI input ( TV digital interface support HDMI1.4a) with digital audio/PC DVI input/MHL/CEC • HDMI 2: HDMI input ( TV digital interface support HDCP) with digital audio/PC DVI input/CEC •...
  • Page 24 6.6 Video and Audio Processing - MSD3463 The MSD3463 is the main audio and video processor (or System-on-Chip) for this platform. It has the following features: 1. Worldwide multi-standard analog TV demodulator 2.PAL/SECAM/DVB-T/DVB-T2 /DVB-C demodulators 3.1920*1080@60Hz direct drive 4. Powerful CPU core 5.

  • Page 25: Ic Data Sheet

    7. IC Data Sheets...

  • Page 27: Circuit Diagrams

    8. Circuit Diagrams MSD3463-T8C2 Three in One board Circuit Diagrams VER:A1.0 2015-11-10 PAGE Content Index&History Rev Block Diagram Power & LED Driver System Power MSD3463 Video&VGA&USB&Amplify &LVDSpage HDMI page Tuner page History Rev Author DATE Description 11/10/2015 Ver:A1.0 First Version Release ZHQING This document for ShenZhen KTC Technology CO., Ltd and presented party internal use only, Do not spread to third party without the written permission.
  • Page 28 Dri v e LED Backl i g ht BOOST switching circuit 12V_NORMAL RESET Panel Voltage 40P LVDS SPK-L TUNER_3.3V TUNER PWR Audio AMP AS1117 TPA3020 12V_NORMAL SPK-R MOS tube control 12V OUTPUT 12V_NORMAL DC/DC convert Output filtering circuit Rectification 1.15V VDDC PWR DC-DC 5V_NORMAL...
  • Page 29 SR5200 SR5200 +30V PL19 PL19 68uH 68uH PD12 PD12 PL15 PL15 SR5200 SR5200 PL18 PL18 PT1A PT1A PC88 PC88 47Ω 47Ω PR268 PR268 RL207 RL207 EFD30 EFD30 PC90 PC90 PR239 47Ω PR239 47Ω PEC2 PEC2 PEC5 PEC5 1UF/35V 1UF/35V 10nF 10nF AOD478 AOD478...
  • Page 30 1.2V 2A for VDDC Support H.265 need 1.2V, MAX 2A +5V_Standby +1.15V_VDDC L104 L104 3.3uH/2A 3.3uH/2A U105 U105 C128 C128 C133 C133 C129 C129 R123 R123 U114 U114 Imax=350mA 0.1uF 0.1uF C121 0.1uF C121 0.1uF C119 C119 C120 C120 C132 C132 C122 C122...
  • Page 31 DDR3 POWER CORE POWER OTHER AVDD_DDR_DATA AVDD5V_MHL +1.5V_DDR AVDD_DDR_CMD AVDD_DDR_DATA AVDD_DDR_CMD +1.15V_VDDC VDDC DVDD_DDR AVDD_ETH VDDC VDDC AVDDL_DVI VIFP 0.1uF 0.1uF C254 C254 AVDDL_DVI DIF+ FB205 FB205 FB212 FB212 VIFM 0.1uF 0.1uF C250 C250 AVDD_MOD1 DIF- IFAGC_T DVDD_DDR IFAGC_T C249 C249 C251 C251...
  • Page 32 YPBPR & VIDEO R509 R509 PC_LIN R513 R513 PC_RIN USB ESD分布电容要求<2pF +5V_USB1 R516 R516 R517 R517 USB0_DM CN10 CN10 PHONEJACK PHONEJACK USB0_DM 5 R401 R401 USB0_DP AV-LIN USB0_DP 5 R402 R402 AV-RIN D701 D701 D703 D703 R404 R404 SHIELD R403 R403 C408 C408...
  • Page 33 HDMI1(ARC) HDMI0-RX2P HDMI0-RX2N P502 P502 HDMI0-RX1P HDMI0/5V HDMI0-RX2P HDMI0-RX1N DATA2+ HDMI0-RX0P DATA2 SHIELD HDMI0/5V HDMI0-RX2N HDMI0-RX2P HDMI0_RX2P HDMI0_RX2P 5 HDMI0-RX0N DATA2- HDMI0-RX1P HDMI0-RX2N HDMI0_RX2N HDMI0_RX2N 5 HDMI0-CLKP DATA1+ HDMI0-RX1P HDMI0_RX1P R519 R519 HDMI0_RX1P 5 HDMI0-CLKN DATA1 SHIELD HDMI0-RX1N HDMI0-RX1N HDMI0_RX1N R521 R521 HDMI0_RX1N 5...
  • Page 34 +3.3V_TU TUNER POWER U1001 U1001 GND_TUNER AS1117L-3.3 AS1117L-3.3 270nH 270nH 400mA 270nH 270nH GND_TUNER RF_REF 0.1uF 0.1uF T_IF-IN+ IF_P 39pF 39pF RF_IP RF_IN 47pF 47pF 0.1uF 0.1uF T_IF-IN- +3.3V_TU IF_N Si2151 Si2151 +5V_Normal_T 39pF 39pF RF_IN GND_TUNER 270nH 270nH 270nH 270nH XTAL_I 180nH...

  • Page 35: Styling Sheet

    9. Styling Sheet 4082 series 43"...
